Huawei E5577 Manual de usuario

Quick Start

1

Installation

SIM card

microSD card (optional)

1

2

1

2

2

1

2

Wi-Fi connection

SSID:xxxx

Wi-Fi Key:xxxx

Press the MENU button to access the menu and view the current SSID and Wi-Fi key

on the device screen.

We strongly recommend that you change the default SSID and Wi-Fi key to keep your

data secure.

3

HUAWEI HiLink

Download HUAWEI HiLink to manage your Mobile WiFi.

APP

You can also manage your Mobile WiFi through the web interface at

http://192.168.8.1. The default username and password is admin.

ClickHelp in the upper right corner of the screen to learn more about your

Mobile WiFi.

4

Wi-Fi extender (optional)

The Wi-Fi extender feature increases Wi-Fi coverage and connects to Wi-Fi networks

where available to reduce mobile data usage.

1. From the HUAWEI HiLink app, touch Settings and enable the Wi-Fi extender

feature.

2. Connect to a Wi-Fi network.

Your Mobile WiFi will connect to known Wi-Fi networks when the extender

feature is enabled.

5

Appearance

POWER button

MICRO USB port RESET button

MENU button

POWER button: Press and hold to turn your Mobile WiFi on or off.

MENU button: Press to display the menu.

RESET button: Press and hold to reset your Mobile WiFi and restore it to its factory

settings.

If you forget the username, password or SSID for your Mobile WiFi, try restoring

the device to its factory settings.

6

Charging

0%100%0%100%

Please only use compatible chargers provided by a designated manufacturer.

The charger is an optional accessory. To buy a charger, please contact an

authorized retailer.

7

FAQs

Why isn't my Mobile WiFi responding?

Try restarting the device. If that doesn't work, restore the device to its factory

settings.

Why can't I connect to my Mobile WiFi sometimes?

To save power, your Mobile WiFi's Wi-Fi auto off feature is designed to turn off

Wi-Fi when there haven't been connections for a while. You can press the

POWER button to turn on Wi-Fi again. Alternatively, you can disable this feature,

although this might impact battery life. Log in to the HiLink app or web interface

and disable the Wi-Fi auto off feature.

Why won't my Mobile WiFi connect to a network even though all the

settings are correct?

The PIN verification feature might be enabled. Launch HUAWEI HiLink and enter

the correct PIN.

You can disable this feature if you find entering the PIN regularly inconvenient.

8

From the HiLink app, select Settings and then disable the PIN verification

feature.

Why can't I access the web interface at 192.168.8.1?

This is likely due to an IP address conflict when the Mobile WiFi assigns itself a

new IP address. Please try 192.168.9.1 in this case.

If your Mobile WiFi has an LCD screen, the new IP address of your web interface

will be displayed.

Why won't my Mobile WiFi power on?

Your battery is probably out of power.

Charge your Mobile WiFi for a while and power it back on.

Why did my Mobile WiFi power off all of a sudden?

Your Mobile WiFi may overheat when you use it continuously over a long period

of time, and thereby trigger its automated protection system. Wi-Fi will be turned

off and your Mobile WiFi will power off if this occurs.

Please ensure the device is properly ventilated and cooled before you power it

on again.
