Dancover PRO EventZone 9m Series Manual de usuario

for

Storage PRO EventZone

9m Series

Manual

25-06-2021

Safety Advice

Attention

In some countries approval is needed to set up a tent larger than 75 m2. It is your responsibility

to comply with local rules and regulations and to ensure that the tent is assembled correctly.

In case of bad weather conditions, it is your responsibility to ensure the tent is safely secured

and that the tent does not cause damage to others.

Do not use open re, welding equipment or other sources which can ignite, inside or close to the

tent.

The tent must be safely secured. We recommend you secure your tent with straps and pegs as

soon as it is assembled.

Make sure to check if the tent is covered by your home contents insurance.

Tents must be evacuated under extreme weather conditions.

In the event of snow, always remove snow from the roof of the tent regularly to prevent snow

from building on the roof, as heavy snow can cause the tent to collapse.

In the event of rain, there is a risk of rain puddles building up on top of the roof of the tent.

Heavy rain puddles can cause the roof to collapse. It is your responsibility to ensure rain

puddles do not build up. As a precaution, make sure the roof of the tent is stretched out

properly and adequately over the side frames of the tent and remove rain water regularly.

Do not unpack or repack your tent in freezing temperatures. In case of temperatures below

zero, always unpack and repack your tent indoors to avoid the risk of cracking parts.

The tent must be totally dry before you repack and store it to avoid mildew.

Note: Dancover warranty applies only to the normal use of the Product, normal wear and tear

excepted, in accordance with written use instructions or manual. The warranty does not apply

to damage caused by accident, abuse, misuse, or modification of the Product.

Warranty Information

Please visit dancovershop.com for information on warranty.

Please always check our website for the latest safety advice and manual.

1.Frames Assembling Guide

⚫Measure the site and mark the position

⚫Please arrange the face line of one longitudinal side or the face line of the

gable side

⚫Then mark and stake the Base-Plates on the right position

⚫Check the material list and put all of them on the right position for setup

(Please find the packing list in the delivery-Techniques of the Tent)

⚫Use the bolt (M12x70, M12x100, M12x120) to connect the Foot-Plates, Legs

Roof-Beams, Eave-Connections and Top Connections. And then, erect the

first frame of the tent.

⚫NO.11, Portal beams is on four corners for support. Use bolt M12x70 to fix it.

⚫Erect all frames and put the purlins on the roof as the first section.

⚫Use bolt M12x70 to fix the leg NO.5 and Roof beam NO.1 and Top connection

through NO.31

⚫Use bolt M12x120 to fix the (NO.2,5) and Gable Purlin (NO.6,7).

⚫Use bolt M12x100 to fix Tie down on the NO.2 and NO.5.

2.’Roof Cover and Sidewalls’ Assembling Guide

⚫ Roof-Cover

⚫Unpack the Roof-Cover and put onto a protecting foil or carpet to avoid it

getting dirty or damaged.

⚫Throw 2 PCS of Setup -Ropes over the first unit of the tent.

⚫Tie the Setup-Ropes with the straps inside of the Roof-Cover.

⚫Lift the Roof-Cover up to the eaves and insert the Keder into the groves of the

Roof-Beams.

⚫Slowly pull in the Roof-Cover with equal force on both sides.

⚫Pull in until the Roof-Cover reaches the opposite eaves.

⚫Repeat the procedure until all Roof-Covers have been pulled on.

Caution:

The Roof-Cover has to be completely inserted into the glove of the Roof-Beam.

⚫ Gable Triangle

⚫Divide the Gable-Cover into two pieces.

⚫Insert each triangle into Roof-Beam, starting from the eave.

⚫Connect the two triangles with the zipper.
