HP Z1 Manual de usuario

Latches

Internal USB 2.0 Port

Memory Slots

Hard Drive Bay

Optical Drive Bay

MXM graphics

System Blower

Power supply

Front facing speakers

10.

CPU cooler

QuickSpecs

HP Z1 Workstation

Overview

DA - 14263 North America — Version 21 — October 4, 2013

Page 1

Power Button

4-in-1 Media Card Reader

System Activity LED

Firewire 1394a

Optical Drive Eject Button

USB 3.0 (2 ports)

Slot load Optical Drive

Audio In/Out

QuickSpecs

HP Z1 Workstation

Overview

DA - 14263 North America — Version 21 — October 4, 2013

Page 2

Digital Microphone array

Stand

HD Webcam

27” LED backlit IPS Display

Front Facing Speakers

QuickSpecs

HP Z1 Workstation

Overview

DA - 14263 North America — Version 21 — October 4, 2013

Page 3

Audio In/Out, Subwoofer Out

LAN

4 USB 2.0 ports

DisplayPort In/Out

S/PDIF (digital optical audio)

Power

Form Factor

All in One

Operating Systems

Windows 8 Pro 64-bit

Windows 8 Simplified Chinese Edition 64-bit

Windows 8 Pro Downgrade to Windows 7 Professional 32-bit

Windows 8 Pro Downgrade to Windows 7 Professional 64-bit

Genuine Windows® 7 Professional 32-Bit(1)

Genuine Windows® 7 Professional 64-Bit(1)

HP Linux Installer Kit(2)

SUSE Linux Enterprise Desktop 11 (90 day license) (4)

Red Hat Enterprise Linux Desktop/Workstation (3,4)

NOTE 1

: Systems may require upgraded and/or separately purchased hardware and/or DVD drive to install

the Windows 7 software and take full advantage of Windows 7 functionality. See

http://www.microsoft.com/windows/windows-7/

for details.

NOTE 2

: HP Linux Installer Kit Includes drivers for 32-bit and 64-bit OS versions of Red Hat Enterprise Linux

(RHEL) 5 Workstation, RHEL 6 Workstation, and 64-bit SUSE Linux Enterprise Desktop (SLED) 11. See

http://www.hp.com/go/linux

for details.

NOTE 3:

RHEL Desktop is not available as a preinstall from HP. RHEL Desktop is only available as a one-

year paper license drop-in-the-box.

QuickSpecs

HP Z1 Workstation

Overview

DA - 14263 North America — Version 21 — October 4, 2013

Page 4

NOTE 4

: For detailed OS/hardware support information for Linux, see:

http://www.hp.com/support/linux_hardware_matrix

Available Processors

Name

Cores

Clock

Speed

(GHz)

Intel® Turbo

Boost

Technology

Cache

(MB)

Memory

Speed

(MHz)

Hyper-

Threading

Featuring

Intel® vPro™

Tech-nology

Intel® HD

Graphics

TDP

(W)

Intel® Xeon®

processor

E3-1280v2

3.6 4.0

8 1600

Y Y

N/A

69W

Intel® Xeon®

processor

E3-1245v2

3.4 3.8

8 1600

Y Y

Intel HD

Graphics

P4000

77W

Intel® Xeon®

processor

E3-1225v2

3.2 3.6

8 1600

Intel HD

Graphics

P4000

77W

Intel® Core™ i5-

3470 processor

3.2 3.6

6 1600

Intel HD

Graphics

2500

77W

Intel® Core™ i3-

3220 processor

3.3

N/A

3 1600

N N

Intel HD

Graphics

2500

55W

1The specifications shown in this column represent the maximum frequency (GHz) of one processor core when accelerated with Intel

Turbo Boost Technology. Turbo boost stepping occurs in 100MHz increments. Processors that do not have turbo functionality are

denoted as N/A.

Available Processor

Disclaimers

Intel Xeon E3 and Intel Core i3 processors can support either ECC or non-ECC memory.

Intel's numbering is not a measurement of higher performance. Processor numbers differentiate features

within each processor family, not across different processor families. See:

http://www.intel.com/products/processor_number/

for details.

64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS,

operating system, device drivers and applications enabled for Intel 64 architecture. Processor will not

operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary

depending on your hardware and software configurations. See:

http://www.intel.com/info/em64t

for more

information.

