Dell Alienware Aurora R15 Manual de usuario

Alienware Aurora R15

Antenna Installation Guide

Regulatory Model: D30M

Regulatory Type: D30M004

October 2022

Rev. A00

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use of your product.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the

problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

Other trademarks may be trademarks of their respective owners.

Contents

Chapter 1: Before working inside your computer...................................................................................4

Chapter 2: Antenna.................................................................................................................................. 5

Chapter 3: Antenna placement................................................................................................................ 6

Chapter 4: SMA antenna-cable............................................................................................................... 7

Chapter 5: Getting help and contacting Alienware................................................................................8

Before working inside your computer

NOTE: The images in this document may differ from your computer depending on the configuration you ordered.

1. Save and close all open files and exit all open applications.

2. Shut down your computer. Click Start > Power > Shut down.

NOTE: If you are using a different operating system, see the documentation of your operating system for shut-down

instructions.

3. Disconnect your computer and all attached devices from their electrical outlets.

4. Disconnect all attached network devices and peripherals, such as keyboard, mouse, and monitor from your computer.

CAUTION: To disconnect a network cable, first unplug the cable from your computer and then unplug the cable from

the network device.

5. Remove any media card and optical disc from your computer, if applicable.

Antenna

1. Follow the procedure in Before working inside your computer.

2. Align and connect the antenna cables to the SMA connectors on the chassis.

3. Tighten the bolts to secure the antenna cables to the SMA connectors on the chassis.

Antenna placement

Place the antenna in a suitable location.

SMA antenna-cable

For more information about the SMA antenna-cable removal and installation procedures, see Service Manual at Dell.com/support.

Getting help and contacting Alienware

Self-help resources

You can get information and help on Alienware products and services using these online self-help resources:

Table 1. Alienware products and online self-help resources

Self-help resources Resource location

Information about Alienware products and services www.alienware.com

My Dell app

Tips

Contact Support In Windows search, type Contact Support, and press Enter.

Online help for operating system www.dell.com/support/windows

Access top solutions, diagnostics, drivers and downloads, and

learn more about your computer through videos, manuals and

documents.

Your Alienware computer is uniquely identified by a Service Tag

or Express Service Code. To view relevant support resources for

your Dell computer, enter the Service Tag or Express Service

Code at www.dell.com/support.

For more information on how to find the Service Tag for your

computer, see Locate the Service Tag on your computer.

VR Support www.dell.com/VRsupport

Videos providing step-by-step instructions to service your

computer

www.youtube.com/alienwareservices

Contacting Alienware

To contact Alienware for sales, technical support, or customer service issues, see www.alienware.com.

NOTE: Availability varies by country/region and product, and some services may not be available in your country/region.

NOTE: If you do not have an active Internet connection, you can find contact information about your purchase invoice, packing

slip, bill, or Dell product catalog.
