Installation & Operation Guide

KMD-5831

Programmable Loop Controller PLC-28 Direct Digital Controller

902-019-04B

(Shown with optional Override Board Cover)

Introduction

This section provides a brief overview of the KMD-5831 Programmable Loop

Controller PLC-28 and the KMD-5821 Programmable Loop Controller PLC-16 +

Direct Digital Controllers. Review this material before you attempt to install the

controller.

For clarity we will focus on the KMD-5831 but all installation and operating

instructions apply equally to the KMD-5821.

Illustration 1 shows the major controller components and their locations. The

KMD-5821has fewer inputs and outputs.

Note:

Additional components are located under the blank cover. We will cover these in

detail later in this document.

Illustration 1. Controller Components

Input Terminal

Blocks

Input Pull-Up

Switches

RS–485

Connector

Isolation

Lamps

RJ–12

Connector

Output Terminal

Blocks

Grounds

Status LEDs

Blank

Cover

Override

Board

Cover

AC Power

Input

Installation

This section provides important instructions and guidelines for installing the

KMD-5831 Programmable Loop Controller PLC-28 Direct Digital Controller.

Carefully review this information prior to attempting installation.

Mounting

Use the four mounting holes to securely mount the controller using #6 hardware

inside a UL-approved Enclosed Energy Management Equipment Panel or other

suitable protective enclosure. Refer to Illustration 2.

Input Connections

Universal Inputs

Wiring connections are made depending on the intended application. Sixteen

Universal Inputs are provided on the controller. Observe the following guide-

lines. (Refer to Illustration 2.)

◆Connect device inputs to the input terminal connections (+).

◆Connect input grounds to the associated ground terminal (-).

Illustration 2. Connector Detail

6.00"

◆If input pull-ups are required, refer to “Configuration” later in this section.

◆Wiring terminals are suitable for up to two 12–22 AWG wires. If more than

two wires are required, use an external terminal strip for additional connec-

tions.

Note:

Pulse inputs may be used under the following conditions:

◆If the pulse input does not use a voltage variation, then leave the input pull-up

in the “On” position.

◆If the pulse produces voltage peaks (up to +5 VDC max.), then the input pull-

up must be set to the “Off” position.

◆The maximum pulse rate is 8 HZ (8 pulse/sec).

Connecting Outputs

Twelve Universal Outputs are available for output connections labeled as 1–12 on

the output terminal blocks. The outputs are grouped into three groups of four

outputs each with a shared grounds (labeled “SC”) in each block.. Each output

can produce 50 mA at +12 VDC. If a greater current is required, KMC recom-

mends the use of Override Boards discussed later in this section.

A separate ground block provides six additional ground connections.

Network Connections

The controller provides connections for two types of RS–485 circuits.

RJ-12

The RJ–12 connector provides a six-wire RS-485 connection to a modem or PC

using the KMD-5559 CommTalk Data Exchange Module. Simply connect a

suitable RJ-12 cable between the devices.

RS-485 Inputs

A RS–485 terminal is available for connections to a network of controllers If the

Controller is at the End-of-Line, refer to “Configuration” after connections are

completed.

Detail

The End-of-Line connection will have only one wire attached to the A and B

terminals.

◆For reliable operation, use Belden cable model #82760 or equivalent (18 gauge,

twisted, shielded, 50 picofarads or less) for all network terminal block connec-

tions.

◆Connect the nodes of the network in a daisy-chain arrangement. This means:

Connect the Aterminal in parallel with all other Aterminals.

Connect the Bterminal in parallel with all other Bterminals.

◆Connect the shields of the cable together at each controller.

Installation KMD-5831 PLC-28 Direct Digital Controller Installation & Operation Guide

◆Connect the shields to an earth ground (DO NOT use a chassis ground) only at

one end of the segment; tape back the shield ground at the other end.

Wiring Notes

Use approved shielded cable and the following principles when connecting a

controller to a network:

◆Connect no more than 124 Tier 2 KMC addressable controllers or devices to

the RS-485 network.

◆Connect the nodes of the network in a daisy-chain arrangement. This means:

Connect the Aterminal in parallel with all other Aterminals.

Connect the Bterminal in parallel with all other Bterminals.

◆Connect the shields of the cable together at each controller.

◆Connect the shields to an earth ground at only one end of the segment; tape

back the shield ground at the other end.

◆Use a KMD–5575 repeater between every 32 Tier 2 controllers or if the cable

length of the Tier 2 network exceeds 4000 feet (1220 meters). Use no more

than seven repeaters per network.

