Freescale Semiconductor I.MX35 Manual de usuario

i.MX35 PDK 1.5 Linux Quick Start Guide

Standard Base

Doc Number: 926-78233

Rev. 1.5

04/2009

How to Reach Us:

Home Page:

www.freescale.com

Web Support:

http://www.freescale.com/support

USA/Europe or Locations Not Listed:

Freescale Semiconductor

Technical Information Center, EL516

2100 East Elliot Road

Tempe, Arizona 85284

+1-800-521-6274 or +1-480-768-2130

www.freescale.com/support

Europe, Middle East, and Africa:

Freescale Halbleiter Deutschland GmbH

Technical Information Center

Schatzbogen 7

81829 Muenchen, Germany

+44 1296 380 456 (English)

+46 8 52200080 (English)

+49 89 92103 559 (German)

+33 1 69 35 48 48 (French)

www.freescale.com/support

Japan:

Freescale Semiconductor Japan Ltd.

Headquarters

ARCO Tower 15F

1-8-1, Shimo-Meguro, Meguro-ku,

Tokyo 153-0064, Japan

0120 191014 or +81 3 5437 9125

support.japan@freescale.com

Asia/Pacific:

Freescale Semiconductor China Ltd.

Exchange Building 23F

No. 118 Jianguo Road

Chaoyang District

Beijing 100022

China

+86 010 5879 8000

support.asia@freescale.com

For Literature Requests Only:

Freescale Semiconductor Literature Distribution Center

P.O. Box 5405

Denver, Colorado 80217

1-800-441-2447 or 303-675-2140

Fax: 303-675-2150

LDCForFreescaleSe[email protected]

Information in this document is provided solely to enable system and software

implementers to use Freescale Semiconductor products. There are no express or

implied copyright licenses granted hereunder to design or fabricate any integrated

circuits or integrated circuits based on the information in this document.

Freescale Semiconductor reserves the right to make changes without further notice to

any products herein. Freescale Semiconductor makes no warranty, representation or

guarantee regarding the suitability of its products for any particular purpose, nor does

Freescale Semiconductor assume any liability arising out of the application or use of

any product or circuit, and specifically disclaims any and all liability, including without

limitation consequential or incidental damages. "Typical" parameters that may be

provided in Freescale Semiconductor data sheets and/or specifications can and do

vary in different applications and actual performance may vary over time. All operating

parameters, including "Typicals", must be validated for each customer application by

customer’s technical experts. Freescale Semiconductor does not convey any license

under its patent rights nor the rights of others. Freescale Semiconductor products are

not designed, intended, or authorized for use as components in systems intended for

surgical implant into the body, or other applications intended to support or sustain life,

or for any other application in which the failure of the Freescale Semiconductor product

could create a situation where personal injury or death may occur. Should Buyer

purchase or use Freescale Semiconductor products for any such unintended or

unauthorized application, Buyer shall indemnify and hold Freescale Semiconductor and

its officers, employees, subsidiaries, affiliates, and distributors harmless against all

claims, costs, damages, and expenses, and reasonable attorney fees arising out of,

directly or indirectly, any claim of personal injury or death associated with such

unintended or unauthorized use, even if such claim alleges that Freescale

Semiconductor was negligent regarding the design or manufacture of the part.

Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc.

All other product or service names are the property of their respective owners.

Freescale Semiconductor i.MX35 PDK 1.5 Linux Quick Start Guide, Rev 1.5 iii

Chapter 1 About the Boards................................................................................ 1-1

1.1 About the 3-Stack Platform System........................................................................ 1-1

1.2 CPU Board............................................................................................................ 1-4

1.3 Debug Board.......................................................................................................... 1-5

1.4 Personality Board................................................................................................... 1-9

Chapter 2 Getting Started ................................................................................... 2-1

2.1 Development Kit Content....................................................................................... 2-1

2.2 Provide a Development PC..................................................................................... 2-3

Chapter 3 Building the Platform ......................................................................... 3-1

