gofanco USBCwireless Manual de usuario
Wireless Type-C/HDMI
Extender Kit - 30m
User's Guide
G4-0076A
P/N: USBCwireless
2
Thank you for purchasing from gofanco. Our
products aim to meet all your connectivity needs
wherever you go. For optimum performance
and safety, please read the instructions carefully
and keep this User’s Guide for future reference.
If you need more information about our
products, please visit www.gofanco.com. For
technical support, please email us at
download, please go to www.gofanco.com/
download.
Important Safety Notices
Please read safety instructions carefully before
installation and operation.
• Please pay close attention to all warnings
and hints for this device
• Do not expose this unit to rain, heavy
moisture, or liquid
• Do not repair the device or open the
enclosure without professional guidance
to avoid electric shocks. Doing so may void
your warranty
• Keep the product in a well-ventilated
location to avoid damage from overheating
3
• Shut off power and make sure environment
is safe before installation
• Do not plug the HDMI cables in/out when
the device is in use to avoid cable damage.
Make sure they are plugged into the correct
ports
• Use the included DC5V power adapters
only. Make sure the specification matches
if using 3rd-party DC power adapters
Introduction
The Wireless Type-C/HDMI Extender Kit - 30m
extends high definition 1080p HDMI signals up
to 30 meters.
Note: Wireless transmission distance will
vary due to the environment conditions.
Thick walls, brick, glass or electronic
interference will shorten the wireless
transmission distance or cause signal loss.
4
Features
• Mid-range wireless extension ideal for
meeting/conference room applications
• Type-C input on the Transmitter (TX) and
HDMI output on the Receiver (RX)
• Type-C Transmitter unit powered by the
Type-C source device
• Supports up to 98 feet (30m) in 1080p with
auto quality adjustment
• Operates on 5Ghz frequency with strong
anti-interference ability
PackageContents
Transmitter (TX) Receiver (RX)
Power Adapter (1pc) User's Guide
5
Installation Requirements
1. Type-C source device (Phone, tablet,
computer, etc)
2. HDMI display device (SDTV/Monitor,
HDTV/Monitor, projector, etc.)
Product Layout
Figure 1: Transmitter (TX)
1. Type-C Input Connects to the source device's Type-C port
2. Connection LED On when the Transmitter and Receiver are
linked properly
3. Power LED On when Transmitter is powered by the Type-C
port properly
6
Figure 2: Receiver (RX)
1. Power Adapter Jack Connects to the included power adapter
2. Connection LED On when powered on
Blinks when wireless connection is linked
3. Data Transmission LED On when transmitting data, otherwise it's off
4. HDMI Output Connects to the HDMI display device
5. Antenna Transmits wireless signals
7
Hardware Installation
1. Power off your HDMI display.
2. Plug the Transmitter's Type-C connector
into a Type-C port of the source device.
3. Connect your HDMI display to the
Receiver's HDMI Output with an HDMI
cable (HDMI cable not included).
4. Plug the included power adapter into the
Receiver's power jack, then plug the power
adapter into a reliable power source.
5. Power on the HDMI display.
6. The extender is ready for use.
8
Application
Transmitter
Receiver
HDMI
Cable Display
Type-C Source
(Phone, Computer)
Power Adapter
9
FAQ & Solutions
Q: The Transmitter and Receiver can't connect
to each other:
A: 1) Please check if the Connection LED on
Transmitter and Receiver are blinking.
2) Power cycle the transmitter and receiver.
3) Make sure the HDMI cable is firmly
connected to the display.
4) Change the position of the transmitter
and receiver and make sure they are within
the required signal range.
Q: The Transmitter's Connection LED is on
but no image on the display:
A: 1) Reconnect the HDMI cable to the display.
2) Connect the source device directly to the
display to see if there is a signal.
Q: The display is not clear or stable:
A: 1) Change the position of the transmitter
and receiver and make sure they are within
the required signal range.
2) Reconnect the HDMI cable.
3) Power cycle the transmitter and receiver.
4) Remove other wireless signals and move
any obstacles that are blocking the signal.
10
Specifications
Item Specification
HDMI Compliance HDMI 1.3
HDCP Compliance HDCP 1.2
Resolution 480p@60Hz, 576p@50Hz,
720p@50/60Hz, 1080p@50/60Hz
Bandwidth 10.2Gbps
Wireless Transmission 5.0 GHz
Wireless Latency <200ms
Transmission Distance Up to 98ft (30 meters)
Housing Material Plastic
Power Adapter (RX only) Output: DC5V/2A
Power Consumption TX: <3W / RX: <5W
Operating Temperature 32° - 104° F (0° - 40° C)
Storage Temperature -4° - 158° F (-20° - 70° C)
Humidity 0% - 90% (non-condensing)
Product Dimension TX: 3.42" (L) x 1.53" (W) x 0.60" (H)
RX: 5.18" (L) x 3.74" (W) x 0.78" (H)
Weight TX: 0.04 lbs / RX: 0.49 lbs
