Keysight Technologies

E4980A Precision LCR Meter

20 Hz to 2 MHz

E4980AL Precision LCR Meter

20 Hz to 300 kHz/500 kHz/1 MHz

Configuration Guide

www.keysight.com/find/LCRmeters

E4980A Ordering Guide

The following steps will guide you through configuring your E4980A.

Standard Furnished Item

Description Additional Information

CD-ROM Contains User’s Guide (in PDF) and Sample Program. See documentation option for printed manuals.

CD-ROM Contains Keysight IO Libraries Suite (the latest versions).

USB Cable USB (Type A) to USB (Type Mini-B) cable

Power Cable

Certificate of Calibration

Note: Test Fixture and printed copy of User’s Guide are not furnished. See Documentation Option and Available Accessories for the selection of these items.

Step 1. Choose Hardware Option (Mandatory)

Description Option No. Additional Information

Handler Interface E4980A-201 Adds handler interface

Scanner Interface E4980A-301 Adds scanner interface

No Interface E4980A-710 Attaches blank panel to the expansion slots

E4980A/E4980AL Configuration Guide Introduction

This guide helps you to define the options and accessories for the E4980A and E4980AL precision LCR meters.

The E4980A is the model number of the 20 Hz to 2 MHz frequency range LCR meter. The E4980AL is the model number of 20 Hz to

either 300 kHz, 500 kHz or 1 MHz frequency range LCR meter. The E4980AL is a distributor preferred product.

For configuring options, see this page for the E4980A, and page 8 for the E4980AL.

Notes:

Up to 2 interfaces can be installed in the expansion slots on the rear panel. When no interface is added, two of the E4980A-710 are installed. When one

interface is added, that interface and the E4980A-710 are installed.

Refer to Hardware Upgrade for retrofit information on the above options.

02 | Keysight | E4980A/E4980AL Precision LCR Meters - Configuration Guide

www.keysight.com/find/LCRmeters

Step 2. Choose Software Option (If not required, go to Step 3)

Description Option No. Additional Information

Power and DC Bias

Enhancement

E4980A-001 Increases test signal level range to 20 V/100 mA rms max. Adds internal DC bias function controllable

from 0 ± 40 V/± 100 mA dc, 2nd DC source, and Rdc/Vdc/Idc measurement functions.

DCR Measurement E4980A-200 Adds a DC resistance measurement. (mandatory option)

Note: Refer to Software Upgrade for retrofit information on the above options.

Step 3. Choose General/Miscellaneous Accessory Option (If not required, go to Step 4)

Description Option No.

Rackmount Kit E4980A-1CM

Note: Front Handle Kit and Handle/Rack Mount Kit are not available.

Step 4. Choose Documentation Option (If not required, go to Step 5)

Description Option No. Additional Information

U.S. - English Localization E4980A-ABA Printed manuals are not furnished. Order documentation option if required.

Japan - Japanese Localization E4980A-ABJ

Step 5. Choose Calibration Certificate Option

Description Option No. Additional Information

ISO 17025 Compliant Calibration E4980A-1A7 ISO 17025 compliant calibration

ANSI Z540 Compliant Calibration E4980A-A6J ANSI Z540 compliant calibration

E4980A Ordering Guide (continued)

03 | Keysight | E4980A/E4980AL Precision LCR Meters - Configuration Guide

www.keysight.com/find/LCRmeters

Hardware Upgrade

Option No. Description

Upgrade

Model No. or

Equivalent Part

Number

Customer

Installable

Requires

(Instrument

must already

include the

following)

Not

Compatible Additional Information

E4980A-201 Handler Interface E4980AU-201 No None None Installable at service center only

E4980A-301 Scanner Interface E4980AU-301 No None None Installable at service center only

E4980A-1CM Rackmount Kit 5063-9241 Yes None None

Note: For details of the upgrade information, refer to product homepage on the Keysight home website.