Dual-Core and Quad-Core technologies are designed to improve performance of multithreaded software

products and hardware-aware multitasking operating systems and may require appropriate operating

system software for full benefits; check with software provider to determine suitability; Not all customers

or software applications will necessarily benefit from use of these technologies.

Integrated Display

See below for detailed information

Panel

Type: IPS (in-plane switching) LED Backlit LCD

Viewable Image Area: 68.5 cm, (27 in.) widescreen; diagonally measured

Screen Opening (W x H): 59.8 x 33.6 cm, (23.5 x 13.3 in.)

Optimal Resolution: 2560 x 1440 @ 60 Hz; 3.7MP

Aspect Ratio: 16:9 Widescreen

Viewing Angle (typical): Up to 178° horizontal/178° vertical (10:1 minimum contrast ratio)

QuickSpecs

HP Z1 Workstation

Overview

DA - 14263 North America — Version 21 — October 4, 2013

Page 5

Maximum Brightness (typical)*: 380 nits cd/m2

Minimum Brightness (typical)*: 50 nits cd/m2

Contrast Ratio (typical)*: 1000:1

Dynamic Contrast Ratio (typical)*: N/A

Response Time (typical)*: 12 ms (gray to gray); 14 ms (on/off)

Pixel Pitch: 0.2331 mm

Backlight Lamp Life (to half brightness): 39,000 hours minimum

Color Gamut Area vs. NTSC: 96% (CIE 1976), 77% (CIE 1931)

Color Gamut Coverage of sRGB: 100% (CIE 1931)

Color Support**: Up to 1.07 billion colors

Notes

: *All performance specifications represent the typical specifications provided by HP's component

manufacturers; actual performance may vary either higher or lower.

Notes

: ** Display of up to 1.07 billion colors on HP Z1 requires use of 10-bit content.

Signal Interface/Performance

Horizontal Frequency: 90 kHz

Vertical Frequency: 60 Hz

Native Resolution: 2560 x 1440 @ 60 Hz; 3.7MP

Preset VESA Graphic Modes (non-interlaced): 2560 x 1440 @ 60 Hz

Maximum Pixel Clock Speed: 250 MHz

User Programmable Modes: None

Default Color Temperature: 6500 K

Convertibility

The Z1 can either be placed on the desktop in the traditional display method or mounted on a wall with the

industry standard VESA mount. The VESA mount on the Z1 uses a 100x100 VESA mount pattern.

Expansion Slots

(see

system board section for

more details)

1 MXM (dedicated for graphics)

3 miniPCIe full-length

Expansion Bays

(see

storage section for more

details)

1 internal 3.5" bay, or

2 internal 2.5" bays

Side I/O

2 USB 3.0, 1 IEEE 1394a, 1 4-in-1 Media Card Reader, 1 Headphone, 1 Mic; Mic can be re-tasked to function

as Line-in

Internal I/O

1 USB 2.0 Type A on Rear IO board, 2 internal on 9-pin header

Rear I/O

1 DisplayPort v1.1, 4 USB 2.0, 1 RJ45 LAN, 1 Subwoofer Output, 1 optical S/PDIF Output, 1 Audio Line-in,

and 1 Audio Line-out

QuickSpecs

HP Z1 Workstation

Overview

DA - 14263 North America — Version 21 — October 4, 2013

Page 6

Chassis Dimensions

(HxWxD)

Standard display orientation WITH stand: 584.2mm x 660.4mm x 419.1mm (23in. x 26in. x 16.5in.);

Standard display orientation WITHOUT stand: 457.2mm x 660.4mm x 81.28mm (18in. x 26in. x 3.2in.)

Service/Shipping orientation: 116mm x 660mm x 510mm

Weight

Exact weights depend upon configuration;

Max system weight WITH stand: 21.32 kg (47 lbs);

Stand weight 5.9 kg (13 lbs)

Temperature

Operating:

40° to 95°F (5° to 35°C)

Non-operating

-40° to 140°F (-40° to 60°C)

Humidity

Operating:

8% to 85%

Non-operating

8% to 90%

Maximum Altitude

(non-

pressurized)

Operating:

3,000 m (10,000 ft)

Non-operating

9,100 m (30,000 ft).

