D-Link DCS-2800LH-EU Manual de usuario

Wire-Free Battery Camera

Quick Start Guide

DCS-2800LH-EU

ENGLISH

DCS-2800LH-EU

ENGLISH

Minimum Requirements

To install this product, you will need:

• 802.11g/n wireless router

• Internet connection

• DCS-H100 hub (included in the DCS-2802KT-EU Wire-Free Camera

Kit)

• The latest version of the mydlinkTM app from your operating

system’s application store.

• The mydlink app is available for iPhone®, iPad® and Android™

devices. Please refer to the mobile app's store page to check

whether your device is compatible.

• An e-mail account (required to register for mydlink service)

Note: Please assure that your phone is connected to the same Wi-Fi

network on the router that you plan on plugging the hub into.

DCS-2800LH-EU

ENGLISH

top left, then tap Add a Device to start the setup wizard.

Continue conguraton in the app.

DCS-2800LH-EU

ENGLISH

If you select "Yes" in the app, scan the QR code on the bottom of

the camera. Continue conguration in the app.

DCS-2800LH-EU

ENGLISH

If you select "No" in the app then select the DCS-2800LH camera

from the menu. Continue conguration in the app.

DCS-2800LH-EU

ENGLISH

Once at the camera is synced successfully, the LED on the camera

will illuminate green to indicate it's currently connected.

DCS-2800LH-EU

ENGLISH

Camera Placement Precautions

Improper Placement:

Do not place the camera directly on top of a surface or in a spot

where there is something directly below it, obstructing its view.

Caution:

Please make sure that the camera is

not directly facing the sun or a source

of heat.

Proper Placement:

Place the camera at least 2.2 m (7 ft) or higher from the ground, and at least

20cm (7.8in) from the ceiling. The minimum recommended viewing distance

for the motion detection is 60 cm (24 in), and the maximum is 7.5 m (25 ft).

2.2 m

(7 ft)

64° 60 cm

(24 in)

min

115°

7.5 m

(25 ft)

max

good detection

poor detection

DCS-2800LH-EU

ENGLISH

Step 1:

Place the baseplate at the desired location, assuring

that it is at least 20cm from the ceiling. Make sure

the screw is facing up and the holes are level. Use a

pencil to mark the holes.

Step 2:

Using a 6 mm drill bit, drill two 25 mm deep holes

over the pencil marks. For a plaster, drywall, or

concrete wall, insert the plastic anchors to support

the screws rst.

Step 3:

Place the baseplate over the holes. Use the supplied

screws to attach the baseplate to the wall.

Step 4:

Align the large top screw with the largest hole on

the snap mount. Slide the mount down to lock into

place.

Step 5:

Attach the back of the camera to the mount. Adjust

the angle as desired.

Camera Mounting Instructions

Snap Mount

Version 1.00 (EU)_90X130

June 27, 2018

Support

For troubleshooting tips and more information, visit:

support.dlink.com