Software Upgrade

Option No. Description

Upgrade

Model No. or

Equivalent Part

Number

Customer

Installable

Requires

(Instrument

must already

include the

following)

Not

Compatible Additional Information

E4980A-001 Power and DC Bias

Enhancement

E4980AU-001 No None 002 1,4 Installable at service center only

E4980A-007 4Standard Model E4980AU-007 No E4980A-005 4None Installable at service center only

E4980A-200 DCR Measurement E4980AU-200 No None E4980A-001 2Installable at service center only

1. The E4980A-001 and E4980A-002 can be installed in the same unit but cannot be operated simultaneously.

2. The DCR (Rdc) measurement becomes available with either E4980A-200 or E4980A-001. It is unnecessary to upgrade if the unit has the E4980A-001.

3. Note: For firmware update and upgrade information, refer to product homepage on the Keysight home website.

4. E4980A-002, E4980A-005 and E4980A-007 are not available with new purchase.

Application Software

Option No. Description Supported Fixtures Additional Information

N1500A-006 Parallel Plate/

Inductance Method

Up to 120 MHz

16451B

16452A

Operation frequency is up to 2 MHz with E4980A.

Can run on an external PC.

Transportable with dongle key.

04 | Keysight | E4980A/E4980AL Precision LCR Meters - Configuration Guide

www.keysight.com/find/LCRmeters

Description Model Number Additional Information

SMD Test Fixture 16034E For SMD; (0.1 to 8)L x (0.5 to 10)W x (0.5 to 10)H mm.

Operation and Service Manual is furnished.

SMD Test Fixture 16034G For SMD; (0.1 to 5)L x (0.3 to 1.6)W x (0.3 to 1.6)H mm. 100 ΩSMD resistors set is furnished.

16034G-ABA U.S. – English localization 1

16034G-ABJ Japan – Japanese localization 1

SMD Test Fixture 16034H For Array-type SMD; (0.1 to 5)L x (≤ 15)W x (0.6 to 3)H mm. 100 ΩSMD resistors set and Operation

Manual are furnished.

Test Fixture 16047A For axial or radial lead device. Operation and Service Manual is furnished.

16047A-701 Adds Shorting plate

Test Fixture 16047E For axial or radial lead device

16047E-ABA U.S. - English localization 1

16047E-ABJ Japan – Japanese localization 1

Test Leads 16048A BNC connector leads; 0.94 m. BNC connector bracket and Operation and Service Manual are furnished.

Test Leads 16048D BNC connector leads; 1.89 m. BNC connector bracket and Operation and Service Manual are furnished.

Test Leads 16048E BNC connector leads; 3.8 m. BNC connector bracket and Operation and Service Manual are furnished.

Available Accessories – General Measurement Accessories

Tweezers Test Fixture 16334A For SMD; ≤ 10 mm L. Tweezers type; cable length 1 m.

Shorting block and Operation and Service Manual are furnished.

Kelvin Clip Leads 16089A 2 large clips. 5 Hz - 100 kHz. Choose mandatory option 16089A-800 or C20.

Operation and Service Manual is furnished.

16089A-800 Cable length: 1 m (standard)

16089A-C20 Cable length: 2 m

Kelvin Clip Leads 16089B 2 medium clips. 5 Hz - 100 kHz. Choose mandatory option 16089B-800 or C20.

Operation and Service Manual is furnished.

16089B-800 Cable length: 1 m (standard)

16089B-C20 Cable length: 2 m

Kelvin IC Clip Leads 16089C 2 IC clips. 5 Hz - 100 kHz. Cable length 1 m. Operation and Service Manual is furnished.

External Voltage Bias

Fixture

16065A ± 200 V dc max., for axial or radial lead device.

Shorting plate and Operation and Service Manual are furnished.

Dielectric Test Fixture 16451B Test fixture for measuring permittivity of dry solid sheet material; Cable length 1 m.

38 mm and 5 mm diameter electrodes for measuring bare material and two types of electrodes for

measuring material with pre-formed electrodes are furnished.

