Kramer VM-22H Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VM-22H

2x1:2 HDMI Switcher/DA

P/N: 2900-000663 Rev 3

VM-22H – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Defining the VM-22H 2x1:2 HDMI Switcher/DA 4

4Connecting the VM-22H 6

5Acquiring the EDID 7

6Technical Specifications 9

Figures

Figure 1: VM-22H 2x1:2 HDMI Switcher/DA 5

Figure 2: Connecting the VM-22H 2x1:2 HDMI Switcher/DA 6

VM-22H - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Products.

Congratulations on purchasing your Kramer VM-22H 2x1:2 HDMI Switcher/DA,

which is ideal for the following typical applications:

Home theater, presentation and multimedia applications

Rental and staging

VM-22H - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerelectronics.com/support/product_downloads.asp

to check for up-to-date user manuals, application programs, and to check if

firmware upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer VM-22H away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

VM-22H - Getting Started

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning:

Disconnect the power and unplug the unit from the wall

before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

VM-22H - Overview

3 Overview

The VM−22H is a distribution amplifier for HDMI signals. The unit reclocks and

equalizes one of two selectable input signals and distributes it to two identical

outputs.

In particular, the VM-22H features:

A maximum data rate of 6.75Gbps (2.25Gbps bandwidth per graphic

channel

I-EDIDPro™ Kramer Intelligent EDID Processing™, an intelligent EDID

handling and processing algorithm that ensures Plug and Play operation for

HDMI systems

Kramer Equalization & re-Klocking™ Technology that rebuilds the digital

signal integrity to travel longer distances

3D pass-through

HDMI support for Deep Color, x.v.Color™, Lip Sync, CEC

HDCP compliance

Selected input and active output LED indicators

The VM-22H is 5V DC fed and is housed in a DigiTOOLS®enclosure.

3.1 Defining the VM-22H 2x1:2 HDMI Switcher/DA

This section defines the VM-22H.

VM-22H - Overview

Figure 1: VM-22H 2x1:2 HDMI Switcher/DA

Feature

Function

5V DC

+5V DC connector for powering the unit

HDMI OUT2 Connector

Connects to the HDMI acceptor 2

HDMI OUT1 Connector

Connects to the HDMI acceptor 1

HDMI IN 2 Connector

Connects to the HDMI source 2

HDMI IN 1 Connector

Connects to the HDMI source 1

REMOTE IR

The yellow LED illuminates when receiving signals from the

Infrared remote control transmitter

EDID SETUP Button

Press briefly to determine the type of EDID stored in the non-

volatile memory. Press and hold to select the desired EDID

setup and then release to acquire EDID (see Section 5)

IN SELECT Button

Press to select the input. The relevant IN LED illuminates

IN 1LED

Illuminates when input 1 is selected

IN 2LED

Illuminates when input 2 is selected

OUT 1 LED

Illuminates when output 1 is connected and active (also

illuminates or blinks during EDID setup, see Section 5)

OUT 2 LED

Illuminates when output 2 is connected and active (also

illuminates or blinks during EDID setup, see Section 5)

ON LED

Illuminates when receiving power

VM-22H - Connecting the VM-22H

4 Connecting the VM-22H

Always switch off the power to each device before connecting it to your

VM-22H. After connecting your VM-22H, connect its power and then

switch on the power to each device.

To connect the VM-22H as illustrated in the example in Figure 2:

1. Connect the HDMI source (for example, a DVD player) to the HDMI

IN 1 connector.

2. Connect the HDMI source (for example, a DVD player) to the HDMI

IN 2 connector.

3. Connect the HDMI OUT connectors to up to two HDMI acceptors, as follows:

HDMI OUT 1 connector to an LCD TV

HDMI OUT 2 connector to a plasma display

4. Connect the 5V DC power adapter to the power socket and connect the

adapter to the mains electricity.

5. Press the EDID SETUP button to acquire or change the EDID information

(see Section 5).

Figure 2: Connecting the VM-22H 2x1:2 HDMI Switcher/DA

VM-22H - Acquiring the EDID

5 Acquiring the EDID

This is usually done only once, when the machine is being set up in an installation.

Once acquired, the EDID is saved in non-volatile memory and further acquisition is

not necessary.

Initially, the VM-22H operates with the factory default EDID. This lets you connect

the power before connecting one of the acceptors or sources.

You can acquire the EDID from:

One output (the relevant output illuminates)

The default EDID (both output LEDs blink)

Two connected outputs, the auto-mix mode (both output LEDs illuminate)

The EDID acquired is a weighted average of all the connected outputs. For example, if

several displays with different resolutions are connected to the outputs, the acquired

EDID supports all the resolutions, as well as other parameters included in the EDID.

When pressing the EDID SETUP button briefly, the OUT LEDs indicate which type

of EDID was last acquired. If the:

OUT 1 LED illuminates, the OUT 1 EDID is stored in the non-volatile

memory

OUT 2 LED illuminates, the OUT 2 EDID is stored in the non-volatile

memory

OUT 1 and OUT 2 LEDs blink, the Default EDID is stored in the non-volatile

memory

OUT 1 and OUT 2 LEDs illuminate, the Auto-Mix EDID is stored in the non-

volatile memory

To acquire the EDID, do the following:

1. Connect the power.

2. Connect the output or outputs from which you want to acquire the EDID.
