Kramer 1608HDS Manual de usuario

www.kramerelectronics.com 2008

LASSEN 1608HDS 16x8

LASSEN HD™ 16 SERIES ROUTING SWITCHERS

LASSEN HD 1608 SERIES SERIES

HD-

SDI AND SDI VIDEO AND STEREO AUDIO.

DESCRIPTION

The Lassen 16 series are high performance routing switchers for SDI (SMPTE 259) and HD

SDI (SMPTE 292) video signals. These units come in a compact 2U (3.5”

)

frame and can

be ordered with or without analog or digital audio. They can route any or all inputs to any

or all outputs. HD

SDI models can input SDI and HD

SDI simultaneously, but there is no

conversion between formats.

LASSEN XL ANALOG (COMPOSITE) VIDEO FEATURES

High Bandwidth

300MHz (

3dB) fully loaded.

Very Low Crosstalk

80dB @ 1MHz,

47dB @100MHz.

Qwik Adjust Knob™ Rotary Control interface

This user intuitive knob along with the 80 character LCD display provides quick and convenient setup,

adjustment and signal switching.

Video Mute Capability

Genlock Input

Looping internal sync input for vertical interval switching.

Output Disconnect Feature

LASSEN SDI VIDEO FEATURES

Maximum Data Rates

360Mbits/sec.

Standards

SMPTE 310, SMPTE 259, DVB

ASI.

Jitter

< 0.2UI.

LASSEN HD VIDEO FEATURES

Backwards compatible with SDI Signals

Maximum Data Rates

1.485Gbits/sec.

Standards

SMPTE 310, SMPTE 259, SMPTE 292, DVB

ASI.

Jitter

< 0.2UI.

ANALOG AUDIO FEATURES.

Audio Type

Balanced or un

balanced on terminal blocks.

Input (Level) Adjustment Capability (

10dB to +15dB)

Each input via RS

232, front panel, and G.R.I.P software.

Output (Volume) Adjustment Capability (Mute,

59.5dB to +15dB)

Each input via RS

232, front panel, and G.R.I.P software.

No Zipper Effect

Lassen routing switchers employ zero crossover chip technology which eliminates the annoying “zipper sound effect”associated with

digital volume controls.

Audio Mute Capability.

Crosstalk

80dB @ 1kHz & 70dB @ 20kHz.

S/N (20

20kHz)

90dB.

DIGITAL AUDIO FEATURES

Standards

Balanced AES/EBU.

Jitter

20ns.

OTHER FEATURES

Firmware Updates

Downloadable.

Control

Local front panel control with 80 character LCD readout.

232/422 plus RS

485 for optional control panels.

IP (Ethernet) control.

G.R.I.P: Windows

based routing switcher setup/diagnostic software.

Redundant Power Supplies

Optional on 32x16 & 32x32 models.

Approvals

UL & CE.

Control Panels (Optional)

Programmable, Single Bus and XY.

www.kramerelectronics.com 2008

LASSEN 1608HDS 16x8

LASSEN HD™ 16 SERIES ROUTING SWITCHERS

LASSEN HD 1608 SERIES

HD-

SDI AND SDI VIDEO AND STEREO AUDIO.

SPECIFICATIONS

ANALOG VIDEO

ANALOG AUDIO

SDI VIDEO

DIGITAL AUDIO

SDI VIDEO

INPUT IMPEDANCE

Ω

nominal

INPUT CONNECTOR TYPE

BNC

VIDEO INPUT LEVEL

300mV to 2.5V P

VIDEO BANDWIDTH

300MHz (

3dB)

CROSSTALK

80dB @ 1MHz

47dB @ 100MHz

1 INPUT TO MANY OUTPUTS

All electrical specifications remain the same

VIDEO GAIN

Unity (adjustable per channel +/

1.5dB)

MAX. INPUT AMPLITUDE

+ 24dBu

INPUT IMPEDANCE

> 20k

OUTPUT IMPEDANCE

< 50

VOLTAGE GAIN (ADJUSTMENT RANGE IF ANY)

Unity +/

0.75dB max (+

0.25 typical)

Input adjust range:

8dB to + 20dB

Output adjustment range: + 15dB to fully off (Mute)

FREQUENCY RESPONSE

20Hz to 20kHz +/

0.5dB(typical

3dB @ 120kHz) (unity gain)

S/N RATIO (20 TO 20KHZ)

96dB (20

20kHz unweighted

unity gain)

CROSSTALK (ALL INPUTS HOSTILE)

80dB @ 1kHz (unity gain)

60dB @ 10kHz (unity gain)

IM & THD (20 TO 20KHZ)

THD: < 0.025% (20Hz

20kHz @ + 4dBu) (unity gain)

IM: < 0.025 SMPTE

DIN @ + 4dBu (unity gain)

< 0.01% CCIF @ + 16dBu (unity gain)

MAX OUTPUT AMPLITUDE

+ 24dBu balanced

+ 18dBu unbalanced

AUDIO CONNECTORS

5 pin per stereo input or output

Every IO can be connected to be either balanced or unbalanced

DATA RATES

up to 360 Mbps/sec

DATA TYPES

SMTE 310, SMPTE 259, DVB

ASI

INPUT CABLE EQUALIZATION RANGE

200 meters

INPUT RETURN LOSS

> 15dB

OUTPUT LEVEL

750

850mVp

OUTPUT JITTER

< 0.2 UI

OUTPUT RETURN LOSS

> 15dB

SIGNAL CONNECTORS

BNC

DATA RATES

AES3: Balanced; AES3ID: Unbalanced

CONNECTOR

AES3: XLR/phoenix ; AES3ID: BNC

INPUT/OUTPUT IMPEDANCE

AES3: 110

; AES3ID: 75

OUTPUT LEVEL

AES3: 2

7Vp

p; AES3ID: 10Vp

CABLE

AES3: STP; AES3ID: Coax

MAX. DISTANCE

AES3: 100m; AES3ID: 1000m

MIN. INPUT

AES3: 2Vp

p; AES3ID: 32Vp

EQUALIZATION

AES3: Optional; AES3ID: Optional

JITTER

AES3: +/

20ns; AES3ID: +/

20ns

BANDWIDTH

AES3: 1MHz

6MHz; AES3ID: 1MHz

6MHz

DATA RATES

up to 1.485 Gbits/sec

DATA TYPES

SMTE 310, SMPTE 259, SMPTE 292, DVB

ASI

INPUT CABLE EQUALIZATION RANGE

100 meters for SMPTE 292

200 meters for all other stds.

INPUT RETURN LOSS

> 15dB up to 1.5GHz

OUTPUT LEVEL

750

850mVp

OUTPUT JITTER

< 0.2 UI

OUTPUT RETURN LOSS

> 15dBup to 1.5GHz

SIGNAL CONNECTORS

BNC