16451B-ABA U.S. – English localization 1

16451B-ABJ Japan – Japanese localization 1

Liquid Test Fixture 16452A Test fixture for measuring permittivity of liquid material. Required volume of material; 3.4, 3.8, 4.8 or

6.8 ml. Temperature range: –20 ° to +125 °C. Shorting plate, spacers, SMA-BNC adapters, fixture stand,

carrying case and Operation and Service Manual are furnished.

(16048A or 16452-61601 Test Leads recommended)

Test Leads 16048G, BNC

(m-m) adapter × 4

(p/n 1250-0216 × 4)

Heat-proof test leads for use with the 16452A. Temperature range: –20 ° to +150 °C

1. Language selection of Operation and Service Manual.

Note: For more detailed information, refer to Accessories Selection Guide for Impedance Measurements.

05 | Keysight | E4980A/E4980AL Precision LCR Meters - Configuration Guide

www.keysight.com/find/LCRmeters

Description Model Number Additional Information

Open Termination 42090A 4-terminal pair Open termination. Needed for performing calibration.

Short Termination 42091A 4-terminal pair Short termination. Needed for performing calibration.

4-Terminal Pair Standard

Capacitor Set

16380A 1 pF, 10 pF, 100 pF and 1000 pF standard capacitor set with carrying case. Calibration report and

Operation Note are furnished.

4-Terminal Pair Standard

Capacitor Set

16380C 0.01 μF, 0.1 μF and 1 μF standard capacitor set with carrying case. Calibration report and

Operation Note are furnished.

16380C-001 Adds 10 μF standard capacitor

4-Terminal Pair Standard

Resistor Set

42030A 9 standard resistors from 1 mΩto 100 kΩin decade steps; Carrying case, calibration report and

Operation and Service Manual are furnished.

Note: For more detailed information, refer to Accessories Selection Guide for Impedance Measurements.

Available Accessories – for Calibration and Maintenance

06 | Keysight | E4980A/E4980AL Precision LCR Meters - Configuration Guide

www.keysight.com/find/LCRmeters

E4980AL Ordering Guide

The following steps will guide you through configuring your E4980AL.

Standard Furnished Item

Description Additional Information

CD-ROM Contains User’s Guide (in PDF) and Sample Program. See documentation option for printed manuals.

CD-ROM Contains Keysight IO Libraries Suite (the latest versions).

USB Cable USB (Type A) to USB (Type Mini-B) cable

Power Cable

Calibration of Certification

Step 1. Choose Hardware Option (One of the frequency options is mandatory.)

Description Option No. Additional Information

20 Hz to 300 kHz E4980AL-032

20 Hz to 500 kHz E4980AL-052

20 Hz to 1 MHz E4980AL-102

Handler Interface E4980A L-201 Adds handler interface

Scanner Interface E4980AL-301 Adds scanner interface

No Interface E4980A L-710 Attaches a blank panel

Note: There are two interface slots on the rear panel. When neither the E4980AL-201 nor the E4980AL-301 is selected, two of the E4980AL-710 are selected.

When either of them is selected, an E4980AL-710 is selected.

Step 2. Choose General/Miscellaneous Accessory Option (If not required, go to Step 4)

Description Option No.

Rackmount Kit E4980A L-1CM

Note: Front Handle Kit and Handle/Rack Mount Kit are not available.

Step 3. Choose Documentation Option

Description Option No. Additional Information

U.S. - English Localization E4980AL-ABA Printed manuals are not furnished. Order documentation option if required.

Japan - Japanese Localization E4980AL-ABJ

Step 4. Choose Calibration Certificate Option

Description Option No. Additional Information

ISO 17025 Compliant Calibration E4980AL-1A7 ISO 17025 compliant calibration

ANSI Z540 Compliant Calibration E4980AL-A6J ANSI Z540 compliant calibration

07 | Keysight | E4980A/E4980AL Precision LCR Meters - Configuration Guide

www.keysight.com/find/LCRmeters

Hardware Upgrades

When the model number on the front panel is labeled E4980AL:

