TECHNICAL GUIDEBOOK—

INSIDE THE OPTIPLEX FX170 THIN CLIENT

DELL

OPTIPLEX

FX170

™

TABLE OF CONTENTS

O V E R VI E W

OPTIPLEX FX170 FRONT AND BACK VIEWS 3

MARKETING SYSTEM CONFIGURATIONS 4

DET A I L E D E N G I NE E RI NG S P EC I FI CAT IO NS : SY S TE M CO M P ON E NT DE T A I L S 5

PO W E R D E T AIL S 6

AU DI O & C OMM U N IC AT I O N S NE T WO RK AD AP T ER 7

BIO S D E FA U L T S 9

SE RV IC E , S U P P OR T , A N D S OFT WA RE 10

RE G U L AT O RY C O MP LI AN CE A N D E NV I R ON M E N T AL 10

DELL™ OPTIPLEX™ FX170 TECHNICAL GUIDEBOOK 1.0

FRON T AN D B A C K VIE W

Front Back

Number Name Number Name

1Power Button 6USB 2.0 Connectors (4)

2Network Activity Indicator LED 7DVI-I

3Audio Line Out 8PS/2

4Microphone 9Power Connector

5Network Connector 10 Security Cable Slot

DELL™ OPTIPLEX™ FX170 TECHNICAL GUIDEBOOK 1.0

MARKETING SYSTEM CONFIGURATIONS

N O T E : O  e r in g s m a y v a r y by c o u n t r y. F o r m or e i n f o r m a  o n re g a r d i n g t h e c o n  g u r a o n o f y o u r c o m pu t e r , c l ic k S t a r t > He l p

a n d S u p p o r t a n d s e l e c t t h e o p  o n t o v ie w in fo r m a o n a bo u t y o u r c om p u t e r .

*C h o o s e y ou r O S o n t h e F X1 7 0 .

OPERATING SYSTEM for the FX170

WES 2009, WES7, or DeTOS Operating System

DELL™ OPTIPLEX™ FX170 TECHNICAL GUIDEBOOK 1.0

Processor CPU / Chipsets Intel Atom N270 1.6 GHz / Intel 945GSE + ICH7-M

Memory RAM 1GB DDR2 RAM (WES 2009/DeTOS),

2GB DDR2 RAM (WES7)

Data Storage DOM 2GB DOM (WES 2009), 4GB DOM (WES7),

1GB DOM (DeTOS)

Storage x 1 (44 pins IDE port for DOM)

Display

Resoluon Up to 1920x1200 at 32 bit color

Video Memory Dynamic Video Memory Technology (DVMT) 3.0 sup-

ports up to 224MB of video memory

Display Data Control On-board Intel GMA 950

Audio Speaker x 1 (Built-in 1W internal speaker)

I/O Physical

USB (1.1/2.0)

Front x 2

Rear x 2

PS/2 x 1 (For keyboard, mouse or optional PS/2 splitter cable)

Video DVI x 1 DVI-I (or x 1 VGA with included adapter)

Audio

Mic-In x 1 3.5 mm jack

Line-Out x 1 3.5 mm jack

Networking

LAN x 1 (RJ-45, 10/100/1000 Base-T)

WLAN Optional (Linksys WUSB600N USB Network Adapter, sold

separately)

Environment

Temperature

Operaon 32° to 95° F (0° to 35° C)

Storage -4° to 140° F (-20° to 60° C)

Relave Humidity 20% to 80% non-condensing

Power Power Supply 36W, DC 12V/3A external power adapter

Mounng

Foot Stand Horizontal or Vertical Vercal

VESA Bracket (wall mount vercal only) Metal mounng kit for VESA standard (Opon)

Security Kensington Lock Yes

Physical

Characteriscs

Chassis Housing Plasc and metal

Dimension /

Weight

Thin Client 36 (W) x 156 (H) x 122 (D) mm / NW : 0.75 KG

Packing : Single Box 217 (W) x 85 (H) x 236 (D) mm / GW : 1.65 KG

Packing : Carton 450 (W) x 265 (H) x 355 (D) mm / GW : 20 KG, 8 boxes in

one carton

DETAILED ENGINEERING SPECIFICATIONS

SYST EM COM PO NENTS DETAIL S :

DELL™ OPTIPLEX™ FX170 TECHNICAL GUIDEBOOK 1.0

POW ER D ET AI LS

Power supply dimensions

Power Supply Waage 36W

AC input Voltage Range 100-240 V

AC input current (max) 2A

AC input Frequency 47HZ/63HZ

Average Eciency >=78%

Typical Eciency (Acve PFC) 84.8%

DC parameters

+12.0v output 3A

Max total power 36W

Max combined 12.0v power (note: only if more than one 12v rail) 36W

BTUs/h (based on PSU max waage) 123 BTU

Compliance:

1wa requirement Yes

Blue Angel Compliant No

Climate Savers / 80Plus Compliant No

FEMP (CECP) Standby Power Compliant No

E Star Compliant No

3.0v CMOS baery (Type and esmated baery life)

Brand Type Voltage Composion Life

KTS CR-2302 with

wire

3V Lithium Connuous Discharge Under

15 kΩ Load to 2.0V End-

Voltage.

