IFM DTE801 Manual de usuario

Installation instructions
RFID compact unit
DTE801
DTE802
DTE803
DTE804
80279577 / 00 03 / 2019
UK

2
Contents
1 Preliminary note���������������������������������������������������������������������������������������������������4
1�1 Symbols used ������������������������������������������������������������������������������������������������4
1�2 Warnings used�����������������������������������������������������������������������������������������������4
1�3 Copyright and trademarks �����������������������������������������������������������������������������4
2 Safety instructions �����������������������������������������������������������������������������������������������4
3 Functions and features ����������������������������������������������������������������������������������������5
3�1 Configuration via Ethernet interface ��������������������������������������������������������������6
4 Items supplied������������������������������������������������������������������������������������������������������6
5 Function���������������������������������������������������������������������������������������������������������������6
5�1 Operating principle ����������������������������������������������������������������������������������������6
5�2 Overview DTE801������������������������������������������������������������������������������������������7
5�3 Overview DTE802������������������������������������������������������������������������������������������7
5�4 Overview DTE803������������������������������������������������������������������������������������������7
5�5 Overview DTE804������������������������������������������������������������������������������������������8
6 Installation������������������������������������������������������������������������������������������������������������8
6�1 General installation instructions���������������������������������������������������������������������8
6�2 Notes on ID tag mounting������������������������������������������������������������������������������8
6�3 Avoiding interference �������������������������������������������������������������������������������������9
6�4 Mechanical design�����������������������������������������������������������������������������������������9
6�5 Installation options�����������������������������������������������������������������������������������������9
6�5�1 Installation with angle bracket E80335 �����������������������������������������������10
6�5�2 Installation with mounting device E80336 ������������������������������������������ 11
6�5�3 Installation with fixing bars E80337 ���������������������������������������������������� 11
6�6 Mounting distances��������������������������������������������������������������������������������������12
6�7 Positioning of the ID tags�����������������������������������������������������������������������������12
7 Electrical connection������������������������������������������������������������������������������������������13
7�1 Voltage supply PWR������������������������������������������������������������������������������������13
7�2 Ethernet �������������������������������������������������������������������������������������������������������14
7�2�1 Factory setting of the Ethernet parameters ����������������������������������������14
7�3 Functional earth connection ������������������������������������������������������������������������15
7�3�1 Mounting plate ������������������������������������������������������������������������������������15
8 Operating and display elements ������������������������������������������������������������������������16
8�1 Reset to factory settings ������������������������������������������������������������������������������16

3
UK
8�2 LED indicators ���������������������������������������������������������������������������������������������17
8�2�1 Power LEDs and signal bar ����������������������������������������������������������������17
8�2�2 LED signal bar ������������������������������������������������������������������������������������17
8�2�3 LED LINK/ACT ETH 1 / ETH 2 �����������������������������������������������������������18
8�2�4 Special device LED indicators ������������������������������������������������������������18
8�3 LED indicators DTE801 �������������������������������������������������������������������������������19
8�3�1 LED SF �����������������������������������������������������������������������������������������������19
8�3�2 LED BF �����������������������������������������������������������������������������������������������19
8�4 LED indicators DTE802 �������������������������������������������������������������������������������20
8�4�1 LED Mod (module status)�������������������������������������������������������������������20
8�4�2 LED Net (network status) �������������������������������������������������������������������21
8�5 LED indicators DT803 ���������������������������������������������������������������������������������22
8�5�1 RUN LED��������������������������������������������������������������������������������������������22
8�5�2 LED ERR ��������������������������������������������������������������������������������������������22
8�6 LED indicators DTE804 �������������������������������������������������������������������������������23
8�6�1 LED SF �����������������������������������������������������������������������������������������������23
8�6�2 LED BF �����������������������������������������������������������������������������������������������23
9 Technical data����������������������������������������������������������������������������������������������������24
9�1 Data sheet ���������������������������������������������������������������������������������������������������24
9�2 Device manual���������������������������������������������������������������������������������������������24
10 Maintenance, repair and disposal��������������������������������������������������������������������24
11 Approvals/standards ����������������������������������������������������������������������������������������24
11�1 Radio approvals�����������������������������������������������������������������������������������������24
11�1�1 Overview�������������������������������������������������������������������������������������������24
11�1�2 Europe ����������������������������������������������������������������������������������������������24
11�2 EU declaration of conformity����������������������������������������������������������������������24
12 Scale drawing ��������������������������������������������������������������������������������������������������25

4
1 Preliminary note
Technical data, approvals, accessories and further information →
www�ifm�com�
1.1 Symbols used
►Instruction
> Reaction, result
[…] Designation of keys, buttons or indications
→Cross-reference
Important note
Non-compliance may result in malfunction or interference�
Information
Supplementary note
1.2 Warnings used
NOTE!
Kind and source of the hazard
> Possible consequences�
►Actions to refrain from�
►Measures to take�
1.3 Copyright and trademarks
© All rights reserved by ifm electronic gmbh� No part of these instructions may be
reproduced and used without the consent of ifm electronic gmbh�
All product names, pictures, companies or other brands used on our pages are the
property of the respective rights owners�
2 Safety instructions
• The device described is a subcomponent for integration into a system�
- The manufacturer is responsible for the safety of the system�
- The system manufacturer undertakes to perform a risk assessment and to
create a documentation in accordance with legal and normative requirements
to be provided to the operator and user of the system� This documentation
must contain all necessary information and safety instructions for the operator,
the user and, if applicable, for any service personnel authorised by the
manufacturer of the system�

