Elo TouchSystems 2794L Manual de usuario

USER MANUAL

Elo Touch Solutions

90 Series Open Frame Touchscreen

User Manual: 90 Series RevB

UM600129 Rev E, page 1 of 28

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or

by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of Elo Touch Solutions, Inc.

Disclaimer

The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Affiliates (collectively “Elo”) makes no representations or warranties

with respect to the contents herein, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose. Elo reserves the right to

revise this publication and to make changes from time to time in the content hereof without obligation of Elo to notify any person of such revisions or changes.

TrademarkAcknowledgments

Elo, Elo (logo), Elo Touch,Elo TouchSolutions, andIntelliTouch are trademarks of Elo and its Affiliates. Windows is a trademark

of Microsoft Corporation.

User Manual: 90 Series RevB

UM600129 Rev E, page 2 of 28

Table of Contents

Section 1: Introduction ............................................................................................................................................................................................................................. 4

Section 2: Installation............................................................................................................................................................................................................................... 4

Section 3: Mounting ................................................................................................................................................................................................................................. 7

Section 4: Operation ................................................................................................................................................................................................................................ 9

Section 5: Technical Support.................................................................................................................................................................................................................. 14

Section 6: Safety & Maintenance........................................................................................................................................................................................................... 16

Section 7: Regulatory Information.......................................................................................................................................................................................................... 17

Section 8: Warranty Information............................................................................................................................................................................................................. 21

User Manual: 90 Series RevB

UM600129 Rev E, page 3 of 28

Section 1: Introduction

Product Description

Your new touchscreen display combines Elo’s latest developments in touch technology and display design with the reliability for use in

high-traffic environment.

This touchscreen incorporates a 24-bit color, active matrix thin-film-transistor LCD panel to provide high quality display performance. The

90 Series offers sizes that range from 10.1-inch to 27 -inch and resolutions that range from 800x600 to Full HD 1920x1080. The LED

backlight significantly reduces power consumption and eliminates mercury (compared to CCFL-backlit panels). Other features that

enhance this LCD monitor’s display performance are Plug & Play compatibility, remote on-screen display (OSD) controls and flexible

mounting options.

Precautions

Follow all warnings, precautions and maintenance as recommended in this user manual to maximize the life ofyour

unit and prevent risks to user safety. See the Safety & Maintenance Section for more information.

This manual contains information that is important for the proper setup and maintenance of the unit. Before setting up and powering

on your new touchscreen, read through this manual, especially the Installation, Mounting, and Operation Sections.

User Manual: 90 Series RevB

UM600129 Rev E, page 4 of 28

Section 2: Installation

Unpacking the Touchscreen Display

Open the carton and verify that the following items arepresent:

•

Japanese language regulatory informationpamphlet

•

Quick Install Guide

•

HDMI cable

•

EEI label

•

VGA cable

•

USB cable

•

Mounting brackets

•

OSD remote

User Manual: 90 Series RevB

UM600129 Rev E, page 5 of 28

Connector Panel & Interfaces

*Please note the COM (Serial) port for touch is only applicable for EXX9XL-XCXX models and removed for the rest models.

With COM (Serial) port

Without COM (Serial) port

Touchscreen Display Connections

Connect the HDMI/DP/VGA video cables between the monitor’s HDMI/DP/VGA input connectors and

your HDMI/DP/VGA video source. Tighten the video cable’s screws for best performance on VGA

connector.

Connect the USB touch cable between the monitor’s USB connector and your PC’s USB port.

* Or Connect the Serial touch cable between the monitor’s COM (Serial) connector and your PC’s COM (Serial) port. (Only applicable for EXX9XL-XCXX

models)

Connect a 12VDC power supply to the monitor’s input power jack.

The touchscreen display ships in an ON state, video should be displayed on your monitor already.

User Manual: 90 Series RevB

UM600129 Rev E, page 6 of 28

Installing the Touch Technology Software Drivers

No additional drivers are required for your projected-capacitive touchscreen displays with Windows 7 ,8.1 and 10 or later operating systems, it uses Windows HID

drivers. If the monitor is used with Windows XP operating system, follow below steps to install Windows XP touch driver.

Todownload the latest touch drivers

Visitwww.elotouch.com/Support/Downloads/Driver/DriverDownload/Default.aspx

Select the “Touch Drivers” from “Product Category” dropdown menu.

Select the “Operating System”from “Operating System” dropdown menu.

Click on the driver version required for your touchscreen display.

User Manual: 90 Series RevB

UM600129 Rev E, page 7 of 28

Section 3: Mounting

Flush Mount

Flush-mount Bracket Installation Notes:

Bracket shape varies for each model, drawing for illustration purposes

only.See dimensional drawing for exactdimensions.

Attach bracket “A” Totouchscreen display (all four sides) with M4 screws(included)

Attach bracket “C’ to customer panel per drawing (all four sides)

Attach bracket “B” to bracket “C” on all four sides with M4 screws (included)

Adjust depth of bracket “B” so monitor is flush with customer panel

Place touchscreen display into customer panel opening

Secure touchscreen display to bracket “B” from behind with M4 screws(included)

Side Bracket Mount

Side-mount Bracket Installation Notes:

Bracket shape varies for each model, drawing for illustration

purposes only. See dimensional drawing for exactdimensions.

User Manual: 90 Series RevB

UM600129 Rev E, page 8 of 28

Rear VESA Mount

A four-hole mounting pattern for M4(10mm) screws is provided on the rear of

the monitor.

The VESA FDMI-compliant counting is coded: VESAMIS-E,C.

ET1093L

ET1291L

ET1590L

ET1593 L

ET1790L

ET1990/1991L

ET2094L

ET2293/2294/2295L

ET2494/2495L

ET2794/2795/2796L

75 x 75 mm

(depends on

different

model)

100x100 mm

200x100 mm

User Manual: 90 Series RevB

UM600129 Rev E, page 9 of 28

Section 4: Operation

Power

The touchscreen display ships in an ON state.

Toturn the touchscreen display on or off, press the touchscreen display power button on the OSD

controller once. The power status LED on the OSD controller functions according to the following

table.

Touchscreen Display/Computer Module Status LED Status

OFF OFF

SLEEP PULSING

ON ON

The system consumes low power when in SLEEP and OFF modes. For detailed power consumption

specifications, refer to technical specifications on the Elo website http://www.elotouch.com

Touching the screen will bring the attached host PC out of SLEEP mode (similar to moving the mouse or pressing a keyboard key).

To improve reliability and reduce wasteful power consumption, disconnect the AC power cable from the monitor when long periods of disuse are planned.

Touch

Your touchscreen display is factory-calibrated and should not need manual calibration (unless the input video is

not fully scaled to the native resolution, or the touch experience needs to be calibrated to a specific user).