Power Supply

400 watts wide-ranging, active Power Factor Correction, 90% Efficient

The Power Supply Efficiency Report for this product may be found at these links: TBD

Chipset

Intel® C206 chipset

Memory

4 DIMM slots, supporting up to 32GB ECC or 16GB non-ECC Unbuffered DDR3 1600 MHz

Memory Disclaimers

The CPU determines the speed at which the memory is clocked. If a 1333MHz capable CPU is used in the

system, the maximum speed the memory will run at is 1333MHz regardless of the specified speed of the

memory.

Workstation ISV

Certifications

See the latest list of certifications at

http://www.hp.com/united-states/campaigns/workstations/partnerships.html

QuickSpecs

HP Z1 Workstation

Overview

DA - 14263 North America — Version 21 — October 4, 2013

Page 7

Processors

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

2nd generation Intel® Core™ processor family

Intel® Xeon® processor E3 v2 family (Z220/Z1)

Intel® Xeon® processor E3-1280v2, Quad-Core, 8 MB cache,

3.6 GHz, up to 4.0 GHz with Intel Turbo Boost Technology

Y Y

See Note

Intel® Xeon® processor E3-1245v2, Quad-Core, 8 MB cache,

3.4 GHz, up to 3.8 GHz with Intel Turbo Boost Technology

Y Y

See Note

1, 2

Intel® Xeon® processor E3-1225v2, Quad-Core, 8 MB cache,

3.2 GHz, up to 3.6 GHz with Intel Turbo Boost Technology

Y Y

See Note

1, 2

3rd generation Intel® Core™ processor family

Intel® Core™ i5-3470 processor, Quad-Core, 6 MB cache, 3.2

GHz, up to 3.6 GHz with Intel Turbo Boost Technology

Y Y

Intel® Core™ i3-3220 processor, Dual-Core, 3 MB cache, 3.3

GHz

Y Y

See Note

NOTE 1

: These processors support either ECC or non-ECC memory

NOTE 2

: Intel HD Graphics P4000 provides improved desktop performance and supports workstation-

specific graphics drivers for improved compatibility and performance on select professional applications

compared to Intel HD Graphics 2500.

Monitors / Displays

Factory

Configured

Option Kit

Part

Number

Support

Notes

HP Z1 27-inch WLED IPS Display

HP DreamColor LP2480zx Professional Display

HP ZR30w 30-inch S-IPS LCD Monitor

HP ZR2740w 27-inch LED Backlit IPS Monitor

HP ZR2440w 24-inch LED Backlit IPS Monitor

HP Z Display Z24i 24-inch IPS LED Backlit Monitor

HP Z Display Z23i 23-inch IPS LED Backlit Monitor

HP Z Display Z22i 21.5-inch IPS LED Backlit Monitor

NOTES

Supported by all Operating Systems available from HP

Screen Size Diagonally Measured

QuickSpecs

HP Z1 Workstation

Supported Components

DA - 14263 North America — Version 21 — October 4, 2013

Page 8

Hard Drives

SATA Hard Drives

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

SATA (Serial ATA) Hard Drives for HP Workstations

250GB SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y

500GB SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y

1TB SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y

300GB SATA 10K rpm SFF HDD

Y Y

600GB SATA 10K rpm SFF HDD

Y Y

500GB SATA 10K rpm SFF HDD

Y Y

B8X19AA

1TB SATA 10K rpm SFF HDD

Y Y

B8X20AA

3.0TB SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y

QF298AA

SATA Solid State Drives

HP Solid State Drives (SSDs) for Workstations

HP 256GB SATA 6Gb/s SSD

Y Y

A3D26AA

HP 512GB SATA 6Gb/s SSD

Y Y

D8F30AA

Hard Drive Controllers

Factory

Configured

Option Kit

Part

Number

Support

Notes

Factory integrated RAID on motherboard for SATA drives

RAID 0 Configuration - Striped Array

RAID 1 Configuration - Mirrored Array

SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID,

provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please

visit

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf

for RAID

capabilities with Linux.

All drives must be identical in type and capacity

All RAID arrays must be less than 2 TB

NOTE 1

: Requires identical hard drives (speeds, capacity, interface).