◆Place a KMD–5567 surge suppressor in the cable where it exits a building.

Refer to Illustration 3 for an example of typical RS-485 connections.

KMD-5831 PLC-28 Direct Digital Controller Installation & Operation Guide Installation

Illustration 3. Typical RS-485 Wiring Configuration

KMC Controlle

Connections

Wiring

Shield

Wiring

Shield

Wiring

Shield

Override Cards

For large relays or devices that cannot be powered directly from a standard

output, you will need to install an output override card. Override cards provide:

◆a wide choice of output signals.

◆a slide switch for automatic or manual control.

◆an LED for assessment of the output state.

The following Override Cards are available from KMC Controls.

Note

Output cards must be powered with 24 VAC to enable the manual override

(HAND) function. However, this connection must not be made until the default

analog output jumper is removed.

Installing Override Boards

To install an Override Board:

1. Remove the appropriate cover from the module. The upper cover is for out-

puts 1–8 the lower for outputs 9–12.

2. Remove the jumper from the mounting header.

3. Press the override board onto the header pins. The “Hand-Off-Auto” selection

switch is always positioned toward the output connections. (Refer to Illustra-

tion 4.)

4. If required, set the selection switch on the Override Board.

Installation KMD-5831 PLC-28 Direct Digital Controller Installation & Operation Guide

rebmuNledoM epyTtuptuO

1076-OPH pmA1fosegatlovCAgnihctiwsrofdesu-yaleRcairT

.sselro

2076-OPH gniriuqersnoitacilpparofdesU-edirrevOgolanA

.ecivedlortnocgolananafotnemtsujdalaunam

3076-OPH

sdaolhctiwsotdesu-)AmroF(yaleRlacinahceM.O.N

anehwrostiucricCDgnihctiwsnehw,spmA2otpufo

FFOebtsumecivedehtdnaderiuqersitcatnocyrd

.devomersirewopnehw

4076-OPH launamgniriuqersnoitacilpparofdesu-Am02-4

.ecivedlortnocgolananafotnemtsujda

5076-OPH

sdaolhctiwsotdesu-)AmroF(yaleRlacinahceM.C.N

anehwrostiucricCDgnihctiwsnehw,spmA2otpufo

nehwNOebtsumecivedehtdnaderiuqersitcatnocyrd

.devomersirewop

Table 1. KMD-5831 Override Board Options

Caution

DO NOT connect active 24 VAC circuits to the output block unless the associ-

ated jumper is removed first. Doing so will result in damage to the output and

prevent it from working.

If the associated output will be an analog output, leave the jumper in place.

5. Connect output devices to the module.

6. Connect required power to the input module.

Illustration 4 gives an example of a typical output module configuration.

Using Separate Banks

The outputs are grouped into three banks that share a common switched-termi-

nal. This connection is marked as “SC” on the output block. If you connect a

circuit to this connector it then becomes common to all outputs in that bank.

Configuration

Configuration settings may be required for the inputs or the RS-485 connection.

If you must activate or deactivate pull-ups on the inputs or set the end-of-line

termination for the RS-485 connection, refer to Illustration 1 to locate the input

switches and Illustration 6 for the End-of-Line switches.

Remove jumper

before installing

board

Remove jumper

prior to connecting

active 24 VAC circuits

to the associated

output terminals

Selection Switch

LED

Illustration 4. Override Board Instalaltion

KMD-5831 PLC-28 Direct Digital Controller Installation & Operation Guide Installation

Input Pull-ups

A 10K ohm resistor is available as a pull-up to a +5 VDC source voltage for

passive or ‘dry” inputs on each input circuit. The resistor is switched “On” or

“Off” using the two dip-switches at the top of the controller. The top switch is

associated with the first 8 inputs and the lower switch is associated with the last 8

inputs. Illustration 5 shows on of these switches in greater detail.

The default setting for each input is the “On” position. In this position, the

controller will provide +5 VDC to the input device.

If the input is an active input, that is it has it’s own current source, the pull-up for

that input must be switched to the “Off” position.

End-of-Line Switches

Illustration 6 shows the position of the End-of-Line switches associated with the

RS–485 terminal. You must remove the lower blank cover to gain access to these

switches

Illustration 5. Typical Input Pull-Up Switch (1 of 2)

OFF ON

Illustration 6. RS–485 End-of-Line Switches

Installation KMD-5831 PLC-28 Direct Digital Controller Installation & Operation Guide

End-of-Line Switches

Illustration 7 shows the switch in greater detail

If the controller is located at the end of the network segment the switches must

both be placed in the default “ON” position. Otherwise, place the switches in the

“OFF” position.

