32 QHD IPS 165HZ FREESYNC

HDR GAMING MONITOR

(2560 x 1440)

KAMN32RT1SA

•Read all instructions before using this monitor, and retain this user guide for future

reference.

•Unplug the monitor before cleaning it.

•Use a clean, slightly dampened cloth to wipe the main monitor body.

•To clean the screen, turn it off unplug it and wait for it to cool completely, then wipe

it with a dry micro-fibre cloth.

•Do not use cleaning alcohol, ammonia-based liquids or other harsh cleaners.

•This monitor is designed with ventilation holes on the back of the casing. Do not

cover or block them.

•Do not insert any object or spray any liquid into the vents.

•Avoid placing the monitor near heaters, stoves, fireplaces or other sources of heat,

as well as in rooms lacking adequate ventilation.

•Do not position the monitor in unsafe locations. If the monitor falls, it may be

damaged and may injure nearby people.

•Unplug the monitor if it is not going to be used for an extended period.

•Do not place heavy objects on the monitor, its power cord or any connected cable.

•Do not open the back panel of the monitor, as it contains a high-voltage current

even when not plugged in.

The terms HDMI and HDMI High-Definition Multimedia Interface and

the HDMI Logos are trademarks or registered trademarks of HDMI

Licensing Administrator, Inc. in the United States and other countries.

SAFETY & WARNINGS

Monitor

Stand connector Stand base

Stand base screw

(M6 x 16mm) (x1) VESA screws (x4)

DisplayPort cable Power cable User guide

COMPONENTS

1

Power/OK button

5

DP port 1

2

Direction keys

6

DP port 2

3

USB

7

Audio out

4

HDMI port

8

Power connector

OVERVIEW

1. Carefully remove the monitor, stand

connector and stand base from the box.

2. Attach the stand base to the stand

connector using the M6 screw provided.

3. Insert the connection block into the back

cabinet and push down until ﬁrmly

connected.

4. Lift monitor up straight and remove the

bottom foam. Stand the monitor up on the

installed base.

STAND ASSEMBLY

WARNING: The panel of the monitor is fragile. Keep the foam

underneath the monitor screen while assembling the stand.

1. Open the box, remove the monitor with the protection foam attached and gently place

it on a desktop or table.

2. Remove the foam covering the back of the monitor and all additional components from

the packaging. Press the release button to remove the stand plate. If the monitor was

already attached to the stand, remove the stand.

3. Follow the Mount Assembly Instructions as provided with the mount.

VESA mounting pattern is 100 x 100mm, screw size M4.

Note: VESA mount or mounting accessories are NOT included.

Stand base Monitor

Stand connector

Stand plate

Button

Mount

(not included)

Foam

VESA MOUNT

Power cable

Connect the included power cable to the monitor power port, then connect the other end to

a power outlet.

Earphones (Audio Out)

Connect an audio cable to the 3.5mm audio port on the monitor (Audio In) and the 3.5mm

audio port on your computer.

Note: The monitor may need to be set as the PC’s default sound output device.

CONNECTIVITY

DisplayPort

In order for the monitor to receive DisplayPort signals from the computer, use the DisplayPort

cable to connect the monitor to the computer.

HDMI

In order for the monitor to receive HDMI signals from the computer, use the HDMI cable to

connect the monitor to the computer.

USB

In order to update the software, use a USB cable to connect the monitor to the computer.
