1–5MMDS0508 Target Interface

General Description

1.1 Introduction

The M68MMDS05/08 Motorola Modular Development System (MMDS) is a tool for

developing embedded systems based on an MC68HC05 or MC68HC08

microcontroller unit (MCU). A modular emulation system, the MMDS provides

interactive control of a microcontroller application when connected to your target

system.

The MMDS environment allows for source-level debugging and simplifies writing

and debugging code. These features significantly reduce development time.

A complete MMDS includes a station module, an emulation module (EM), and a

target cable assembly. The EM completes MMDS functionality for a particular MCU

or MCU family.

1.2 MMDS Features

MMDS features include:

• Real-time, non-intrusive, in-circuit emulation

• Real-time bus state analysis

• MC68HC11K1 system controller, for fast command transfer

• Compliance with ECC92 European electromagnetic compatibility standards

• Four complex data breakpoints, each qualified by an address, an address range,

data, or externally connected logic clips.

• 32 variables or real-time variables, plus a 32-byte block of real-time memory,

mappable anywhere within a 1-kilobyte window over the 64-kilobyte HC05/HC08

memory map.

•64 kilobytes of emulation memory, to accommodate the largest available ROM

size of current HC05/HC08 MCUs.

Freescale Semiconductor, Inc.

For More Information: www.freescale.com

General Description

System Components

1–6 MMDS0508 Target Interface

• 64 hardware instruction breakpoints over the 64-kilobyte memory map

• A personality file for each EM. (Each personality file defines a memory-map.)

• Latch-up resistant design (47-Ωseries resistor on I/O connections to the target

system) to make power-up sequencing unimportant.

• Built-in bus state analyzer that includes:

• 8K x 64 real-time trace buffer

– Four hardware triggers, for controlling real-time bus analysis and to

provide breakpoints

– Nine triggering modes

– Display of real-time trace data as raw data, disassembled instructions, raw

data and disassembled instructions, or assembly-language source code

– As many as 8190 pre- or post-trigger points

– Trace buffer that can be filled as you single-stepping through user software

– 16-bit time tag, or an optional 24-bit time tag that sacrifices eight logic

clips

– Eight software selections for the time tag clock source, permitting wide

time variance between analyzer events

– 16 general-purpose logic clips, five of which can be used to trigger the bus

state analyzer sequencer

• Four software-selectable internally generated oscillator clock sources

• Built-in power supply with 85 to 264 VAC input

• RS-232 operation speeds as high as 57600 baud

• Compact size: 15.38 inches (390.6 mm) deep, 10.19 inches (258.83 mm) wide, and

2.75 inches (69.85 mm) high. The station module weighs 6.0 pounds (2.72 kg).

For connection instructions, configuration instructions, and other related information,

see the installation section of this hardware addendum. For similar information with

regard to EMs, see the corresponding EM user's manual.

1.3 System Components

The MMDS components include:

•Station module: the MMDS enclosure, containing the platform board and the

internal power supply. The access panel in the enclosure top lets you insert an EM

easily.

Freescale Semiconductor, Inc.

For More Information: www.freescale.com

General Description

System Components

1–7MMDS0508 Target Interface

•9-lead RS-232 serial cable: the cable that connects the station module to the host-

computer RS-232 port.

•Serial adapter: a DB9M-to-DB25F RS-232 adapter, for use with a 25-pin host-

computer serial port.

•Two logic clip cable assemblies: twisted-pair cables that connect the station

module to your target system, a test fixture, a clock, an oscillator, or any other

circuitry useful for evaluation or analysis. One end of each cable assembly has a

molded connector, which fits into the pod A or pod B connector of the station

module. Leads at the other end of each cable terminate in female probe tips. Ball

clips come with the cables.

Separately purchased components are:

•Emulation module (EM): a printed circuit board that completes MMDS

functionality for one or more MCUs. The two DIN connectors on the bottom of the

EM fit into connectors on the top of the MMDS0508 platform board, providing

power and signal connections. The EM also has a connector for the target cable.