23℃±3C Standard 1000 Hrs.

Minimum Value 800h

0℃±3C Standard 850 Hrs. Mini-

mum Value 680h

DELL™ OPTIPLEX™ FX170 TECHNICAL GUIDEBOOK 1.0

Audio

COMM UN IC ATION S - N ETW O R K A DA PT ER (N IC )

INTEGRATED VIA 1708B HIGH DEFINITION AUDIO FX170

High Denion Stereo support No

Number of Channels 2

Number of Bits / Audio resoluon 16 and 24-bit resoluon

Sampling rate (recording/playback) Support 44.1K/48K/96K/192 kHz sample rates

Signal to Noise Rao 98 dB DAC outputs, 90 dB for ADC inputs

Analog Audio N/A

Dolby Digital N/A

THX N/A

Digital out (S/PDIF) N/A

Audio Jack Impedance

Microphone In 10K ohm

Headphone Out 50~65 ohm

Internal Speaker Power Rang 1Wa (peak) / 0.5Wa (average)

PCIE REALTEK 8111DL-GR

ETHERNET LAN 10/100/1000 FX170

External Connector Type RJ45

Data Rates supported 10/100/1000 Mbps

Controller Details

Controller bus architecture PCIe-based interface

Integrated memory N/A

Data transfer mode (example Bus-Master DMA) N/A

Power consumpon (full operaon per data rate connecon speed) 538mW (Max.)

Power consumpon (standby operaon) 227mW (Max.)

IEEE standards compliance (example 802.1P) 802.3

Hardware Cercaons (example FCC, B, GS mark…) N/A

Boot ROM Support EEPROM (located in SPI)

Network Transfer Mode (example Full Duplex, Half Duplex)

Network Transfer Rate (example 10BASE-T (half-duplex) 10 Mbps

10BASE-T (full-duplex) 20 Mbps

100BASE-TX (half-duplex) 100 Mbps

100BASE-TX (full-duplex) 200 Mbps

1000BASE-T (full-duplex) 2000 Mbps

10 Mb (full/half-duplex)

100 Mb (full/half-duplex)

1000 Mb (full-duplex)

DELL™ OPTIPLEX™ FX170 TECHNICAL GUIDEBOOK 1.0

Communicaons - NETWORK ADAPTER (NIC) (CONT.)

PCIE REALTEK 8111DL-GR

ETHERNET LAN 10/100/1000 (CONT.) FX170

Environmental

Operang humidity 20% to 80% (non-condensing)

Manageability (examples WOL, PXE) WOL, PXE 2.1

Management Capabilies Alerng N/A

DELL™ OPTIPLEX™ FX170 TECHNICAL GUIDEBOOK 1.0

BIOS DEFA U LT S

System Conguraon Integrated NIC: Enable

USB Controller: Enable

Serial Port: N/A

SATA Operaon: N/A

SMART Reporng: N/A

Diskee Drive: N/A

Miscellaneous Devices: Enable (Front USB, Rear USB, PXE)

Drives: (IDE—0)

Video Primary Video: EGA/VGA

Performance Mulple Core Support: N/A

Intel® SpeedStep™: N/A

C States Control: N/A

Limit CPUID Value: Disable

HyperThread control: Enable

Virtualizaon Support Virtualizaon: N/A

VT for Direct I/O: N/A

Security Administrator Password: Not set

System Password: Not set

Password Changes: Enable

TPM Security: N/A

CPU XD Support: Enable

Computrace®: N/A

SATA-0 Password: N/A

Power Management AC Recovery: Power O

Auto On Time: Disable

Deep Sleep Control: N/A

Fan Control Override: N/A

Wake on LAN: Enable

Maintenance Service Tag: Set by the factory

Asset Tag: Oponal User Entry

SERR Message: N/A

Numlock LED: Enable

USB Emulaon: Enable

Keyboard Errors: Default—No Error

POST HotKeys: Enable

Fast Boot: Thorough

DELL™ OPTIPLEX™ FX170 TECHNICAL GUIDEBOOK 1.0

SER V I CE A N D SUP P O RT

N O T E : F or m or e d e ta il s o n D e l l S er v ic e P la n s p le a s e t o g o t o : w w w . d e l l . co m / s e r v i c e / s e r v i c e _ p l a n s

SO FTW A RE

FX170

3 Year Warranty1 Standard

ProSupport Oponal

1 For a copy of our guarantees or limited warranes, please write Dell USA L.P., An: Warranes, One Dell Way, Round Rock, TX 78682. For more informaon, visit

www.dell.com/warranty.

2 Service may be provided by third-party. Technician will be dispatched if necessary following phone-based troubleshoong. Subject to parts availability, geograph-

ical restricons and terms of service contract. Service ming dependent upon me of day call placed to Dell. U.S. only.

FX170

VMware View Ready Yes

Citrix HDX Ready Yes

REGU LAT OR Y C O M PLI AN CE AN D EN VI RON M EN TAL

Product related conformity assessment and regulatory authorizaons including Product Safety, Electromagnec Compability (EMC), Ergonomics,

and Communicaon Devices relevant to this product may be viewed at www.dell.com/regulatory_compliance. The Regulatory Datasheet for this

product is located at hp://www.dell.com/regulatory_compliance.
