Felix Storch 3.1 Single Manual de usuario

Assembly manual for:

FELIX 3.1 Single

FELIX 3.1 Dual

This document contains proprietary information that is protected by copyright.

no part of this document may be photocopied, reproduced, or translated to another language with-

out the prior written consent of FELIXrobotics BV.

Felixrobotics BV

FELIX 3.1

assembly manual

Before you start

Assembly Manual FELIX 3.1 V1

INDEX:

Description: Steps: Page:

Required tools 5

Frame 1 - 8 6

Z-axis 9 - 28 8

X-axis 29 - 41 11

Extruder 42 - 59 15

Y-axis and printbed 60 - 80 23

Handle 81 - 83 27

Electronics Box 84 - 92 28

Wiring 93 - 102 30

Display 103 - 113 34

BOM (Bill of Materials) 37

Assembly Manual FELIX 3.1 V1

Required tools:

Rubber hammer

Assembly Manual FELIX 3.1 V1 6

MODULE 1: FRAME 10-30 MINUTES

Tools:

Step 1 / 8

12x Bolt M8 x 20

2x Frameconnector

pro le 4

2pro le 1

Pro le:

423

Bolt M8 x 20

Frameconnector

!holes

Holes

Pro le 4

Pro le 1

160 mm

Pro le 4

hole

Assembly Manual FELIX 3.1 V1 7

42x Bolt M8 x 20

2x Frameconnector

2x pro le 2

160 mm

!Holes

Pro le 2

62x Bolt M8 x 20

2x Frameconnector

1x pro le 3

Pro le 3

!Make sure everything is perpendicular and

aligned.

84x End cap square

1x End cap rectangle

The frame is now ﬁ nished.

Pro le 4

Pro le 1

Assembly Manual FELIX 3.1 V1 8

MODULE 2: Z-AXIS 45-90 MINUTES Step 9 / 28

Tools:

94x CSK bolt M3x8

1x Motor

1x Z-axis motor bracket

Label end of the wire

with the letter: Z

Example mounting T-slots:

Cable orientation

10 2x M4 T-slot 11 2x Bolt M4x20

2x Small washer M4

Assembly Manual FELIX 3.1 V1 9

Make sure the plastic part

properly touches the frame! !

Don’t let the cart run off the rail!!

13 3x M4 T-slot

1x Hiwin lineair ball bearing set

HGW15CC1R300Z0

3x Bolt M4x20

15 1x Z-axis lift part

1x Hexagon nut

10mm 10mm between rail

and plastic!

12mm from side rail

to side frame!

Assembly Manual FELIX 3.1 V1 10

16 2x Bolt M4x40

2x Locknut M4 17

Put the bolts in place in

the plastic part by pulling

the bolts.

19 2x Bolt M4x25

4x Bearing

2x Small washer M4

Remove the bolts M4x40

21 4x Bolt M5x16

4x Small washer M5

Assembly Manual FELIX 3.1 V1 11

23 4x CSK bolt M3x8

1x Motor

1x pulley

1x Set screw M3x6

Label end of the wire with the letter: Y

Wire orientation!

Distance pulley to motor face = 1-2mm

25 1x Spindle

26 1x Set screw M3x6

Hole for set screw

27 1x Z-axis limitswitch vane

1x Bolt M4x25

1x Square nut M4

1x Selﬂ ocking nut M4

28 1x Bolt M4x20

1x Small washer M4

1x M4 t-slot

The Z-axis is

ﬁ nished.

Put some grease

on the spindle,

for example ball

bearing grease.
