Fujitsu Fi-4860C Manual

erator's Guid

i-4860C Ima

e Scanne

PC-E1

3EN

●i

Thank you for purchasing the fi-4860C Duplex Color Scanner.

The fi-4860C is an image scanner designed to scan various documents in large

quantities. FUJITSU fi series image scanners are known for its high reliability and

this scanner is no exceptions. The fi-4860C is designed to give you the best results

for your scanning need.

The fi-4860C has the following features.

 High speed, high quality color scanning capabilities

Scans documents of Letter/A4 size at the speed of 60ppm/120ipm

@200dpi.

 Highly reliable document handling

Accepts various thicknesses, sizes and types of documents.

 Production ready

High capacity hopper 500sheets of 20lb or 80g/m2 Letter/A4 size and

Pre and Post imprinter options. Duplex capability is available as

standard feature.

About this manual

The manual provides the following information.

1. BASIC OPERATIONS

This chapter describes basic scanner operations and basic document

scanning.

2. SCANNING DOCUMENTS

This chapter describes how to scan various type of documents.

3. DAILY CARE

This chapter describes how to clean the scanner.

4. REPLACING CONSUMABLES

This chapter describes how to replace scanner consumables.

INTRODUCTION

●ii

5. SOLVING COMMON PROBLEMS

This chapter describes how to remedy document jams, other trouble,

and items to check before contacting the agent where you bought the

scanner, and how to check device labels.

6. ADF DOCUMENT SPECIFICATIONS

This chapter describes about documents can be used with this scanner.

7. OPERATOR PANEL MENUS

This chapter describes about Setup-mode and Test-mode.

8. OPTIONS

This chapter describes about options.

9. SCANNER SPECIFICATIONS

This chapter lists the scanner specifications.

The “Installation Guide” is attached to this Scanner.

This guide contains necessary information for the scanner and the driver

installation, please also read the Installation Guide.

1. SCANNER BASICS

This chapter describes how to prepare the scanner for use.

2. INSTALLATION AND CONNECTIONS

This chapter describes how to install and connect the scanner, and how

to install the scanner application.

We hope that this manual is useful in taking full advantage of the fi-4860C Duplex

Color Scanner's features.

●iii

■ Regulatory Information

FCC Regulations

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his

own expense.

Canadian DOC Regulations

This digital apparatus does not exceed the Class A limit for radio noise emissions

from digital apparatus set out in the Radio interference Regulations of the Canadian

Department of Communications.

Le pésent appareil numérique n’ément pas de bruits radioélectriques dépassant les

limites applicables aux appareils numériques de la classe A prescridtes dans le

Réglesment sur le brouillage radioélectrique dicté par le ministere des

Communications du Canada.

Cet appareil numérique de la classe A est conformme à la norme NMB-003 du

Canada.

CAUTION

Changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to

operate the equipment.

ATTENTION

•The use of a shielded interface cable is required to comply

with the Class A limits of Part 15 of FCC rules. The length of

the SCSI interface cable must be 1.5 meters (5 feet) or less.

•The length of the AC cable must be 3 meters (10 feet) or

less.

●iv

Bescheimigung des Herstellers / Importeurs

Hiermit wird bescheinigt, daß der/dieldas

•fi-4860C in Übereinsstimmung mit den Bestimmungen der

•AmtsblVfg 243/1991 funkentstört ist. Der Deutschen Bundesport wurde das

Inverkehrbringen dieses Gerätes angezeigt und die Berechtigung zur Überprüfung

der Serie auf Einhaltung der Bestimmungen eingeräumt.

•Maschinenlärminformationsverordnung 3. GS GV, 18.01.1991:Der höchste

Schalldruckpegel beträgt 70 dB (A) order weniger gemäß ISO/7779.

●v

International ENERGY STAR® Program

As an ENERGY STAR® Partner, PFU LIMITED has determined

that this product meets the ENERGY STAR® guidelines for energy

efficiency.

The International ENERGY STAR® Office Equipment Program is

an international program that promotes energy saving through the penetration of

energy efficient computers and other office equipment. The program backs the

development and dissemination of products with functions that effectively reduce

energy consumption. It is an open system in which business proprietors can

participate voluntarily. The targeted products are office equipment such as

computers, monitors, printers, facsimiles, copiers, scanners, and multifunction

devices. Their standards and logos ( ) are uniform among participating

nations.

