Interlogix UVD-XP4DNR(-P) Manual de usuario
P/N 1079204B-EN • REV 1.0 • ISS 15JUN12
UVD-XP4DNR(-P) Camera
User Manual
Copyright
©
2012 UTC Fire & Security. All rights reserved.
Trademarks and patents
Interlogix, UltraView brand and logo are trademarks of UTC Fire & Security.
Manufacturer
UTC Fire & Security Americas Corporation, Inc.
1275 Red Fox Rd., Arden Hills, MN 55112 6943, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.
V.
Kelvinstraat 7, 6003 DH Weert, The Netherlands
Certification
N4131
FCC compliance
Class A:
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated i
n a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment
in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
European Union directives
2004/108/EC (EMC directive):
Hereby, UTC Fire & Security declares that this device is in
compliance with the essential requirements and other relevant provisions of Directive
2004/108/EC
ACMA compliance
Notice!
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user m
ay be required to take adequate measures.
Canada
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB
-0330 du Canada.
2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as
unsorted municipal waste in the European Union. For proper recycling, return this product
to your local supplier upon the purchase of equivalent new equipment, or dispose of it at
designated collect
ion points. For more information see: www.recyclethis.info.
Contact information
www.interlogix.com
www.utcfssecurityproducts.eu
UVD-XP4DNR(-P) Camera User Manual i
Content
Preface 3
Safety terms 3
Product description 4
Features 4
User guidelines 4
Components 5
OSD control pad 6
Installation 6
Cable connection 6
Camera installation 7
Angle adjustment 7
Focus adjustment 7
Connect the monitor 8
Programming 9
Main menu 9
Presets menu 10
Setup menu 10
Viewing menu 13
Exposure menu 13
White balance menu 14
Save/restore menu 15
Menu Map 18
UVD-XP4DNR(-P) Camera User Manual 3
Preface
This is the UVD-XP4DNR(-P) Camera. This document includes an overview of
the product and detailed instructions explaining:
• how to connect the camera; and
• how to program the camera.
• how to adjust the camera angle and focus
To use this document effectively, you should have the following minimum
qualifications:
• a basic knowledge of CCTV systems and components; and
• a basic knowledge of electrical wiring and low-voltage electrical connections.
Note: A qualified service person, complying with all applicable codes, should
perform all required hardware installation.
Safety terms
These terms may appear in this manual:
CAUTION: Cautions identify conditions or practices that may result in damage to
the equipment or other property.
WARNING: Warnings identify conditions or practices that could result in
equipment damage or serious personal injury.
4 UVD-XP4DNR(-P) Camera User Manual
Product description
The UVD-XP4DNR(-P) (rugged dome) color video cameras is a 24 VAC/12 VDC
model. The cameras are equipped with a digital signal processor (DSP) for
processing the video signal.
Features
Camera features include:
• Next-generation XPosure technology.
• Improved low-light performance and color balance.
• 540 TVL lines color.
• Dynamic range 95 dB (typical), 120 dB (maximum).
• Preset modes optimized for various environments.
• On-screen display interface.
User guidelines
Use the following guidelines:
• Program as many camera settings as possible before mounting the camera.
Take appropriate safety precautions while completing programming after
installation.
• Always use a 12 VDC or 24 VAC UL listed Class 2 power supply to power the
camera.
Do not use the camera outside the temperature range specifications: -22 to 122°F
(-30 to +50°C).
• If the light source where the camera is installed experiences rapid, wide-
variations in lighting, the camera may not operate as intended.
WARNING: To reduce the risk of fire or electronic shock, do not expose the
camera to rain or moisture and do not remove the cover or back.
UVD-XP4DNR(-P) Camera User Manual 5
Components
Figure 1 shows the main components of the rugged dome unit.
Figure 1: Rugged dom2e unit
Lens body Bubble
Camera body OSD control pad Video monitor output
Figure 3 shows the monitor output components.
Figure 2: Monitor output cable
A. Monitor output BNC B. Monitor output RCA
Plug the monitor output RCA into the video monitor output and connect the
monitor output BNC to the TV monitor.
6 UVD-XP4DNR(-P) Camera User Manual
OSD control pad
The on-screen display (OSD) control pad (Figure 4) is a five-direction joystick
that provides the ability to manually control the camera functions. Table 1 below
lists the OSD control pad functions and describes their use.
Figure 3: OSD control pad
OSD control pad
Table 1: OSD control pad controls
Pad directions
Desc
ription
Up
Moves the cursor upward to select an item
Left
Moves the cursor left to select or adjust the parameters of the selected
item.
Right
Moves the cursor to the right to select or adjust the parameters of the
selected item.
Down
Moves the cursor downward to
select an item.
Enter
P
ress the center of the control pad to display the Setup menu.If the selected item
h
as its own menu, press the control pad to enter a submenu. Press the control pad
f
or 2 seconds to save all settings and exit the Setup menu.
Installation
This chapter provides information on how to install the camera and adjust
camera angle and focus.
To install the camera you will need to prepare the mounting surface, make cable
connections, and mount the camera.
Cable connection
To make cable connections, do the following:
1. Connect a coaxial cable from the camera’s BNC connector to a CCTV
monitor or video recording device.
2. Connect a 12 VDC or 24 VAC power supply to the power input. The label on
the camera gives the following information:
Red cable. Power in.
Black cable. Power in.
White cable. Video out.
UVD-XP4DNR(-P) Camera User Manual 7
Black cable. Video ground.
Note: For AC24V or DC12V, Black or Red may be used for ground.
Camera installation
To mount the camera, attach the camera to the mounting surface using the
appropriate fasteners.
Angle adjustment
To adjust the horizontal angle of the platform up to 180 degrees, turn the platform
(Figure 4 below).
To adjust the horizontal angle of the rotor up to 350 degrees, turn the rotor on the
platform (Figure 4 below).
To adjust the vertical angle of the platform up to 90 degrees, turn the platform
(Figure 4 below).
Figure 4: Camera adjustment
Platform horizontal adjustment
Platform vertical adjustment
Rotor horizontal adjustment
Focus adjustment
To adjust the camera zoom and focus, see Figure 5 on page 8 and do the
following:
1. Loosen the zoom ring thumbscrew.
2. Turn the zoom ring to set the desired zoom.
3. Tighten the zoom ring thumbscrew.
4. Loosen the focus ring thumbscrew.
5. Turn the focus ring to set the desired focus.
6. Tighten the focus ring thumbscrew.
8 UVD-XP4DNR(-P) Camera User Manual
Figure 5: Zoom and focus adjustment
Zoom ring thumbscrew for VA2 and focus ring for
VA9 lens Focus ring thumbscrew for VA2 and zooming ring
for VA9 lens
Connect the monitor
Program the cameras by attaching a standard video monitor to the system.
To connect the monitor, do the following:
1. Plug the monitor output cable (Figure 2 on page 5) to the video monitor output
connector (Figure 1 on page 5).
2. Connect the BNC cable to the video monitor.
3. Press Enter (see OSD control pad on page 9) to display the Setup menu.