3.1 Building a Development Platform: Assemble 3 Boards ........................................... 3-2

3.1.1 Connect Personality Board to Debug Board........................................................... 3-2

3.1.2 Connect CPU Board to Personality Board.............................................................. 3-3

3.2 Connect Development Platform to PC; Run Preloaded Image................................. 3-4

3.3 Building a Demo Platform: Assemble Two Boards................................................. 3-5

Chapter 4 Using the Linux Demo Image.............................................................. 4-1

4.1 Downloading Multimedia to the PDK..................................................................... 4-1

4.2 Using an SD Card .................................................................................................. 4-3

4.3 Running the Applications ....................................................................................... 4-4

4.3.1 Running the Video Application............................................................................... 4-4

4.3.2 Running the Audio Application .............................................................................. 4-4

4.3.3 Running the Picture Viewer Application................................................................. 4-5

4.3.4 Running the FM Radio Application ........................................................................ 4-5

4.4 Supported Codecs.................................................................................................. 4-6

Freescale Semiconductor i.MX35 PDK 1.5 Linux Quick Start Guide, Rev 1.5 1-1

Chapter 1

About the Boards

This chapter provides detailed information about the three boards (CPU, Debug, Personality) and

identifies the locations of the connectors and switches.

1.1 About the 3-Stack Platform System

Freescale introduces the 3-Stack Platform System, which you use to develop multimedia and

connectivity applications using the i.MX35 Applications Processor and the MC13892 Audio and

Power Management device.

The 3-Stack Platform System decreases the time between first development and final product

release by providing you (as the system designer) with a near-to-final product design, which you

can use as a development platform for software and hardware.

There are two Board Support Packages (BSP) for the 3-Stack Platform System, with one BSP for

Windows® and one BSP for Linux operating systems. These BSPs contain drivers optimized for

multimedia operations using the i.MX35 and MC13892 devices.

Freescale's 3-Stack Platform System consists of three small boards: CPU, Debug, and Personality.

•A CPU board contains the i.MX35 CPU, memories and the MC13892 Power

Management IC (PMIC).

•A Debug board provides the debug interfaces (like JTAG), and also has a CPLD that

implements an external Ethernet and serial controller for debug purposes.

•The Personality board implements the functionality of the 3-Stack board system, and

contains hardware to demonstrate most of the i.MX35 chip functionality.. The Personality

board can be modified to meet your specific requirements without the need to modify the

other two boards (CPU, Debug The Personality board was designed to support common

multimedia applications, and has a 7-inch WVGA display, image sensor camera, FM

receiver, SD Card connector, USB OTG, USB Host, ATA connector and TV-Out

connector, as well as additional functionality, which is described in this document.

i.MX35 PDK 1.5 Linux Quick Start Guide, Rev 1.5 Freescale Semiconductor

1-2

Table 1.1 describes the 3-Stack Platform in detail.

Table 1.1 3-Stack Platform Features

Item Description

All boards •Near to final product form-factor demonstration modules and

working platforms

•Solid reference schematics that closely resemble final products

to aid customers' designs

CPU board •i.MX35 ARM11™ Applications Processor

•MC13892 Atlas power management chip

•512MB of Flash Memory

•512MB of 32 bit DDR2 memory

•69.85mm x 69.85 mm

Personality board •Peripheral components

•Interface connectors

•177.62mm x 132mm

Debug board •Two RS-232 interfaces (only one is populated)

•10/100 Base-T Ethernet connector

•Current measure connectors

•71.400 mm x 174.900 mm

Battery Support +4.2 V 2400mAh Battery power supply and Battery Charging

Function

LCD Display 7 inch TFTLCD display panel with touch panel and LED backlight

Camera Interface Image sensor camera connector

Selectable Clock

Sources

System clock source of 24MHz and audio clock source of

24.567MHz

Debug Port RealView®-ICE debug support

Video and Audio Stereo Stereo microphone jack, headphone and video jack, stereo and

mono (ear piece) speaker terminals

GPS Connector One connector to outboard GPS module (GPS module not

included)

FM Receiver

PC Card Expansion SD card connectors, with card sense functionality (also supports

the MMC and MS card).