This product meet the ENERGY STAR® guidelines of Japan and U.S.

Use in High-safety Applications

This product has been designed and manufactured on the assumption that it will be

used in office, personal, domestic, regular industrial, and general-purpose

applications. It has not been designed and manufactured for use in applications

(simply called "high-safety applications" from here on) that directly involve serious

danger to life and health when an extremely high degree of safety is required, for

example, in the control of nuclear reactions at nuclear power facilities, automatic

flight control of aircraft, air traffic control, operation control in mass-transport

systems, medical equipment for sustaining life, and missile firing control in weapons

systems, and when provisionally the safety in question is not ensured. The user

should use this product without adopting measures for ensuring safety in such high-

safety applications. PFU LIMITED assumes no liability whatsoever for damages

arising from use of this product by the user in high-safety applications, and for any

claims or compensation for damages by the user or a third party.

●vi

About the use of mercury

The scanner lamp contains mercury.

Too avoid unexpected injury, read the followings carefully.

Doing following actions may result in serious personal injuries:

•Do not put the substance in the lamp in your mouth as it contains mercury.

•Do not incinerate, crush, or shred the scanner.

•Do not breath the chemical liquid contained in the scanner parts.

Disposing of the scanner should be conducted as required by local ordinances or

regulations.

Illegal Copying

Reproducing bills, coins, government securities and passports, licenses issued by

public author or civilian organizations, official documents, private paper is illegal

and brought to justice

Literary works like books, paintings, wood block prints, maps, drawings, and

photographs should not be reproduced other than the personal or domestic use or

the use within other limit without the rightful person’s permission.

●vii

Trademarks

Microsoft, Windows and Windows NT are registered trademarks of Microsoft

Corporation of the USA and other respective countries.

ISIS is a registered trademark of Pixel Translations, A Division of Actionpoint Inc.

Adobe and the Adobe logo as well as Acrobat and the Acrobat Logo are trademarks

of Adobe Systems Incorporated.

Other product names referred to in this manual are registered trademarks or

trademarks of respective companies.

How Trademarks Are Indicated In This Manual

References to operating systems (OS) are indicated as follows:

Windows®95: Refers to Microsoft®Windows®95 operating system.

Windows®98: Refers to Microsoft®Windows®98 operating system.

Windows®Me: Refers to Refers to Microsoft®Windows®Millennium Edition

operating system.

Windows®2000: Refers to Microsoft®Windows®2000 Professional operating

system.

Windows®XP: Refers to Microsoft®Windows®XP Professional operating

system, and Microsoft®Windows®XP Home Edition operating

system.

Windows NT®: Refers to Microsoft®Windows NT®operating system Version4.0.

Where there is no distinction between the different versions of the above operating

system, the general term "Windows®“ is used.

●viii

■ Note, Liability

READ ALL OF THIS MANUAL CAREFULLY BEFORE USING THIS PRODUCT.

IF NOT USED CORRECTLY, UNEXPECTED INJURY MAY BE CAUSED TO

USERS OR BYSTANDERS.

While all efforts have been made to ensure the accuracy of all information in this

manual, PFU LIMITED assumes no liability to any party for any damage caused by

errors or omissions or by statements of any kind in this manual, its updates or

supplements, whether such errors are omissions or statements resulting from

negligence, accidents, or any other cause. PFU LIMITED further assumes no

liability arising from the application or use of any product or system described

herein; nor any liability for incidental or consequential damages arising from the use

of this manual. PFU LIMITED disclaims all warranties regarding the information

contained herein, whether expressed, implied, or statutory.

PFU LIMITED reserves the right to make changes to any products herein, to

improve reliability, function, or design, without further notice and without obligation.

●ix

■ Preface

Safety Precautions

This manual describes important details for ensuring the safe and correct use of

this product. Thoroughly read this manual before you start to use this product. In

particular, be sure to read and fully understand the Safety Precautions described in

this manual before you use this product.

Also, store this manual in a safe place so that it can be easily referred to during use

of this product.

Warning Indications Used In This Manual

This manual uses the following indications to ensure safe and correct use of this

product, and to prevent possible danger and injury to the Operator and other

persons.

CAUTION

This indication alerts operators to an operation that, if not

strictly observed, may result in severe injury or death.

WARNING

This indication alerts operators to an operation that, if not

strictly observed, may result in safety hazards to personnel or

damage to equipment.