5
UK
• Read this document before setting up the product and keep it during the entire
service life�
• The product must be suitable for the corresponding applications and
environmental conditions without any restrictions�
• Only use the product for its intended purpose (→ Functions and features).
• If the operating instructions or the technical data are not adhered to, personal
injury and/or damage to property may occur�
• The manufacturer assumes no liability or warranty for any consequences
caused by tampering with the product or incorrect use by the operator�
• Installation, electrical connection, set-up, operation and maintenance of the
product must be carried out by qualified personnel authorised by the machine
operator�
• Protect the device and the cables against damage�
• Use the device outside petrol stations, fuel depots, chemical plants or blasting
operations�
• Do not transport and store any flammable gases, liquids or explosive
substances near the device�
• Contact the manufacturer of the corresponding device in case of any
interference�
• Because of the requirements for electromagnetic interference emissions, the
device is intended for use in industrial environments� The device is not suitable
for use in domestic areas�
• Device safety: Use the device indoors only�
3 Functions and features
The DTE80x device is composed of an evaluation unit and an integrated RFID
read/write head and provides the following functions
• read and write ID tags which conform to the system without contact,
• DTE801: communication with the control level via PROFINET IO,
• DTE802: communication with the control level via EtherNet/IP,
• DTE803: communication with the control level via EtherCAT,
• DTE804: communication with the control level via EtherNet TCP/IP,
• can be configured via a web server�

6
Example applications:
• material flow control in production lines
• warehouse management by the automatic detection of stored products
• tank management, order picking or product tracking
The device may only be used under the operating conditions specified in
the data sheet�
3.1 Configuration via Ethernet interface
• 10 Mbps and 100 Mbps
• TCP/IP - Transport Control Protocol / Internet Protocol
• IT functionality: HTTP server
• M12, twisted pair
4 Items supplied
• DTE80x RFID compact unit
• Installation instructions
The device is supplied without installation and connection accessories�
In the event of incomplete or damaged items supplied, please contact ifm
electronic�
5 Function
5.1 Operating principle
The ID tags are operated passively, i�e� without battery� The energy required for
operation is supplied by the RFID compact unit�
The energy is transferred via an electromagnetic wave� The receiving antenna
takes up the wave and transforms it into voltage which supplies the data carrier
with energy�

7
UK
5.2 Overview DTE801
Art� no�:
Function:
Type designation:
Operating frequency:
Type:
Typ� transmitter power:
DTE801
RFID compact unit
DTRUHFE HLRWPNUS04
865 - 868 MHz
rectangular
23 dBm ERP (200 mW)
Fig� 1: Overview DTE801
5.3 Overview DTE802
Art� no�:
Function:
Type designation:
Operating frequency:
Type:
Typ� transmitter power:
DTE802
RFID compact unit
DTRUHFE HLRWEIUS04
865 - 868 MHz
rectangular
23 dBm ERP (200 mW)
Fig� 2: Overview DTE802
5.4 Overview DTE803
Art� no�:
Function:
Type designation:
Operating frequency:
Type:
Typ� transmitter power:
DTE803
RFID compact unit
DTRUHFE HLRWECUS04
865 - 868 MHz
rectangular
23 dBm ERP (200 mW)
Fig� 3: Overview DTE803

8
5.5 Overview DTE804
Art� no�:
Function:
Type designation:
Operating frequency:
Type:
Typ� transmitter power:
DTE804
RFID compact unit
DTRUHFE HLRWENUS04
865 - 868 MHz
rectangular
23 dBm ERP (200 mW)
Fig� 4: Overview DTE804
6 Installation
NOTE!
Radiated electromagnetic field strengths
The device sends ultrahigh frequency electromagnetic waves (construed
in accordance with DIN EN 50364, complies with the limit values for the
general public and workers)�
►For workstations adhere to a minimum distance of 10 cm�
►Disconnect the device in the vicinity of medical equipment�
6.1 General installation instructions
Devices installed next to each other interfere if they are not configured
correspondingly�
When mounting several systems adhere to the minimum distances between
the RFID compact units�
Installing a device in or on metal reduces the read and write distance�
The immediate vicinity of powerful HF emission sources such as welding
transformers or converters can affect operation of the RFID compact units�
Available accessories: www�ifm�com
6.2 Notes on ID tag mounting
For installation in and on metal the ID tags provided for this purpose must
be used�

9
UK
The ID tag must be positioned in the area of the sensing face (→ „6.4
Mechanical design“)� The angle of aperture and the operating distance must
be adhered to (→ Data sheet of the device).
The orientation of the RFID compact unit axis must correspond with the
axis of the ID tag�
6.3 Avoiding interference
The device generates a modulated electrical field with a frequency of 865-868
MHz� To avoid interference of the data communication no other RFID UHF devices
generating interference emission in this frequency band must be operated in its
vicinity�
Observe the notes on installation when several RFID UHF devices are
operated simultaneously�
6.4 Mechanical design
1
2
1: Sensing face
2: Connections (can be rotated by 270°)
Fig� 5: Mechanical design
6.5 Installation options
For installation, the following optional accessories are available�
The device can be mounted without the accessories� For installation,
please use the threaded sleeves on the back of the device� The necessary
screws are not supplied with the device�

10
6.5.1 Installation with angle bracket E80335
Fig� 6: Installation with angle bracket E80335
Otros manuales para DTE801
2
Este manual sirve para los siguientes modelos
3
Tabla de contenidos
Otros manuales de Sistema RFID de IFM

IFM
IFM DTM426 Manual de usuario

IFM
IFM DTC510 Manual de usuario

IFM
IFM DTM424 Manual de usuario

IFM
IFM DTM424 Manual de usuario

IFM
IFM ANT513 Manual de usuario

IFM
IFM DTE603 Manual de usuario

IFM
IFM DTE801 Manual de usuario

IFM
IFM DTM434 Manual de usuario

IFM
IFM DTC600 Manual de usuario

IFM
IFM DTI420 Manual de usuario