Upgrade Model No. or

Equivalent Part Number

Description Option number to add2Customer

Installable

Additional Information

E4980ALU-113 Upgrade kit, 500 kHz to 1MHz for

E4980AL-052

E4980AL-102 No

Installable at service center only

E4980ALU-112 Upgrade kit, 300 kHz to 1MHz for

E4980AL-032

E4980AL-102 No

E4980ALU-052 Upgrade kit, 300 kHz to 500 kHz

for E4980AL-032

E4980AL-052 No

E4980ALU-211 Upgrade kit, Handler Interface E49 8 0AL-201 No

E4980ALU-311 Upgrade kit, Scanner Interface E4980AL-301 No

1CM019A Rack mount kit E4980A L-1CM Yes

When the model number on the front panel is labeled E4980A 1:

Upgrade Model No. or

Equivalent Part Number

Description Option number to add2Customer Additional Information

E4980ALU-111 Upgrade kit, 500 kHz to 1 MHz for

E4980A-050

E4980A-100 No

Installable at service center only

E4980ALU-110 Upgrade kit, 300 kHz to 1 MHz for

E4980A-030

E4980A-100 No

E4980ALU-050 Upgrade kit, 300 kHz to 500 kHz

for E4980A-030

E4980A-050 No

E4980ALU-201 Upgrade kit,

Handler Interface

E4980A-201 No

E4980ALU-301 Upgrade kit,

Scanner Interface

E4980A-301 No

5063-9241 Rackmount kit 5063-9241 Yes

For details of the upgrade information, refer to product homepage on the Keysight home website.

1. The unit is ordered as the E4980AL before November 2014.

2. E4980A/AL option number.

08 | Keysight | E4980A/E4980AL Precision LCR Meters - Configuration Guide

www.keysight.com/find/LCRmeters

Software Upgrades

Not available

Application Software

Option No. Description Supported Fixtures Additional Information

N1500A-006 Parallel Plate/

Inductance Method

Up to 120 MHz

16451B

16452A

Operation frequency is up to the frequency limit of the E4980AL.

Can run on an external PC.

Transportable with dongle key.

Accessory

See Available Accessories - General Measurement Accessories on Page 5. These accessories are common to both E4980A and E4980AL.

Description Model Number Requires (Instrument must already

include the following)

Additional Information

40Vdc External Voltage Bias Adapter 16065C

Note: This is an additional accessory for the E4980AL.

For detailed information, refer to the Accessories Selection Guide for Impedance Measurements.

Literature Resouce

Title Publication Number Additional Information

E4980A/E4980AL Data Sheet 5989-4435EN

E4980A Brochure 5989-4235EN

E4980AL Brochure 5991-2305EN

E4980A Technical Overview:

Migrating from a Keysight 4279A to n Keysight E4980A Precision LCR Meter

5989-4433EN

E4980A Technical Overview:

Migrating from a Keysight 4284A to a Keysight E4980A Precision LCR Meter

5989-4434EN

LCR Meters, Impedance Analyzers and Test Fixtures Selection Guide 5952-1430E

Accessories Selection Guide For Impedance Measurements 5965-4792E

Impedance Measurement Handbook 5950-3000

Note: More literature is available on the Keysight home website.

Web Resource

Have access to the following websites to acquire the latest news, product and support information, application literature and more.

http://www.keysight.com/find/impedance

http://www.keysight.com/find/e4980a

http://www.keysight.com/find/e4980al

09 | Keysight | E4980A/E4980AL Precision LCR Meters - Configuration Guide

For more information on Keysight

Technologies’ products, applications or

services, please contact your local Keysight

office. The complete list is available at:

www.keysight.com/find/contactus

Americas

Canada (877) 894 4414

Brazil 55 11 3351 7010

Mexico 001 800 254 2440

United States (800) 829 4444

Asia Pacific

Australia 1 800 629 485

China 800 810 0189

Hong Kong 800 938 693

India 1 800 11 2626

Japan 0120 (421) 345

Korea 080 769 0800

Malaysia 1 800 888 848

Singapore 1 800 375 8100

Taiwan 0800 047 866

Other AP Countries (65) 6375 8100

Europe & Middle East

Austria 0800 001122

Belgium 0800 58580

Finland 0800 523252

France 0805 980333

Germany 0800 6270999

Ireland 1800 832700

Israel 1 809 343051

Italy 800 599100

Luxembourg +32 800 58580

Netherlands 0800 0233200

Russia 8800 5009286

Spain 800 000154

Sweden 0200 882255

Switzerland 0800 805353

Opt. 1 (DE)

