USER MANUAL







Model:

VS-44HD

4x4 SD/HD-SDI Matrix Switcher

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 1

Overview 3

Your VS-44HD 4x4 SD/HD-SDI Matrix Switcher 3

Installing on a Rack 6

Connecting Your VS-44HD 7

6.1

Connecting Your VS-44HD 4x4 SD/HD-SDI Matrix Switcher 7

6.2

Connecting the VS-44HD as a Dual-Link 2x2 SD/HD-SDI Matrix Switcher 9

6.3

Setting the VS-44HD to work in the Dual-Link Mode 10

6.4

Dipswitch Settings 11

6.4.1

Setting the Machine # Dipswitches 11

6.5

Controlling via RS-232 (for example, using a PC) 12

6.6

Controlling via the RS-485 Port 13

6.7

Factory Reset 14

6.8

Switching Genlocked Video Signals 14

6.9

Controlling via ETHERNET 14

6.9.1

Connecting the ETHERNET Port directly to a PC (Crossover Cable) 14

6.9.2

Connecting the ETHERNET Port via a Network Hub (Straight-Through Cable) 16

6.9.3

Configuring the Ethernet Port 16

6.10

Controlling via the REMOTE Connector 16

Operating the VS-44HD 17

7.1

Switching OUT-IN Combinations 17

7.2

Switching OUT-IN Combinations in the Dual-Link Mode 17

7.3

Confirming Settings 18

7.3.1

Toggling between the AT ONCE and CONFIRM Modes 18

7.3.2

Confirming a Switching Action 18

7.4

Storing/Recalling Input/Output Configurations 19

7.4.1

Storing an Input/Output Configuration 19

7.4.2

Recalling an Input/Output Configuration 19

7.5

Locking the Front Panel 20

Technical Specifications 20

Table of Hex Codes for Serial Communication 20

Kramer Protocol 2000 21

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

Figures

Figure 1: VS-44HD 4x4 SD/HD-SDI Matrix Switcher 4

Figure 2: Connecting the VS-44HD 4x4 SD/HD-SDI Matrix Switcher 8

Figure 3: Connecting the VS-44HD as a Dual-Link 2x2 SD/HD-SDI Matrix Switcher 10

Figure 4: VS-44HD SETUP Dipswitches 11

Figure 5: Connecting a PC without using a Null-modem Adapter 12

Figure 6: Controlling via RS-485 (for example, using an RC-3000) 13

Figure 7: Local Area Connection Properties Window 15

Figure 8: Internet Protocol (TCP/IP) Properties Window 15

Figure 9: Using the REMOTE Connector 16

Tables

Table 1: Front Panel VS-44HD 4x4 SD/HD-SDI Matrix Switcher 5

Table 2: Rear Panel VS-44HD 4x4 SD/HD-SDI Matrix Switcher 5

Table 3: Machine # Dipswitch Settings 11

Table 4: Technical Specifications of the VS-44HD 4x4 SD/HD-SDI Matrix Switcher 20

Table 5: VS-44HD Hex Codes for Switching via RS-232/RS-485 20

Table 6: Protocol Definitions 21

Table 7: Instruction Codes for Protocol 2000 22

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups

that are clearly defined

by function.

Congratulations on purchasing your Kramer VS-44HD 4x4 SD/HD-SDI

Matrix Switcher. This product is ideal for:

Professional broadcasting and production studios

Presentation applications

The package includes the following items:

VS-44HD 4x4 SD/HD-SDI Matrix Switcher

Null-modem adapter, infrared remote control transmitter and power cord

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

2.1 Quick Start

This quick start chart summarizes the basic steps when connecting a

VS-44HD:

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Overview

3 Overview

The VS-44HD is a true 4x4 matrix switcher

for standard definition / high

definition SDI signals that lets you simultaneously route any of the four

inputs to any or all of the four outputs. It can be used as a 4x4 SD/HD-SDI

matrix switcher or as a dual-link 2x2 SD/HD-SDI Matrix switcher. The

VS-44HD features:

Input and output signals on BNC connectors and selector buttons that

automatically light up in different colors—green, when the VS-44HD

detects a ‘standard definition’ signal, or blue, when it detects a ‘high

definition’ signal

Reclocking and equalization on each input

The ability to switch genlocked video signals according to timing of the

GENLOCK reference input. Switching according to the Bi-level or

Tri-level Genlock input according to SMPTE RP-168

Factory reset that lets you reset the machine to its original default state

The storing and recalling of setups, a Take button for the execution of

multiple switches all at once, and a front panel lock

The VS-44HD is housed in a 19" 1U rack mountable enclosure and is fed

from a 100-240 VAC universal switching power supply. Control is via the

front panel buttons, infrared remote control transmitter, and/or remotely, by

RS 232 or RS 485 serial commands transmitted by a touch screen system, PC,

or other serial controller, as well as ETHERNET or remote contact closure for

forced operation.

To achieve the best performance:

Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables)

Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer VS-44HD

away from moisture, excessive sunlight and dust

4 Your VS-44HD 4x4 SD/HD-SDI Matrix Switcher

Figure 1, Table 1, and Table 2 define the VS-44HD 4x4 SD/HD-SDI Matrix

Switcher.

1 Switching is implemented during the vertical interval period according to the SMPTE RP-168 standard, when using

synchronized SDI sources

The sources must be genlocked to the GENLOCK input in order to switch cleanly

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VS-44HD 4x4 SD/HD-SDI Matrix Switcher

Figure 1: VS-44HD 4x4 SD/HD-SDI Matrix Switcher

Your VS-44HD 4x4 SD/HD-SDI Matrix Switcher

Table 1: Front Panel VS-44HD 4x4 SD/HD-SDI Matrix Switcher

# Feature Function

1 IR Receiver The red LED illuminates when receiving signals from the infrared remote control transmitter

2 POWER Switch Illuminated switch for turning the unit ON or OFF

3 INPUT SELECTOR

Buttons Select the input to switch to the output (from 1 to 4).

In the dual-link mode, select input 1 or 2 to switch dual-link 1 or 2 to the outputs

Press input buttons 1, 2 and 3 simultaneously, to reset the machine to its factory

default values

(see section 6.7)

Use to set the resolution when switching genlocked video signals (see section 6.8)

4 OUTPUT

SELECTOR Buttons

Select the output to which the input is switched (from 1 to 4). In the dual-link

mode, select the dual-link output 1 or 2 to which the input is switched

5 TAKE Button Pressing TAKE toggles the mode between the CONFIRM mode

and the AT

ONCE mode (user confirmation per action is unnecessary)

6 ALL Button Pressing ALL followed by an INPUT button, connects that input to all outputs

7 OFF Button An OFF-OUT combination disconnects that output from the inputs; an OFF-ALL

combination disconnects all the outputs

8 LOCK Button Disengages the front panel buttons

9 RCL (RECALL)

Button

Pressing the RCL button and the corresponding INPUT / OUTPUT key recalls a

setup from the non-volatile memory. The stored status blinks. Pressing a

different INPUT / OUTPUT button lets you view

another setup. After making

your choice, pressing the RCL button again implements the new status

STO (STORE) Button

Pressing STO followed by an INPUT / OUTPUT button stores the current setting

7-segment Display Displays the selected input switched to the output (marked above each input)