Power Connection

Connect the 24 VAC supply voltage to the power connectors above the RJ–11

connector on the output side of the controller. Power is applied to the controller

when the power supply (or transformer) is plugged in, as long as the Power

jumper is in place. Illustration 6 shows a typical connection diagram for the

controller.

Note:

The following guidelines apply.

◆In general, use a separate Class 2 24 VAC transformer with the smallest VA

rating that matches the specification.

◆If several controllers are mounted in the same cabinet, you can share a trans-

former between them PROVIDED the transformer does not exceed 100 VA

Configuration

Prior to operating the controller, it must be configured using the Hardware

Configuration Manager (HCM) application supplied with WinControl. Refer to

the WinControl XL User’s Manual for additional information.

Note:

All controllers on the same network must be configured for the same baud rate.

Programming

Refer to the KMC Digital Applications Manual for information on how to pro-

gram the controller.

OFF

Illustration 7. RS-485 End-of-Line Switch Detail

KMD-5831 PLC-28 Direct Digital Controller Installation & Operation Guide Installation

Operation

Once configured, programmed and powered up, the controller requires very

little user intervention.

Controls and Indicators

The following sections describe the controls and indicators found on the card.

Alternately, you may remove the RS-485 terminal block from the card to isolate

the card from the network without disrupting network communications to other

controllers.

Status LEDs

Two Status LEDs are located on the bottom left side of the controller. They are

used to indicate the following:

Communications – This yellow LED flashes whenever the controller is commu-

nicating with other controllers over the RS-485 network connection.

Ready– This green LED indicates the controller has power and is operating

normally. The LED will flash on and off at one second intervals.

Isolation Lamps

Two Isolation Lamps are located below the RJ–12 connector on the right side of

the controller. These lamps serve three functions:

◆Removing the lamps will open the RS-485 circuit and isolate the controller

from the network.

◆If one, or both, lamps are lit, it indicates the network is improperly phased.

This means that the ground potential of the controller is not the same as other

controllers on the network

◆If the voltage or current on the network exceeds safe levels, the lamps operate

as fuses to protect the controller from damage.

Power Jumper

The power jumper, shown in Illustration 8, can be used to remove power from

the controller. This should be done anytime connections are made or changed on

the controller. Removing the jumper opens the 24 VAC supply circuit.

Resetting the Controller

If the controller appears to be operating incorrectly, or is not responding to

commands, you may need to reset the controller.

Tabla de contenidos

Otros manuales de Controladores de KMC Controls

KMC Controls

KMC Controls SimplyVAV BAC-8001 Guía del usuario

KMC Controls

KMC Controls AppStat Manual de usuario

KMC Controls

KMC Controls MEP-5062 Manual de usuario

KMC Controls

KMC Controls BAC-9300 Series Manual de usuario

KMC Controls

KMC Controls MEP-4 Series Guía del usuario

KMC Controls

KMC Controls CSC 3000 Series Guía del usuario

KMC Controls

KMC Controls BAC-7401 Instrucciones de funcionamiento

KMC Controls

KMC Controls BAC-7003 Manual de usuario

KMC Controls

KMC Controls MEP-3001 Instrucciones de funcionamiento

KMC Controls

KMC Controls FlexStat BAC-120063CW-ZEC Manual del operador

KMC Controls

KMC Controls FlexStat BAC-12 63 Series Manual de usuario

KMC Controls

KMC Controls MEP-4201 Manual de usuario

KMC Controls

KMC Controls BAC-7001 Manual de usuario

KMC Controls

KMC Controls CSC-3501 Manual de usuario

KMC Controls

KMC Controls KMD-5205 Instrucciones de funcionamiento

KMC Controls

KMC Controls MCP-1040 Series Manual de usuario

KMC Controls

KMC Controls KMD-7001 Instrucciones de funcionamiento originales

KMC Controls

KMC Controls CSC 3000 Series Guía del usuario

KMC Controls

KMC Controls KMDigital KMD-5290E Instrucciones de funcionamiento

KMC Controls

KMC Controls CEE-3009 Manual de usuario

KMC Controls

KMC Controls SimplyVAV BAC-8205 Manual de usuario

KMC Controls

KMC Controls CTE-3017 Manual de usuario

KMC Controls

KMC Controls MCP-1060 Series Manual de usuario

KMC Controls

KMC Controls MEP-46 Q Series Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