Network Support Two Ethernet jack connectors, one on personality board (for

applications) and one on debug board (for debug purposes)

Freescale Semiconductor i.MX35 PDK 1.5 Linux Quick Start Guide, Rev 1.5 1-3

USB •One USB OTG high-speed transceiver with micro-USB

connector

•One USB high-speed host transceiver, with standard USB host

connector

ATA Support ATA5-compliant controller with one 44-position dual row, 2mm

header for small form-factor disk drivers and two CE-ATA

connectors

CAN One DB9 connector for CAN bus and one 10-pin connector for

CAN bus

Expansion Connectors •One 2mm connector for MLB signal

•An audio codec header for connect audio feature card

Serial Port Two RS-232 interfaces with DB-9 connectors, one is driven by

UART channel internal to the MX35 and supports DCE with

optional full modem controls, the other is DTE with optional full

modem controls.

Cables •RS-232 standard serial cable

•Shielded microUSB to type A male cable

•Ethernet straight thru cable

Power Supply 5.0V/5.0A universal power supply kit

Software •Linux Demo Image from Freescale

•Linux BSP available from Freescale

•RedBoot boot loader from Freescale

Application Development

Tools

•Advanced Toolkit (ATK) software

•Linux Target Image Builder (LTIB)

•Linux Toolchain (included in LTIB)

i.MX35 PDK 1.5 Linux Quick Start Guide, Rev 1.5 Freescale Semiconductor

1-4

1.2 CPU Board

Figures 1-1 and 1-2 illustrate the top and bottom of the CPU Board.

Use the J1 board-to-board connector (500 pins) to connect the CPU board to either of the other

two boards:

•Connect the CPU board to a Personality board, for running demos (no Debug board is

needed to run demos that do not use serial console commands).

•Connect the CPU board to a Personality board, (and connect the Personality board to the

Debug board) for developing software. The Personality board plugs in the other side of

the Debug board.

Figure 1-2 CPU Board, top Figure 1-2 CPU Board, bottom

Freescale Semiconductor i.MX35 PDK 1.5 Linux Quick Start Guide, Rev 1.5 1-5

1.3 Debug Board

Figures 1-3 and 1-4 illustrate the top and bottom of the Debug Board.

Figure 1-3 Debug Board, Top

i.MX35 PDK 1.5 Linux Quick Start Guide, Rev 1.5 Freescale Semiconductor

1-6

Table 1.2 Debug Board Physical Features

Type Physical Features

Switches •S1: Power button

•S2: Debug board reset button

•S3: System reset switch

•S4: Power-on switch

•SW4: Enable switch

Figure 1-4 Debug Board, bottom view

Tabla de contenidos

Otros manuales de Hardware de computadora de Freescale Semiconductor

Freescale Semiconductor

Freescale Semiconductor PowerQUICC III MPC8555E Manual de instrucciones

Freescale Semiconductor

Freescale Semiconductor EVB9S12NE64 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor HC05P3 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MPC8349EA MDS Manual de usuario

Freescale Semiconductor

Freescale Semiconductor Demonstration Board DEMO9S08AC60E Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MPC8272ADS Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MC68HC08KH12 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor Motorola MMDS0508 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor TWR-VF65GS10 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor TWR-K60D100M Manual de usuario

Freescale Semiconductor

Freescale Semiconductor NXP CodeWarrior USB TAP Manual de usuario

Freescale Semiconductor

Freescale Semiconductor i.MX27 PDK 1.0 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MPC8569E-MDS-PB Manual de usuario

Freescale Semiconductor

Freescale Semiconductor FRDM-STBC-SA9500 Guía de referencia

Freescale Semiconductor

Freescale Semiconductor 1322x-USB Dongle Manual de usuario

Freescale Semiconductor

Freescale Semiconductor TWR-MCF51QM Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MPC5604P Manual de usuario

Freescale Semiconductor

Freescale Semiconductor PowerPC MPC823 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MPC5200B Manual de usuario

Freescale Semiconductor

Freescale Semiconductor TWR-K64F120M Manual de usuario

Freescale Semiconductor

Freescale Semiconductor TWR-MPC8309 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor TWR-S12G64 Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MPC8349EA PowerQUICC II Pro Manual de usuario

Freescale Semiconductor

Freescale Semiconductor MC68HC908MR16 Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario

Freescale Semiconductor i.MX35 Manual de usuario

Manuales populares de Hardware de computadora de otras marcas