Each EM comes with its own user’s manual.

•Target cable: a flat, flexible cable that connects the MMDS to the target system.

The cable’s emulator terminator mates to the EM target connectors; the cable’s

head terminator mates to a target head adapter. (A target cable and target head

adapter make up a target cable assembly.)

•Target head adapter: a target-cable adapter that plugs into the MCU socket of the

target system. (For some EMs, the target head adapter plugs into a surface-mount

adapter.)

Freescale Semiconductor, Inc.

For More Information: www.freescale.com

General Description

System Components

1–8 MMDS0508 Target Interface

Freescale Semiconductor, Inc.

For More Information: www.freescale.com

2–9MMDS0508 Target Interface

Installation

2.1 Introduction

Complete MMDS installation consists of:

• Configuring the platform board,

• Configuring the emulation module (EM),

• Installing the EM, and

• Making system cable connections.

This section explains all items except EM configuration. (As EM configuration is

specific to each EM, you must follow the instructions of your EM user's manual.)

Additionally, this sections explains how to remove an EM from the station module.

Figure 2.1 shows the right side of the MMDS station module, with the access panel

open. Callouts indicate the reset switch and power LED (on the front of the station

module), and the logic cable A and B connectors (on the right side of the station

module). (Alternate names for the logic cable connectors are pod A and pod B.) If you

use logic clip cables, always attach the black clip to ground.

Figure 2.2 shows the left side of the station module, with the access panel closed.

Callouts indicate the power cord socket, the power switch, and the 9-pin RS-232 serial

connector. The circular, +5 V out connector is reserved for possible future features. (A

spacer covers the final enclosure cutout, for a future connector.)

Freescale Semiconductor, Inc.

For More Information: www.freescale.com

Installation

Introduction

2–10 MMDS0508 Target Interface

Figure 2.1 M68MMDS0508 Station Module (Right Side)

Freescale Semiconductor, Inc.

For More Information: www.freescale.com

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de computadora de Freescale Semiconductor

Freescale Semiconductor

Freescale Semiconductor PowerQUICC III MPC8555E Manual de instrucciones

Freescale Semiconductor

Freescale Semiconductor M68HC08 series Manual de usuario

Freescale Semiconductor

Freescale Semiconductor KW2xDxxx Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MSC8144ADS Manual de usuario

Freescale Semiconductor

Freescale Semiconductor FRDM-STBC-SA9500 Guía de referencia

Freescale Semiconductor

Freescale Semiconductor 802.15.4/Zigbee Manual de usuario

Freescale Semiconductor

Freescale Semiconductor TWR-VF65GS10 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor TWR-PXD20 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor 1322x-USB Dongle Manual de usuario

Freescale Semiconductor

Freescale Semiconductor PowerQUICC III Instrucciones de instalación y funcionamiento

Freescale Semiconductor

Freescale Semiconductor Motorola MMDS0508 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor FRDM-K64F Manual de usuario

Freescale Semiconductor

Freescale Semiconductor Windows Embedded CE 6.0/Windows CE 5.0 i.MX31 PDK... Manual de usuario

Freescale Semiconductor

Freescale Semiconductor USB-KW24D512 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor TWR-S12G64 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor e200z3 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MCF5329 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor ColdFire MCF52210ColdFire MCF52211ColdFire MCF52212ColdFire... Manual de usuario

Freescale Semiconductor

Freescale Semiconductor TWR-MCF51QM Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MC68HC908MR16 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MPC8569E-MDS-PB Manual de usuario

Freescale Semiconductor

Freescale Semiconductor i.MX53 SABRE Manual de usuario

Freescale Semiconductor

Freescale Semiconductor i.MX 6Solo Manual de usuario

Freescale Semiconductor

Freescale Semiconductor TWR-K64F120M Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
