Elo TouchSystems 1919L Manual de usuario

Touchmonitor User Guide

1519L 15.6” LCD Desktop Touchmonitor

1919L 18.5” LCD Desktop Touchmonitor

(Optional Magnetic Stripe Reader Available)

Elo TouchSystems

15.6” and 18.5” LCD Touchmonitor

Optional Magnetic Stripe Reader

User Guide

Revision A

P/N E356416

Elo TouchSystems

1-800-ELOTOUCH

www.elotouch.com

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system,

or translated into any language or computer language, in any form or by any means, including, but

not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written

permission of Tyco Electronics.

Disclaimer

The information in this document is subject to change without notice. Tyco Electronics makes no

representations or warranties with respect to the contents hereof, and specifically disclaims any

implied warranties of merchantability or fitness for a particular purpose. Tyco Electronics reserves

the right to revise this publication and to make changes from time to time in the content hereof

without obligation of Tyco Electronics to notify any person of such revisions or changes.

TrademarkAcknowledgments

AccuTouch, CarrollTouch, Elo TouchSystems, IntelliTouch, Tyco Electronics and TE (logo) are

trademarks of the Tyco Electronics group of companies and its licensors. Windows is a trademark

of the Microsoft group of companies. Other product names mentioned herein may be trademarks or

registered trademarks of their respective companies.Tyco Electronics claims no interest in trade-

marks other than its own.

iii

Table of Contents

Chapter 1

Introduction 5

ProductDescription .....................................................5

Precautions .................................................................5

Chapter2

Installation and Setup 6

UnpackingYourTouchmonitor ......................................6

Assemblingthestandplate..........................................8

InterfaceConnection ...................................................9

Speakers and Audio ....................................................9

MSRInterfaceconnection (Optional) ............................10

Product Overview .......................................................11

MainUnit ................................................................11

Rear View ............................................................11

Installing theDriver Software .......................................12

Installingthe SerialTouchDriver(notapplicable

toAcousticPulse Recognition monitor) ..................13

Installing the Serial TouchDriver for Windows 7,

WindowsVista, Windows XP, Windows 2000, ME,

Windows 95/98 and NT4.0 ..............................14

Installingthe SerialTouchDriver forMS-DOS

and Windows 3.1 ..................................................14

InstallingtheUSBTouchDriver ..............................15

Installing the USB TouchDriver for Windows 7,

WindowsVista, Windows XP, Windows 2000, ME,

and Windows 98 .............................................15

InstallingAPRUSB TouchDriverfor

Windows XP ....................................................15

Chapter3

Operation 16

AboutTouchmonitorAdjustments.................................16

BottomPanelControls............................................17

ControlsandAdjustment..............................................18

OSDMenuFunctions .............................................18

OSDLock/Unlock ...................................................18

OSDControlOptions ..............................................19

PresetModes ........................................................20

PowerManagementSystem ..................................21

DisplayAngle ..............................................................21

Chapter4

Troubleshooting 22

SolutionstoCommonProblems ....................................22

AppendixA

NativeResolution.........................................................23

Appendix B

TouchmonitorSafety ...................................................25

CareandHandling ofYour Touchmonitor .....................26

AppendixC

TouchmonitorSpecifications ........................................27

15.6"LCDTouchmonitor(ET1519L)Dimensions............30

18.5"LCDTouchmonitor(ET1919L)Dimensions............31

Regulatory Information 32

Warranty 35

CHAPTER

INTRODUCTION

Product Description

Your new 1519/1919L touchmonitor combines the reliable performance of touch technology with

the latest advances in LCD display design. This combination of features creates a natural flow of

information between a user and your touchmonitor.

This LCD monitor incorporates a 15.6” or 18.5” color active matrix thin-film-transistor (TFT) liquid

crystal display to provide high quality display performance. A maximum resolution of WXGA 1366

:768 is well-suited for displaying both graphics and images. Other features that enhance the

performance of this LCD touchmonitor are Plug & Play compatibility, OSD (On Screen Display)

controls, an optional magnetic strip reader (MSR), and Elo’s unique zero-bezel Acoustic Pulse

Recognition (APR) and AccuTouch (AT) touchscreen. In addition, the 1519/1919L is easily

configurable for either portrait or landscape orientation.

Precautions

Follow all warnings, precautions and maintenance procedure as recommended in this user’s manual

to maximize the life of the touch monitor. See Appendix B for more information on touchmonitor

safety.

1-5

2-6

CHAPTER

INSTALLATION AND SETUP

This chapter discusses how to install the 1519L/1919L LCD touchmonitor and the driver software.

Unpacking Your Touchmonitor

Check that the following items are present and in good condition:

LCD monitor VGA cable USB cable Audio cable

CD and Quick Install Guide Power Brick Serial Cable

(not included with APR model)

Elo QuickStart

Software

Powercable forNorthAmericamodels

USA/UL Power cable

PowercableforEuropeanmodels

Europe/VDE power cable UK/UK power cable

PowercableforJapanmodels

Japanese/PSE power cable Adapter/Terminal

Power cable forAsia models

and and

or or

China/CCC power cable Taiwan/BSMI power cable Korea/KC power cable

2-7

2-8

Assembling the stand plate

Pushing the stand plate toward the stand untill it is tight, then fasten the stand plate using captive

screw.

Interface Connection

Note: Before connecting the cables to your touchmonitor and PC, be sure that the computer and touchmonitor

are turned off.

1. Connect DC cable of the power brick to the monitor and the other end through AC power cable

to the AC outlet.

2. Connect one end of either the touchscreen serial (RS232) cable or the touch screen USB cable

(but not both) to the rear side of the computer and the other end to the LCD monitor. Tighten by

turning the two thumb screws clockwise to ensure proper grounding.

3. Connect one end of the video cable to the rear side of computer and the other to the LCD monitor.

Tighten by turning the two thumb screws clockwise to ensure proper grounding.

4. Connect one end of the audio cable to the rear side of computer and the other to the LCD

monitor.

5. Facing the monitor, press the power button located on the underside of the botom-right corner

of the monitor.

Speakers and Audio

The touchmonitor includes two built-in speakers. To use the speakers, plug in the audio cable to

the Audio Input port and connect the other end to your computer.

To use headphones, plug in the headphones to the Audio Output port shown a bove. When

headphones are connected, the sound plays through the headphones only.

The volume and muting of the sound can be adjusted by using the “Audio” choice from the On-

Screen Display (OSD) Control panel menu as described on page 3-19.

321

Power Brick

USB Cable

Serial Cable VGA Cable

Audio Cable

Headphone Cable

2-9

Magnetic Stripe Reader (MSR) Interface Connection (optional)

If the MSR is installed on the monitor, plug the USB cable from the MSR directly to the PC. No

drivers are required to be loaded.

To change the MSR function mode from keyboard emulation to HID, load the “MSR CHANGE

MODE.EXE” utility from the enclosed TouchTools CD or go online to www.elotouch.com to

download this utility.

Note: MSR function mode can be changed to HID mode from keyboard emulation mode and back

using the “MSR CHANGE MODE.EXE” utility.

2-10
