Flying Industry Development S1DA-DC09 Manual de usuario

SHENZHENGUIYUANINDUSTRYDEVELOPMENTCO.,LTD

Http://www.

carymart

.com

Mail:sale@

carymart

.com

RFWireless Remote Control RadioController/ Transmitter& Receiver

PackageInclude:

1xReceiver: S1DA-DC09 /S1DA-DC12 / S1DA-DC24 (1 Channel/ DelayControlMode)

2xTransmitter: C-2

1xUser manual

Feature:

Wireless control,easy toinstall

Adjustabledelay time: 0seconds ~99 hours

ControlLights,Motors,Fans, electricallyoperated Doors/ Locks/Windows/ Blinds/Cars orOtherAppliances.

You canturnon/offthereceiver withtransmitter (remotecontrol)fromanyplacewithinareliabledistance;thewirelesssignalcanpass through

walls, floors and doors.

Withcharacteristics of reversepower protection and over currentprotection

Audible/ visualindication

Usemicrocontroller modelof EM78P156, an 8-bitmicroprocessor designed and developed withlow-power and high-speed CMOS technology.

UseULN2003 todriverelay, withstrong anti-interference.

Reliablecontrol: The transmitter (Encoding) and the receiver (Decoding) usean8-bitcode.

One/severaltransmitterscan controlone/severalreceiverssimultaneously.

If you usetwoor more receiversinthe sameplace, you can setthemwithdifferentcodes.

Transmitting Frequency: 315MHz /433MHz

Receiver:

ModelNo.: S1DA-DC09 /S1DA-DC12 / S1DA-DC24

Channel: 1CH

ControlMode: Delay(Press ->ON;ThenOFFafter thedelaytime)

Adjustabledelay time: 0seconds ~99 hours

Coding Type: Fixed code or Learning code

Coding Setting:Bylearning

Power Supply(Operating Voltage): DC12V 1V (S1DA-DC12), DC9V 1V (S1DA-DC09), DC24V 1V (S1DA-DC24)

Working Voltage Range of Relay:AC110~240V or DC0~28V

PCBsize:93.5mm x73mm x27mm

Casesize: 100mm x77mm x30mm

MaximumWorkingCurrent: 10A

Transmitter:

ModelNo.: C-2

Channel: 2CH

RemoteControlDistance: 100m/ 300ft (theoretically)

Encode:Fixed code by soldering

Unitsize: 58mm x39mm x16mm

Power Supply: 1x23A-12V battery(Included,canbe used for12 months)

Usage:

Initialstate:A,B =NormallyClosed; B, C=NormallyOpen.

Press button 1:Turn on relay(connect B andC,disconnectAand B).

Afterdelaytime:Turn off relayby itself (disconnectBand C,connectA and B).

Press button 2:Turn off relayimmediately, no needtowaitfor delay time.

Press buttonsof “”and “－”on the timer,adjust delay timefrom0second to99hours. “H”is Hour, “M”is Minute,and “S”isSecond.

For example,ifyou set “S01”,itmeansthe delay timeis 1second.

Wehavelearned remotecontroltothe receiver. If you don’t wantthe receiver towork withtheremotecontrol, you can deleteallcodesofremote

controls,whichare stored inthe receiver.

Operation:Press andholdthe button of receiver untilsignalLEDflashesslowly; releasethe button,LEDkeeps slowflash.That meansallstored

codeshavebeen deleted successfully.

Learning the button ofremotecontrol:

1) Pressthe button of receiver;signalLEDonthe receiver keepsshining.Thereceiver enters intostatus ofLEARNING.

2) Press anyone buttonon remotecontrol.IfsignalLEDflashesquickly15 times and turnsoff,it means learning issuccessful.

3) Whenreceiver is inthestatus of LEARNING, pressagainthe button of receiver, signalLEDturns off, learning process will be discontinued.

4) The receiver can learn severalremotecontrols withdifferent codes.

SHENZHENGUIYUANINDUSTRYDEVELOPMENTCO.,LTD

Http://www.

carymart

.com

Mail:sale@

carymart

.com

Application Circuit

A, B=NormallyClosed;B, C=NormallyOpen.

Button

DC0~28V/AC110~240V

Lamp

Relay

Antenna

RFmodule

LED

SignalLED

PowerLED

Powersupply

Timer
