1Introduction
Dear Customer,
Thank you for choosing FELIXprinters!
To get your Felix 3D printer up and running as fast and painlessly as
possible please follow this manual carefully. Please don’t take any
shortcuts. It’s better to spend a few minutes extra on reading, than to
wait a week for new parts.
When things are unclear or if you have any remarks or tips, please
contact us:
Website: www.felixprinters.com/support
Email: support@felixprinters.com
Telephone: +31 (0)30 30 31 387
Address: Zeemanlaan 15, 3401MV IJsselstein, The Netherlands
We also recommend looking on our forum and getting yourself a forum
account. You will benefit from the ability to get downloadable and
printable upgrades for your printer. Also it is a great source to obtain
and share knowledge about your 3D printer and 3D printing in general.
Have fun building!
Kind regards,
FELIXprinters
2Contents
1Introduction...................................................................................................................................1
3Required Tools ............................................................................................................................2
4Frame assembly ........................................................................................................................3
5Z-axis ..................................................................................................................................................5
6X-axis ................................................................................................................................................. 8
7Y-axis ................................................................................................................................................12
8Extruder assembly .................................................................................................................16
8.1 For Single head assembly ......................................................................................16
9Extruder assembly .................................................................................................................19
9.1 For Dual head assembly..........................................................................................19
10 Wiring.............................................................................................................................................22
11 Upload Firmware ...................................................................................................................27
12 Functional Test ........................................................................................................................28
13 Finishing Touches .................................................................................................................30
14 Checklist .......................................................................................................................................32
15 Bill Of Materials........................................................................................................................34
15.1FELIX 3.2 DIY Kit - Base parts - 105 014.1 ......................................................34
15.2 FELIX 3.2 Single to Dual Upgrade Kit - 105 031.0...................................38
15.3 Set Plastic parts Felix 3.2 - 105 047.1................................................................39
