FeiYu Tech VLOG Pocket Manual de usuario
Instructions
EN V 1.2
Foldable Smartphone Gimbal
Catalogue
1. Overview 1
2
2
3
3
5
5
6
7
2. Start to Use
3. Function Operation
3.1 Function / Modes Introduction
3.2 Function Button Operation
3.3 Shutter Button Operation
2.1 Fold and Unfold
2.2 Charging
2.3 Smartphone Installation
11
11
11
5. Download and Connect App
5.1 Download the App
5.2 Connect the App
10
4. Gimbal Initialization
12
12
5.3 Shooting / control interface
5.4 Firmware Upgrade
13
6. Specifications
3.4 Trigger Button Operation
3.5. Landscape and Portrait Shot Switching
3.6 Light Indicator
8
8
9
2.4 Power on / off 4
2.5 Landscape Switching 4
Suggestion
Download the Feiyu ON App
Vlog pocket includes below information, please read the information before using
the gimbal
The tutorial videos can be watched at FeiyuTech official website
or scan the QR code as below: http://www.feiyu-tech.com/play/
Please download Feiyu ON at your smartphone app store or can the QR code below.
1. Quick start guide
2. Online instruction
3. Tutorial
iOS Version Android Version
* Requires iOS 9.0 or later, Android 6.0 or later.
VLOG pocket is a three-axis handheld gimbal suitable for mobile phones. It is
small and foldable which can be folded into a pocket. The gimbal supports
landscape and portrait shooting, which can also control phone shooting.
1. Overview
Accessories
01
www.feiyu-tech.com
X1X1
TripodMicro-USB Cable
12
13
9
14
16
10
17
1
2
5
13
4
11
8
3
15
6
7
12. Tilt axis clamp
13. Pan axis clamp
14. Micro-USB port
5. Tilt axis 17. Status indicator11. Roll axis clamp
8. Vertical arm
15. Handle3. Trigger button 9. Folding knob
1. Function button
2. Shutter button
10. Smartphone holder4. Roll axis 16. 1/4 inch thread hole
6. Pan axis
7. Cross arm
*This product does not include the smartphone
!
02
www.feiyu-tech.com
(1) Please fully charge the battery before powering on the gimbal for the first time.
(2) If the power is too low, the red light will flash three times every five seconds that
indicating you should charge it immediately.
(3) When not in use, power off the gimbal.
(4) Unlock the three axis clamp before powering on the gimbal.
(5) Landscape to mount smartphone.
TIPS
2. Start to Use
Folded status
Unfolded status
2.1. Fold and Unfold
(1) Loosen the folding knob and tighten the knob after unfolding
the vertical arm.
(2) Unlock the three axis clamp.
(1) Lock the three axis clamp.
(2) Loosen the folding knob, and then tighten the knob after folding
the vertical arm.
Unfold
Fold
Unlock status
Take the pan axis clamp for example.
Lock status
Unlock / Lock the clamp
Charge complete
Installation complete
Charging
Connect the USB cable to charge. The indicator light is red when charging, and
green when fully charged.
2.2 Charging
2.3 Smartphone Installation
It is recommended to remove the smartphone case before installation and keep
the logo of the smartphone holder upward.
Keep the smartphone holder in center.
03
www.feiyu-tech.com
keep upward
Front holding Upside down holding Wrong operation
Press and hold
the Trigger button
Holding the gimbal, press and hold the trigger button, turn the handle forward to
the inverted holding, and release the trigger button after adjusting the phone to the
appropriate angle. Upside-down handheld can be used to take low angle pictures.
Double click trigger button is recommended before operating the landscape mode.
Please do not rotate the gimbal from your right side to upside down position.
04
www.feiyu-tech.com
Turn on the smartphone only after it is installed securely.
Unlock the three axis clamp before powering on the gimbal.
Long time press the function button and release it when you hear
the tone.
Long time press the function button and release it when you hear
the tone.
Long time press
Power off
Power on
2.4 Power on / off
2.5 Landscape Switching
(Green light will change to blue)
(The red light will turn off)
05
www.feiyu-tech.com
3.1 Function / Modes Introduction
3. Function Operation
Panning Mode（Default mode）
Lock Mode
Follow Mode
The roll direction is fixed, and the smartphone moves according to the left-right
movements, up-down movements of the user's hand.
The roll and tilt direction are fixed, and the smartphone moves according to the
left-right movements of the user's hand.
The orientation of the camera is fixed.
Panning Mode
Single click the
function button
Follow and
rotate
Follow and
rotate
Default mode Lock Mode Follow Mode
Click again the
function button
Press and hold the
Shortcut button
Reset
Manual Lock
Return to panning mode, three axises return to default position.
Slide the tilt axis to one position for shooting.
Landscape and Portrait Shot
Assist landscape or portrait shooting.
Lock the
position
06
www.feiyu-tech.com
3.2 Function Button Operation
Function Button
Status Indicator
Single click
Click again
Click once Panning Mode
Lock Mode
Keep current status
Function
button Function
Double click Landscape and portrait shot switching
Five click
Long time
press Power on / off
Power on
Power off
Gimbal Initialization
( Single click the function button to wake up )
07
www.feiyu-tech.com
Bluetooth connection
Connect Smartphone
3.3 Shutter Button Operation
（1）Power on VLOG pocket, open smartphone bluetooth.
（2）Choose below Bluetooth connection way:
a. Choose VLOG pocket Bluetooth to connect like FY_PocketV_xx.
b. Open Feiyu ON app, logon or register via tips to connect.
（3）After Bluetooth connecting successful, the shutter button is activated.
The gimbal can control the photography after only Bluetooth is connected with smartphone.
Shutter Button
Single
click
Double click
Photography
Video
( Click again to finished the video )
Switch to photo / video mode
Shutter
Button Function Control
the App Control smartphone
camera
via bluetoothFeiyu ON
Triple click Switch front and rear camera
Long time
press
Video recording in shooting mode
*
*We suggest close Feiyu ON App when you control smartphone camera.
The green light flashes once while other indicator status (About every 5 seconds flashes once)
( Long press the shutter button again to
end the recording )