Opt. 2 (FR)

Opt. 3 (IT)

United Kingdom 0800 0260637

For other unlisted countries:

www.keysight.com/find/contactus

(BP-9-7-17)

DEKRA Certified

ISO9001 Quality Management System

www.keysight.com/go/quality

Keysight Technologies, Inc.

DEKRA Certified ISO 9001:2015

Quality Management System

Evolving Since 1939

Our unique combination of hardware, software, services, and people can help you

reach your next breakthrough. We are unlocking the future of technology.

From Hewlett-Packard to Agilent to Keysight.

myKeysight

www.keysight.com/find/mykeysight

A personalized view into the information most relevant to you.

http://www.keysight.com/find/emt_product_registration

find warranty information.

Keysight Services

www.keysight.com/find/service

Keysight Services can help from acquisition to renewal across your

instrument’s lifecycle. Our comprehensive service offerings—one-

stop calibration, repair, asset management, technology refresh,

consulting, training and more—helps you improve product quality

and lower costs.

Keysight Assurance Plans

www.keysight.com/find/AssurancePlans

Up to ten years of protection and no budgetary surprises to ensure

your instruments are operating to specification, so you can rely on

accurate measurements.

Keysight Channel Partners

www.keysight.com/find/channelpartners

Get the best of both worlds: Keysight’s measurement expertise and

product breadth, combined with channel partner convenience.

10 | Keysight | E4980A/E4980AL Precision LCR Meters - Configuration Guide

This information is subject to change without notice.

Published in USA, February 14, 2018

5989-8321EN

www.keysight.com

Otros manuales para E4980A

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Instrumento de medición de Keysight Technologies

Keysight Technologies

Keysight Technologies M9393A Manual de usuario

Keysight Technologies

Keysight Technologies E5061B Manual de usuario

Keysight Technologies

Keysight Technologies PNA Series Manual de usuario

Keysight Technologies

Keysight Technologies FieldFox A Series Manual de usuario

Keysight Technologies

Keysight Technologies M8131A Manual de usuario

Keysight Technologies

Keysight Technologies N9030B Manual de instalación y operación

Keysight Technologies

Keysight Technologies M9602A Manual de usuario

Keysight Technologies

Keysight Technologies E4990A Manual de usuario

Keysight Technologies

Keysight Technologies U1401B Manual de usuario

Keysight Technologies

Keysight Technologies N524 A Series Manual de instalación y operación

Keysight Technologies

Keysight Technologies N9000A Manual de usuario

Keysight Technologies

Keysight Technologies Agilent Technologies PXI Express M9202A Guía del usuario

Keysight Technologies

Keysight Technologies N9040B Manual de instalación y operación

Keysight Technologies

Keysight Technologies N774 C Series Manual de usuario

Keysight Technologies

Keysight Technologies M981 AS Series Manual de usuario

Keysight Technologies

Keysight Technologies N4374B Manual de usuario

Keysight Technologies

Keysight Technologies E5061B ENA Series Manual de usuario

Keysight Technologies

Keysight Technologies MXA Series Manual de instalación y operación

Keysight Technologies

Keysight Technologies MXA N9020A Manual de instalación y operación

Keysight Technologies

Keysight Technologies N9010B Manual de instalación y operación

Keysight Technologies

Keysight Technologies N1060A Manual de usuario

Keysight Technologies

Keysight Technologies E5260 Series Manual de usuario

Keysight Technologies

Keysight Technologies N9340B Manual de usuario

Keysight Technologies

Keysight Technologies FieldFox B Series Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
