D-Link DU-562M Manual de usuario

If you purchased this Modem to make your Internet connection with PC, you must

have an established Internet account from an Internet Service Provider (ISP).

Check Your Package Contents

These are the items included with your D-Link 562IS purchase:

If any of the above items are missing, please contact your reseller.

holders. Software and specifications subject to change without notice. D-Link DU-562M USB Modem

D-Link DU-562M

USB Modem

Before Your Begin

• D-Link DU-562M USB Modem

• CD-ROM (containing Manual and Q.I.G.)

• Phone Cable

• D-Link DU-562M User’s Guide

• USB Cable

Using a power

supply with a

different voltage rating

will damage and void

the warranty for this

product.

Hardware Installation

Please unplug the telephone Line and plug the telephone line into the socket on

the back of the modem marked LINE.

A. Insert one end of an USB cable to the USB port on the back panel of the

DU-562M. The Power LED will turn ON to indicate proper operation.

B. Use the Phone cable included with the Modem to connect it to the telephone

wall socket. Plug one end of the cable into the PHOME port on the rear

panel of the Modem and insert the other end into the wall socket.

B.This is the

connection for

Phone Cable to

ISP Provider.

A.This is the

connection for

USB Cable to

you Computer

USB Port.

Install Drivers

2.1 Windows 98/ME

Click Install Drivers

When the system was

complete, windows will

detect the modem

automatic, please click

Cancel. Then insert the

driver CD supplied.

Click OK

Click OK to install

driver.

2.1 Windows 98/ME (continue)

Click Modems

Click Yes

Click Yes to automatic

reboot PC.

Click OK

Check Modem Model No.Fo

D-Link DU-562M External

Modem.

If the installation is complete

then click OK to exit.

Go to Start > select

Setting > click the

Control Panel >

Double-click on the

Modems icon.

2.2 Windows 2000

Click Yes, to continue

this installation

procedure.

When the system was

complete, windows will

detect the modem

automatic, please click

Cancel. Then insert the

driver CD supplied.

Click Install Drivers

Click Yes

2.2 Windows 2000 (continue)

Click Yes

Click Yes, to continue

this installation

procedure.

Click CLOSE

After system will auto

Install Modem.

Please click Close to

end the window.

2.2 Windows 2000 (continue)

Click OK

Check Modem Model No. For

D-Link DU-562M External

Modem.

If installation is complete then

click OK to exit.

Go to Start > select

Setting > click the

Control Panel >

Double-click on the

Phone and Modem

Options icon.

Click Phone and

Modem Options

2.3 Windows XP

Click Install Drivers

When the system was

complete, windows will

detect the modem

automatic, please click

Cancel. Then insert the

driver CD supplied.

Click Continue

Anyway

Click Continue

Anyway to skip the

warning message.

2.3 Windows XP (continue)

Select the Install the

software

automatically

[Recommended] then

click Next to search

for the driver.

Click Next

Select Include this

location in the

search: and type a

path: G:\Driver\WinXP

(G is the letter of the

CD-ROM drive).

2.3 Windows XP (continue)

Click Continue

Anyway

Click Continue

Anyway to skip the

warning message.

Click Finish

Install complete.
