Fujitsu PRIMERGY S10 Manual de usuario

Primergy

PRIMERGY S10

Storage Subsystem

XeniaFierley

FujitsuSiemensComputersGmbHcognitasPS

85521München_Ottobrunn

e-mail:Internet:DOCetc@mchp.siemens.de

Tel.:(089)61001-157

Fax:(089)61001103

U41181-J-Z156-1-74

Sprachen:En

Edition October 2000

This manual is printed on

paper treated with

chlorine-free bleach.

Comments…Suggestions…Corrections…

The User Documentation Department would like to know

your opinion on this manual. Your feedback helps us to

optimize our documentation to suit your individual needs.

Fax forms for sending us your comments are included at the

back of the manual.

There you will also find the addresses of the relevant User

Documentation Department

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

Introduction

Important notes

Installation

Preparation or use and operation

Troubleshooting

Related publications and index

U41181-J-Z156-1-74

Contents

1Introduction............................1

1.1 Targetgroup............................2

1.2 Notational conventions .......................2

1.3 User-friendly documentation – verified quality ...........3

1.4 Technicaldata...........................4

2 Important notes ..........................7

2.1 Notesonsafety ..........................7

2.2 Electrostatic-sensitive component label . . ............9

2.3 CEcertificate .......................... 10

2.4 RFI suppression ......................... 10

2.5 FCCnotices(FederalCommunicationsCommission)...... 10

2.6 Powercordselection....................... 11

2.6.1 For the United States and Canada ............... 11

2.6.2 For the United Kingdom ..................... 12

2.7 Notes on mounting in the rack .................. 13

2.8 Notesontransportation ..................... 14

2.9 Environmentalprotection .................... 14

3 Installation ........................... 17

3.1 Installationsteps......................... 17

3.2 Unpacking the storage subsystem ................ 18

3.3 Mounting the subsystem in the rack ............... 18

3.3.1 Routingcables.......................... 19

3.4 SettingtheSCSIID ....................... 20

3.5 Connecting the storage subsystem ............... 20

3.5.1 Connecting SCSI cables ..................... 21

3.5.2 Connecting the power cable ................... 21

3.6 Connecting and disconnecting cables . . . ........... 22

4 Preparation for use and operation .............. 23

4.1 Operating and display components ............... 23

4.2 Switchingthestoragesubsystemon/off............. 23

5 Troubleshooting ........................ 25

5.1 Opening the storage subsystem housing . ........... 25

5.2 Storage subsystem cannot be switched on ........... 26

5.3 SCSIdevicesarenotdetected ................. 27

5.4 IncorrectSCSIID ........................ 27

5.5 Fanfailure ............................ 27

5.6 Replacingthebackupunit.................... 28

U41181-J-Z156-1-74

Contents

Related publications ............................31

Index ....................................33

U41181-J-Z156-1-74 1

1 Introduction

The demand for storage capacity that is capable of scalable growth and the

increasing trend towards rack-based servers have generated a need for corre-

spondingly compact and powerful backup systems with a correspondingly

serious approach to data security.

The PRIMERGY S10 storage subsystem provides a flexible means of consoli-

dating rack-based data security. The PRIMERGY S10 makes it possible to

install present-day backup units (such as, for example, DLT 7000, DDS3,

DDS4, Autoloader, etc.) in a separate 19” cabinet and provides two 3.2”-high or

four 1.6”-high slots for this purpose. The subsystem is also prepared to accom-

modate future back up units.

The subsystem offers a simple, flexible and low-priced solution for avoiding

backup constraints and facilitating expansion.

The PRIMERGY S10 can be connected via onboard controllers or Adaptec

2940 U2W. The storage subsytem has been equipped with an LVD interface

module.

The LVD interface module accommodates the control and display elements and

the logic for controlling the power supply and monitoring the fan. It also estab-

lishes a connection between the external and internal cabling. All the necessary

connectors for the internal cabling are located on this module (socket for the

power supply, for the fan connector, and for the internal SCSI line), as well as

the socket for the external SCSI output (see also section “Connecting the

storage subsystem” on page 20). An LVD/SE SCSI terminator is integrated in

the interface and is automatically activated on the last subsystem in the string if

no SCSI connection to another storage subsystem exists (no daisy-chain).

Up to two PRIMERGY S10 can be connected to a SCSI string.

The storage subsystem is cooled by a fan. The fan is monitored to make sure it

does not fall below the nominal speed. If the “Local/Remote” switch is set to

“Remote“, the storage subsystem is switched off in the event of an error, or the

system is prevented from being switched on again, as appropriate (see also

chapter “Troubleshooting” on page 25).

The PRIMERGY S10 storage subsystem possesses an integrated power

supply unit.

The PRIMERGY S10 occupies three height units (3 HU) in the 19” rack.

2U41181-J-Z156-1-74

Target group Introduction

1.1 Target group

This manual is intended for those responsible for installing the hardware and

ensuring that the system runs smoothly. The operating manual contains all the

information required for installing and operating your system.

Knowledge of the hardware and data transfer, as well as a basic knowledge of

the operating system used, is required to understand the various expansion

options. You should also have a good working knowledge of the English

language.

1.2 Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

Text in italics indicate commands or menu item

"Quotation marks" indicate names of chapters and terms that are being

emphasized

ÊTexts which follow this symbol describe activities that

must be performed in the order shown

IThis symbol is followed by supplementary information,

remarks and tips

VPay particular attention to texts marked with this symbol.

Failure to observe this warning endangers your life,

destroys the system, or may lead to loss of data.

Table 1: Notational conventions

U41181-J-Z156-1-74 3

Introduction User-friendly documentation – verified quality

1.3 User-friendly documentation – verified

quality

As part of its efforts to further improve the information provided for users, the

editorial department responsible for this manual has been independently

audited to verify its high standards of quality of the documentation.

This audit was carried out by TÜV PRODUCT SERVICE GmbH. The following

aspects were investigated:

– General comprehensibility

– User-friendliness

– Occupational hygiene and safety for the users

– Safety of the application and observance of the relevant

regulations, standards and guidelines

– Environmental protection

– Layout, realization, readability

– Conformity with the product

– Accuracy and completeness of the contents

The criteria for the audit were developed in a joint project between

TÜV PRODUCT SERVICE GmbH and

tekom, Gesellschaft für technische Kommunikation e.V.

The DOCcert seal provides visible

evidence of the successful completion

of the audit.

4U41181-J-Z156-1-74

Technical data Introduction

1.4 Technical data

Electrical data power supply unitl

Rated voltage 100 V-125 V / 200 V-240 V

Tolerance of the rated voltage +6 % / -10 %

Rated frequency 50 Hz / 60 Hz

Max. rated current 240 V / 2,0 A

100 V / 4,0 A

Apparent power (heat transfer) max. 200 W

Power factor (PF) >65%

Effective power of typical peripheral devices

(the actual effective power will depend on the number and type of peripheral

devices installed)

DLT7000 39 W

LTO 50 W

SLR100 23.1 W

Mammoth 18 W

Magneto Optical Disk 15 W

Dimensions and weight

Height (mm) 133

Width (mm) 483

Depth (mm) 646

Weight (kg) ca. 20 (depending on configuration)