Table 2: Rear Panel VS-44HD 4x4 SD/HD-SDI Matrix Switcher

# Feature Function

GENLOCK BNC Connector Connect to the Genlock source

TERM Button Press to terminate the Genlock source (75) or release for looping

LOOP BNC Connector Connect to the GENLOCK connector of the next unit in the line

INPUT BNC Connectors Connect to the serial digital video sources

OUTPUT BNC Connectors Connect to the serial digital video acceptors

REMOTE Terminal Block Connector

Connect to closure contact switches

RS-232 DB 9F Port Connects to the PC or the Remote Controller

RS-485 Detachable Terminal

Block Port

Pin G is for the Ground connection

; pins B (-) and A (+) are for RS-485

SETUP Dipswitches Dipswitches for setup of the unit

ETHERNET Connector Connects to the PC or other Serial Controller via computer networking

Power Connector with Fuse AC connector enabling power supply to the unit

1 The 7-segmant display shows 1234 indicating that the operation mode is normal, and that the setups stored via the

INPUT/OUTPUT buttons have been erased

2 When in Confirm mode, the TAKE button illuminates

3 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs

4 Only view, nothing is implemented at this stage

5 For example, press STO and then the Output button # 3 to store in Setup # 3

6 Push in to terminate the input. Release when the input extends to another unit

7 Via a null-modem connection

8 The ground connection is sometimes connected to the shield of the RS-485 cable. In most applications, the ground is not

connected

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Installing on a Rack

5 Installing on a Rack

This section describes what to do before installing on a rack and how to rack

mount.

Before Installing in a Rack How to Rack Mount

Before installing in a rack, be sure that the environment is

within the recommended range:

Operating temperature range +5°to +45°C (41°to 113°F)

Operating humidity range 10 to 90% RHL, non-condensing

Storage temperature range -20°to +70°C (-4°to 158°F)

Storage humidity range 5 to 95% RHL, non-condensing



CAUTION!!

When installing on a 19" rack, avoid hazards by taking

care that:

1. It is located within the recommended environmental

conditions, as the operating ambient temperature of a

closed or multi unit rack assembly may exceed the

room ambient temperature.

2. Once rack mounted, enough air will still flow around

the machine.

3. The machine is placed straight in the correct

horizontal position.

4. You do not overload the circuit(s). When connecting

the machine to the supply circuit, overloading the

circuits might have a detrimental effect on overcurrent

protection and supply wiring. Refer to the appropriate

nameplate ratings for information. For example, for

fuse replacement, see the value printed on the

product label.

5. The machine is earthed (grounded) in a reliable way

and is connected only to an electricity socket with

grounding. Pay particular attention to situations where

electricity is supplied indirectly (when the power cord

is not plugged directly into the socket in the wall), for

example, when using an extension cable or a power

strip, and that you use only the power cord that is

supplied with the machine.

To rack-mount a machine:

1. Attach both ear brackets to the

machine. To do so, remove the

screws from each side of the

machine (3 on each side), and

replace those screws through the

ear brackets.

2. Place the ears of the machine

against the rack rails, and insert the

proper screws (not provided)

through each of the four holes in the

rack ears.

Note that:

In some models, the front panel

may feature built-in rack ears

Detachable rack ears can be

removed for desktop use

Always mount the machine in the

rack before you attach any cables

or connect the machine to the

power

If you are using a Kramer rack

adapter kit (for a machine that is not

19"), see the Rack Adapters user

manual for installation instructions

(you can download it at:

http://www.kramerelectronics.com)

Connecting Your VS-44HD

6 Connecting Your VS-44HD

This section describes how to connect the VS-44HD as a:

4x4 SD/HD SDI Matrix Switcher, see section 6.1

Dual-Link 2x2 SD/HD-SDI Matrix Switcher, see section 6.2

6.1 Connecting Your VS-44HD 4x4 SD/HD-SDI Matrix Switcher

You can use your VS-44HD to switch one of the four standard definition / high

definition SDI inputs to any or all of the four standard definition / high

definition SDI outputs, as the example in Figure 2 shows.

To connect the VS-44HD 4x4 SD/HD-SDI Matrix Switcher, do the following

1. Connect up to four SDI sources to the SDI INPUT BNC connectors (for

example, an HD/SD SDI camera to input 1 and an HD video player to input 4).

