Fujitsu SLR 50 GBYTE Manual de usuario

SLR 50/100 GBYTE

SLR 50/100 GBYTESLR 50/100 GBYTE

SLR 50/100 GBYTE

BETRIEBSANLEITUNG

BETRIEBSANLEITUNGBETRIEBSANLEITUNG

BETRIEBSANLEITUNG

OPERATING MANUAL

OPERATING MANUALOPERATING MANUAL

OPERATING MANUAL

Dieses Handbuch wurde auf Recycling-Papier gedruckt.

This manual has been printed on recycled paper.

Ce manuel est imprimé sur du papier recyclé.

Este manual ha sido impreso sobre papel reciclado.

Questo manuale è stato stampato su carta da riciclaggio.

Denna handbok är tryckt på recyclingpapper.

Dit handboek werd op recycling-papier gedrukt.

Bestell-Nr./Order No.: A26361-H583-Z100-1-7419

A26361-H583-Z100-1-7419A26361-H583-Z100-1-7419

A26361-H583-Z100-1-7419

Printed in the Federal Republic of Germany

AG 0900 09/00

A26361-H583-Z100-1-7419

SLR 50/100 GBYTE BETRIEBSANLEITUNG

OPERATING MANUAL

SLR 50/100 GBYTE

Betriebsanleitung

Operating Manual

Deutsch

lish

Ausgabe September 2000

September 2000 edition

Microsoft, MS, MS-DOS und Windows sind eingetragene Warenzeichen der Microsoft

Corporation.

Die übrigen im Buch erwähnten Software- und Hardwarebezeichnungen sind in den meisten

Fällen auch eingetragene Warenzeichen und unterliegen als solche gesetzlichen

Bestimmungen.

Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.

Zuwiderhandlungen verpflichten zu Schadenersatz.

Liefermöglichkeiten und technische Änderungen vorbehalten.

Dieses Handbuch wurde erstellt von

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation.

Other software and hardware names referred to in the manual are generally also registered

trademarks whose use is also subject to legal conditions.

All rights, including rights of translation, reproduction by printing, copying or similar methods,

even of parts are reserved.

Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or design,

are reserved.

Delivery subject to availability. Right of technical modification reserved.

This manual was produced by

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

A26361-H583-Z100-1-7419 English

Contents

Introduction........................................................................................................................................1

Notational conventions ..............................................................................................................1

Important notes .................................................................................................................................2

Safety........................................................................................................................................2

Manufacturer's note...................................................................................................................2

Installation.........................................................................................................................................2

Setting the jumpers....................................................................................................................3

Mounting the drive.....................................................................................................................5

Connecting the drive..................................................................................................................5

Operation...........................................................................................................................................6

Meaning of the indicators...........................................................................................................7

Handling magnetic tape cartridges.............................................................................................8

Cleaning..........................................................................................................................................10

Technical data.................................................................................................................................11

A26361-H583-Z100-1-7419 English - 1

Introduction

SLR100SLR 50/100 GBYTE is a drive for magnetic tape cartridges with a storage capacity of

50 Gbyte (without compression) or 100 Gbyte (with 2:1 compression).

The drive is an inexpensive mass storage which is especially suited for the following applications:

• Backup of hard disk drives

• Data archiving

• Data exchange

• Software distribution

• Emergency recovery

The drive has an SCSI interface of the type Ultra Wide LVD/SE (Low Voltage Differential or Single-

Ended). Therefore, in order to operate the drive the computer must have a SCSI host adapter and

the appropriate SCSI drivers must be installed.

This manual contains all the information you require to install and operate the drive.

Target group

To install the drive, you need some knowledge of hardware. Make sure you observe the instructions

in the "Important notes" chapter of your system unit's Operating Manual.

In the event of any problems occurring, please contact your sales outlet or our customer service

center.

Further information

For details of the drive mounting procedure refer to the Operating Manual or Technical Manual of

your system unit.

Information on the SCSI host adapter is contained in the Technical Manual of the SCSI host adapter

or in the Operating Manual or Technical Manual of your system unit.

For information on the required SCSI drivers and the backup software, refer to the software

documentation.

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

!Pay particular attention to texts marked with this symbol. Failure to observe this warning

endangers your life, destroys the system, or may lead to loss of data.

Supplementary information, remarks and tips follow this symbol.

Ê Texts which follow this symbol describe activities that must be performed in the order shown.

"Quotation marks" indicate names of chapters, disks and terms that are being emphasized.

SLR 25/50 Gbyte

2 - English A26361-H583-Z100-1-7419

Important notes

!In this chapter you will find information regarding safety which is essential to take note of

with your drive.

Safety

This device complies with the relevant safety regulations for data processing equipment, including

electronic office machines for use in an office environment. If you have any questions, contact your

sales outlet or our customer service center.

• This device has been developed for use in approved systems with a fire-proof casing (in

accordance with IEC 950 / EN 60950).

• Note the power loss and the notes on environmental conditions in the "Important notes"

chapter of the system unit's Operating Manual.

Manufacturer's note

CE certificate

The shipped version of this drive complies with the requirements of the EC Guideline

89/336/EEC "Electromagnetic compatibility".

Compliance was tested in a typical system configuration.

When installing the drive, observe the specific installation notes in the Operating

Manual or Technical Manual of the receiving device.

Installation

!Please note the information provided in the chapter "Important notes" in the Operating

Manual of the system unit or in the manual "Safety, Guarantee and Ergonomics".

The following steps must be performed to install the drive:

• Setting the jumpers (e. g. SCSI address, parity)

• Mounting the drive

• Connecting the drive

• Installing the software required (drivers, backup program)

The drivers required for operating SCSI drives are either part of the operating system or

are provided with the backup software.
