Dancover Pagoda 4x4m Manual de usuario

20-08-2018

for

Pagoda 4x4m

Manual

Safety Advice

Attention

In some countries approval is needed to set up a marquee/tent larger than 75 m2. It is your

responsibility to comply with local rules and regulations and to ensure that the marquee/tent is

assembled correctly.

In case of bad weather conditions, it is your responsibility to ensure the marquee/tent is safely

secured and that the marquee/tent does not cause damage to others.

Do not use open re, welding equipment or other sources which can ignite, inside or close to the

tent.

The marquee/tent must be safely secured. We recommend you secure your marquee/tent with

straps and pegs as soon as it is assembled.

Make sure to check if the marquee/tent is covered by your home contents insurance.

Marquees/tents must be evacuated under extreme weather conditions.

In the event of snow, always remove snow from the roof of the marquee/tent regularly to prevent

snow from building on the roof, as heavy snow can cause the marquee/tent to collapse.

In the event of rain, there is a risk of rain puddles building up on top of the roof of the marquee/

tent. Heavy rain puddles can cause the roof to collapse. It is your responsibility to ensure rain

puddles do not build up. As a precaution, make sure the roof of the marquee/tent is stretched

out properly and adequately over the side frames of the marquee/tent and remove rain water

regularly.

Do not unpack or repack your marquee/tent in freezing temperatures. In case of temperatures

below zero, always unpack and repack your marquee/tent indoors to avoid the risk of cracking

parts.

The marquee/tent must be totally dry before you repack and store it to avoid mildew.

Note: Marquees are intended for events and other arrangements and are as such only meant for

short term temporary assembly and the following disassembly. Dancover warranty applies only

to the normal use of the Product, normal wear and tear excepted, in accordance with written

use instructions or manual. The warranty does not apply to damage caused by accident, abuse,

misuse, or modication of the Product.

Warranty Information

Please visit dancovershop.com for information on warranty.

Please always check our website for the latest safety advice and manual.

Part List

Part NO. Part 4x4m

3 8

4 8

5 4

6 4

7 4

12 8

13 8

14 4

15 60

17 64

20-08-2018

Part List

19 M30 1

20 1

21 3

22 1

23 1

24 4

25 4

20-08-2018

Assembly

Step1: Lay out and connect the square as shown above.

Step2: Fasten the connections.

Assembly

Step3: Set up the top as shown above. NO.1 and 11 assembled by

NO.5.

Step4: Put NO.10 through the top rings (NO.8)

Step5: Put the roofcover (NO.23) on the roof structure.

Step6: Use the legs to raise the top one side at a time.

Step7: Secure the legs to the ground with the stake pegs (NO.13).

Step8: Fasten roofcover (NO.23) with bungee balls (NO.17).

NO. 20

Assembly

Step9: Use NO. 20 to tighten the roofcover as shown above and

fasten with NO.19.

Contact information

Head office:

Dancover A/S

Nordre Strandvej 119 G

3150 Hellebæk

Denmark

For more information

please visit:

www.dancovershop.com

National contact

Denmark: 70 26 76 20

denmark@dancover.com

UK: 020 8099 7570

uk@dancover.com

Spain: 911 436 828

espana@dancover.com

Italy: 02 479 21 198

italia@dancover.com

Germany: 041 0266 7040

germany@dancover.com Switzerland: 0840 000125

schweiz@dancover.com

France: 0975 181 800

france@dancover.com Austria: 0662 626935

austria@dancover.com

Sweden: 040 233 262

sverige@dancover.com

Finland: 0 931 581 720

suomi@dancover.com Nederland: 0 858 880 524

nederland@dancover.com

Poland: 22 300 8602

polska@dancover.com Ireland: 0 151 33 003

ireland@dancover.com

Luxembourg: +49 041 0266 7040

luxembourg@dancover.com

Portugal: 308 800 899

portugal@dancover.com

Belgium: 0 28 08 08 09

belgique@dancover.com

Norway: 231 00 690

norge@dancover.com