QuickSpecs

HP Z1 Workstation

Supported Components

DA - 14263 North America — Version 21 — October 4, 2013

Page 9

Graphics

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support Notes

Supported

Multi

Mixed

Integrated Intel HD Graphics Media Accelerators

Intel HD Graphics P3000

On select CPUs

Intel HD Graphics 2000

On select CPUs

Integrated Intel HD Graphics Media Accelerators (Z220)

Intel HD Graphics P4000

Y Y

On select CPUs

Intel HD Graphics 2500

Y Y

On select CPUs

Entry 3D

NVIDIA Quadro 500M 1GB Graphics

Mid-range

NVIDA Quadro 1000M 2GB Graphics

NVIDIA Quadro K3000M 2GB Graphics

Y Y

C3G85AA

High End 3D

NVIDIA Quadro K4000M 4GB Graphics

Y Y

C3G86AA

NOTE 1

: If a discrete graphics card is installed, Intel integrated graphics is disabled.

Memory

CTO

Option Kit Part

Number

Support Notes

DDR3-1600 ECC Unbuffered DIMMs - CTO

HP 32GB (4x8GB) DDR3-1600 ECC RAM

HP 16GB (2x8GB) DDR3-1600 ECC RAM

HP 16GB (4x4GB) DDR3-1600 ECC RAM

HP 8GB (2x4GB) DDR3-1600 ECC RAM

HP 8GB (4x2GB) DDR3-1600 ECC RAM

HP 4GB (2x2GB) DDR3-1600 ECC RAM

DDR3-1600 nECC Unbuffered DIMMs CTO

HP 16GB (4x4GB) DDR3-1600 nECC RAM

HP 8GB (2x4GB) DDR3-1600 nECC RAM

HP 8GB (4x2GB) DDR3-1600 nECC RAM

HP 4GB (1x4GB) DDR3-1600 nECC RAM

HP 4GB (2x2GB) DDR3-1600 nECC RAM

HP 2GB (1x2GB) DDR3-1600 nECC RAM

Sub-Section Description/Notes

Intel® Xeon E3 and Intel Core i3 processors can support either ECC or non-ECC memory.

Two channels of DDR3 memory are supported. To realize full performance at least one DIMM must be

inserted into each channel.

The CPU determines the speed at which the memory is clocked. If a 1333MHz capable CPU is used in the

system, the maximum speed the memory will run at is 1333MHz regardless of the specified speed of the

QuickSpecs

HP Z1 Workstation

Supported Components

DA - 14263 North America — Version 21 — October 4, 2013

Page 10

Otros manuales para Z1

Tabla de contenidos

Otros manuales de De oficina de HP

HP Pavilion p6110 Manual de usuario

HP Pavilion v400 - Desktop PC Manual de usuario

HP EliteDesk 800 G3 Instrucciones de instalación

HP Compaq 6000 Pro SFF Manual de usuario

HP Pavilion Slimline s3401f Manual de instrucciones

HP Pavilion t500 - Desktop PC Manual de usuario

HP Pavilion t267k Manual de usuario

HP VH677UA#ABA - Pavilion Dv6-1244sb... Hoja de especificaciones

HP SignagePlayer mp8000r Guía de configuración

HP 512n - Pavilion - 128 MB RAM Manual de usuario

HP Vectra 520 Manual

HP 743 Series Manual de uso y cuidado

HP Brio BA300 Manual de usuario

HP TouchSmart 310-1125 Manual de usuario

HP Pavilion Slimline s7500 - Desktop PC Hoja de especificaciones

HP Model 745 - VME Workstation Manual de usuario

HP Vectra VL5 5 Manual del producto

HP b2600 Manual

HP 8000 - Elite Convertible Minitower PC Instrucciones de uso

HP Pavilion m9520 Manual de usuario

HP ZX2000 Manual de uso y cuidado

HP Vectra XA 5 Series Manual de usuario

HP Pavilion a600 - Desktop PC Manual de usuario

HP Pavilion Slimline s5310f Manual de usuario

Manuales populares de De oficina de otras marcas

Asus

Asus E210 Series Manual de usuario

Dell

Dell Inspiron 600m Manual de usuario

Dell

Dell Inspiron 3662 Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

Logitech

Logitech MK320 Manual de usuario

Dell

Dell XPS 730 H2C Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

Dell

Dell Optiplex 9010 All In One Manual de usuario

Everex

Everex eXplora Manual de usuario

Lenovo

Lenovo ThinkCentre M75e Manual de usuario

Dell

Dell Alienware Area-51 R4 Manual de usuario
