Fujitsu Fi-4340C Manual

i-4340C Ima

e Scanne

erator's Guid

NOTICE

This manual is for fi-4340C equipped with both USB and SCSI interfaces.

Explanations related to the USB interface do not apply to fi-4340C equipped only

with SCSI interface.

Regulatory Information

■FCC declaration

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

FCC warning: Changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

NOTICE

•The use of a non-shielded interface cable with the referenced device is

prohibited. The length of the parallel interface cable must be 3 meters (10 feet)

or less. The length of the serial interface cable must be 15 meters (50 feet) or

less.

•The length of the power cord must be 3 meters (10 feet) or less.

Edition Date published Revised contents

01 October, 2001 First edition

02 March, 2003 Second edition

03 August, 2003 Third edition

04 October, 2004 Fourth edition

06 June, 2006 Sixth edition

Specification No. P3PC-E832-06EN

Revisions, Disclaimers

■Canadian DOC Regulations

This digital apparatus does not exceed the Class B limit for radio noise emissions

from digital apparatus set out in the Radio interference Regulations of the Canadian

Department of Communications.

This Class B digital apparatus complies with Canadian ICES-003.

Le présent appareil numérique pas de bruits radioélectriques dépassant les limites

applicables aux appareils numériques de la classe B prescridtes dans le

Réglesment sur le brouillage radioélectrique dicté par le ministere des

Communications du Canada.

Cet appareil numérique de la classe B est conformme à la norme NMB-003 du

Canada.

■Bescheimigung des Herstellers / Importeurs

Für den fi-4340C wird folgendes bescheinigt:

•In Übereinsstimmung mit den Bestimmungen der EN45014(CE) funkentstört

•Maschinenlärminformationsverordnung 3.GPSGV: Der höchste

Schalldruckpegel beträgt 70 dB (A) oder weniger, gemäß EN ISO 7779.

■International ENERGY STAR® Program

As an ENERGY STAR® Partner, PFU LIMITED has

determined that this product meets the ENERGY STAR®

guidelines for energy efficiency.

The International ENERGY STAR® Office Equipment

Program is an international program that promotes energy

saving through the penetration of energy efficient

computers and other office equipment. The program backs

the development and dissemination of products with

functions that effectively reduce energy consumption. It is

an open system in which business proprietors can

participate voluntarily. The targeted products are office equipment such as

computers, monitors, printers, facsimiles, copiers, scanners, and multifunction

devices. Their standards and logos are uniform among participating nations.

iii

■Use in High-safety Applications

This product has been designed and manufactured on the assumption that it will be

used in office, personal, domestic, regular industrial, and general-purpose

applications. It has not been designed and manufactured for use in applications

(simply called "high-safety applications" from here on) that directly involve danger to

life and health when a high degree of safety is required, for example, in the control

of nuclear reactions at nuclear power facilities, automatic flight control of aircraft, air

traffic control, operation control in mass-transport systems, medical equipment for

sustaining life, and missile firing control in weapons systems, and when

provisionally the safety in question is not ensured. The user shall use this product

with adopting measures for ensuring safety in such high-safety applications. PFU

LIMITED assumes no liability whatsoever for damages arising from use of this

product by the user in high-safety applications, and for any claims or compensation

for damages by the user or a third party.

■About the use of mercury

To avoid unexpected injury, read the following carefully.

Doing the following actions may result in serious personal injuries:

•Do not put the substance contained in the lamp in your mouth as it has

mercury

•Do not incinerate, crush, or shred the lamps or scanner parts.

•Do not breathe the chemical liquid contained in the scanner lamps.

■Copying

Copying of paper money, coins, securities and passports issued by government

authorities, licenses and permits issued by public authorities and private

organizations, official documents, and private documents etc. is illegal and is

subject to punishment.

■Copyright

photographs may be copied only for private or home use, or for similar applications.

Copying for other applications without the consent of the holder of the copyright is

illegal.

Lamp(s) inside this product contain mercury and must

be recycled or disposed of according to local, state, or

federal laws.

■Trademarks

Microsoft, Windows, and Windows NT are registered trademarks of the Microsoft

Corporation in the United States and/or other countries.

ISIS and QuickScan are trademarks or registered trademarks of EMC Corporation in

the United States.

Adobe, the Adobe logo, and Acrobat are either registered trademarks of Adobe

Systems Incorporated in the United States and/or other countries.

Other product names are the trademarks or registered trademarks of the respective

companies.

■How Trademarks Are Indicated In This Manual

References to Operating systems (OS) are indicated as follows:

Where there is no distinction between the different versions of the above operating

system, the general term “Windos “ is used.

■Manufacturer

PFU LIMITED

Image Products Sales Dept., Imaging Products Division, Products Group

Solid Square East Tower, 580 Horikawa-cho, Saiwai-ku, Kawasaki-shi Kanagawa

212-88563, Japan

Phone : (81-44) 540-4538

The contentss of this manual may be revised without prior notice.

No part of this manual may be reproduced in any form without permission.
