Fujitsu ETERNUS LT20 S2 Manual de usuario

ETERNUS LT20 S2

(LT20S2JNXU)

ETERNUS LT40 S2

(LT40S2JNXU)

ETERNUS LT60 S2

(LT60S2JNXU)

Tape Library

User's Guide

-Monitoring Software Setup Procedure-

P3AM-5262-01ENZ0

FOR SAFE OPERATION

This manual contains important information regarding the use and handling of

this product. Read this manual thoroughly. Pay special attention to the section

"FOR SAFE OPERATION" Use the product according to the instructions and

information available in this manual. Keep this manual handy for further

reference.

Fujitsu makes every effort to prevent users and bystanders from being injured or

damage to their property. Use the product according to this manual.

ABOUT THIS PRODUCT

This product is designed and manufactured for use in standard applications such

as office work, personal devices and household appliances. This product is not

intended for special uses (atomic controls, aeronautic or space systems, mass

transport controls, medical devices for life support, or weapons firing controls)

where particularly high reliability requirements exist, where the pertinent levels of

safety are not guaranteed, or where a failure or operational error could threaten a

life or cause a physical injury (hereafter referred to as "mission-critical" use).

Customers considering the use of these products for mission-critical applications

must have safety-assurance measures in place beforehand. Moreover, they are

requested to consult our sales representative before embarking on such

specialized use.

TRADEMARKS ACKNOWLEDGEMENTS

- Microsoft, Windows,and MS are registered trademarks of Microsoft

Corporation in the United States or certain other countries.

- All other corporation names and product names mentioned herein are the

trademarks or registered trademarks of their respective owners.

P3AM-5262-01ENZ0

RADIO FREQUENCY INTERFERENCE STATEMENT

The following notice is for EU users only.

WARNING: This is a product which meets Class A of EN55022. In a domestic

environment this product may cause radio interference in which case the user

may be required to take adequate measures.

The following notice is for USA users only.

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the

interference at his own expense.

Measures against instantaneous voltage drop

The LT20 S2/LT40 S2/LT60 S2 may be affected by instantaneous voltage drop

due to lightning strikes or other factors. To protect the LT20 S2/LT40 S2/LT60

S2 against instantaneous voltage drop, the user should preferably provide an AC

uninterruptible power supply or the like for the LT20 S2/LT40 S2/LT60 S2.

P3AM-5262-01ENZ0

Revision History

(1/1)

Edition Date Revised location (type) (*1) Revision

01 June, 2011 −−

*1 Items in the "Revised location" column refer to the latest edition unless the

item is marked with an asterisk. An asterisk indicates an item in an older

edition.

P3AM-5262-01ENZ0 i

Preface

Thank you for your purchasing the ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape

Library.

To ensure the proper handling of this product, read this manual, the other

manuals supplied with this product, and the manuals supplied with the server and

software thoroughly and carefully before using it.

This manual explains the settings for using monitoring software "ETERNUS SF

Storage Cruiser" with the ETERNUS LT20 S2/LT40 S2/LT60 S2 Tape Library.

The purpose of this manual is to explain in detail how to set SNMP for this library

(hereafter called "tape library," "library," or "this device"), how to set up

"ETERNUS SF Storage Cruiser," and how to confirm SNMP trap sending with

this device.

This manual is intended for users who have a basic knowledge of magnetic tape

libraries and the usage of the tape libraries in computer systems. The

organization of the manuals related to this device and the coverage of this

manual are shown in "Manual Organization" provided later in this manual. Use

other manuals as well when necessary.

The organization and contents of this manual are explained below. This

information is followed by the symbols for alert messages with their meanings.

Organization and contents of This Manual

This manual has four chapters below.

Chapter 1 Setting up SNMP

Explains how to set up SNMP with this device.

Chapter 2 Setting up Monitoring Software

Explains how to set up monitoring software "ETERNUS SF Storage Cruiser."

Chapter 3 Confirming the SNMP Trap Settings

Explains how to send SNMP traps with this device.

Chapter 4 Event List

Explains the events that are reported by SNMP of this device.

Preface

ii P3AM-5262-01ENZ0

Abbreviation

In this manual, the product names are abbreviated as follows:

Long title Abbreviation

Microsoft® Windows® XP Professional operating system

Microsoft® Windows® XP Home Edition operating system

Windows XP

Microsoft® Internet Explorer® Internet Explorer IE

P3AM-5262-01ENZ0 iii

Note on Safety

Safety Precautions

Read thoroughly this manual to use this product safely and correctly.

Use the unit correctly according to this manual so that damage should not reach

the human body and your property.

Keep this Monitoring Software Setup Procedure at hand for quick reference at

anytime necessary.

In this User's Guide, the following indications are used to use the product safely

and correctly. Thoroughly understand the meaning of the indication before using

this product.

Warning Failure to heed this sign could result in serious injury or

death.

Caution Failure to heed this sign could result in personal injury or

damage to properties.

Precautions and notices against hazards are presented with one of the following

symbols.

Indicates that improper use may cause fumes or fire.

Indicates that improper use may cause explosion.

Indicates that improper use may cause an electric shock.

Indicates that improper use may cause personal injury due to toxic material.

Indicates that improper use may cause hands or fingers to be caught.

Indicates a general prohibited action or warning that cannot be specifically

identified.

Note on Safety

iv P3AM-5262-01ENZ0

Indicates that the disassembling and modification of the product is inhibited.

Indicates that the user is inhibited to touch the product.

Indicates a general mandatory action or warning that cannot be specifically

identified.

Indicates an instruction to unplug the power cord from the outlet and turn off the

circuit breaker of power distribution panel.

P3AM-5262-01ENZ0 v

Manual Organization

ETERNUS LT20 S2

LTO Library

Installing, Starting Up

and Maintaining

(P3AM-5382)

1. Preface

2. Product Description

3. Installing the Tape Library

4. Operating the LTO Library

5. Troubleshooting

6. Servicing

7. Packaging before Transportation

8. Technical Specifications

9. Recycling and Disposal

10. Regulatory Information

ETERNUS LT40 S2/

LT60 S2 LTO Library

Installing, Starting Up

and Maintaining

(P3AM-5392)

1. Preface

2. Product Description and Features

3. Installing the Tape Library

4. Operating the Tape Library

5. Troubleshooting

6. Servicing the Tape Library

7. Technical Specifications

8. Packaging Before Transportation

9. Recycling and Disposal

10. Regulatory Information

ETERNUS LT20 S2/

LT40 S2/LT60 S2

Tape Library

User's Guide

-Monitoring Software

Setup Procedure-

(P3AM-5262)

1. Setting up SNMP

2. Setting up Monitoring Software

3. Confirming the SNMP Trap Settings

4. Event List