2. Connect the SDI OUTPUT BNC connectors to up to

four SDI acceptors

(for example, output 1 to a Preview monitor, and output 4 to an HD SDI

mixer).

3. Set the dipswitches (see section 6.4).

4. As an option

, connect:

A Genlock source to the GENLOCK BNC connector

The LOOP BNC connector to the GENLOCK connector of the next

unit in the line, and release the TERM button for looping

5. Connect a PC and/or controller (if required), to the:

RS-232 port (see section 6.5), and/or

RS-485 port (see section 6.6), and/or

ETHERNET connector (see section 6.9)

6. As an option

, connect a remote contact closure switch (refer to section 6.10)

7. Connect the power cord

1 Switch OFF the power on each device before connecting it to your VS-44HD. After connecting your VS-44HD, switch on

its power and then switch on the power on each device

2 When only one output is required, connect that output, and leave the other outputs unconnected

3 Not illustrated in Figure 2

4 Pushed in terminates the input. Release when the input extends to another unit

5 We recommend that you use only the power cord that is supplied with this machine

Tabla de contenidos

Otros manuales de Conmutador de matriz de Kramer

Kramer

Kramer VS-88DVI Manual de usuario

Kramer

Kramer VP-729 Manual de usuario

Kramer

Kramer 3232DS Manual de usuario

Kramer

Kramer VP-4x4K Manual de usuario

Kramer

Kramer VS-88UHD Manual de usuario

Kramer

Kramer XL 1608V4 Manual de usuario

Kramer

Kramer VS-42HDMI Manual de usuario

Kramer

Kramer XL 3216VS Manual de usuario

Kramer

Kramer VS-44HC Manual de usuario

Kramer

Kramer VP-747 Manual de usuario

Kramer

Kramer Sierra Pro XL 1204V5 Manual de usuario

Kramer

Kramer VS-402XL Manual de usuario

Kramer

Kramer VP-772T Manual de usuario

Kramer

Kramer MTX3-16-M Manual de usuario

Kramer

Kramer VSM-4x4X Manual de usuario

Kramer

Kramer VS-1616SDI Manual de usuario

Kramer

Kramer VS-3232Vxl Manual de usuario

Kramer

Kramer VP-772 Manual de usuario

Kramer

Kramer VS-626 Manual de usuario

Kramer

Kramer VS-82HDxl Manual de usuario

Kramer

Kramer Sierra Video 1208V3 Manual de usuario

Kramer

Kramer LASSEN XL 3216S Manual de usuario

Kramer

Kramer Sierra Video 3216V3 Manual de usuario

Kramer

Kramer VS-88HDCPxl Manual de usuario

Manuales populares de Conmutador de matriz de otras marcas

Broadcast Tools

Broadcast Tools SS 8.2 Manual de usuario

Altimium

Altimium MATF32 Manual de usuario

ALFAtron

ALFAtron ALF-MUK44N Manual de usuario

Monoprice

Monoprice Blackbird 15377 Manual de usuario

PTN

PTN FMX12 Manual de usuario

CYP

CYP nT15GX01 Manual de usuario

TESmart

TESmart HMA0402A40 Manual de usuario

Octava

Octava HD4XSTPMX Manual de usuario

Intelix

Intelix FLX-88 Instrucciones de funcionamiento

Roland

Roland XS-1HD Manual de usuario

Atlona

Atlona AT-HDMI-22M Manual de usuario

Link

Link HD8X8 Manual de usuario

AMX

AMX AVS-OP-2020-117 Instrucciones y recetas

Lindy

Lindy 38042 Manual de usuario

Extron electronics

Extron electronics MTPX Plus Series Manual de usuario

Key Digital

Key Digital Champion KD-16x16CS Manual de usuario

Shinybow USA

Shinybow USA SB-8811 Manual de usuario

Optimus

Optimus Compact Manual de usuario
