CYP PRO-3GSDIHDMI Manual de usuario

PRO-3GSDIHDMI

3G-SDI Extender with HDMI

Scaler

OPERATION MANUAL

Safety Precautions

Please read all instructions before attempting to unpack or install or

operate this equipment, and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

 Always follow basic safety precautions to reduce the risk of

re, electrical shock and injury to persons.

 To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

 Never spill liquid of any kind on or into this product.

 Never push an object of any kind into this product through

module openings or empty slots, as you may damage parts.

 Do not attach the power supply cabling to building surfaces.

 Do not allow anything to rest on the power cabling or allow it to

be abused by persons walking on it.

 To protect the equipment from overheating, do not block the

slots and openings in the module housing that provide ventilation.

Revision History

Version No Date Summary of Change

VR0 20110325 Preliminary Release

Table of Contents

1. Introduction..................................................................................1

2. Applications.................................................................................1

3. PackageContents......................................................................1

4. SystemRequirements..................................................................1

5. Features........................................................................................1

6. Specifications..............................................................................2

7. OperationControlsandFunctions............................................. 3

7.1 Front Panel .................................................................... 3

7.2 Rear Panel .................................................................... 3

8. OSDMenuandFunctionList....................................................... 4

9. ConnectionandInstallation...................................................... 8

1. Introduction

The SDI to HDMI Scaler with Audio allows SD, HD and 3G-SDI signals to be

display on HDMI/SDI displays while ensuring high bit rates of 2.970 Gbit/s gives

you fast signal transmission without signal loss. For professional this means that it

is now easier to distribute and extend your SDI signal while giving you the ability

to display your work on HDMI displays. Further, the design of coaxial and L/R

audio output allows user to output audio with both digital and analog format

and the loop-through 3G-SDI design also benet user to enjoy both SDI and

HDMI display synchronously.

2. Applications

• Broadcast video signal to HDMI/SDI display

• Broadcast video signal extension

• 3G SDI signal conversion into HDMI signal

3. Package Contents

• SDI to HDMI Scaler with Audio

• 5V/2.6A DC power adaptor

• Operation Manual

4. System Requirements

Input source equipment such as SNG camera or any SDI signal with connection

cables and output to LCD TV or SDI monitor with connection cables.

5. Features

• Operation at 2.970Gb/s, 2.970/1.001Gb/s, 1.485Gb/s, 1.485/1.001Gb/s and

270Mb/s

• Supports SMPTE 425M (Level A and Level B), SMPTE 424M, SMPTE 292M,

SMPTE 259M

• Equalized and re-clocked loop output

• Alternative audio output to coaxial and analog 2CH

• Integrated audio de-embedded for max 8 channels of 48kHz audio

• Auto video mode detection (3G/SD/HD)

• Conversion from SMPTE 425M level B to Level A for 1080p 50/59.94/60 4:2:2

10-bit

• SDI loop-through for long distance

• Convert SDI HD timing to PC timing

6. Specications

SMPTE Standard 425M Level A & B, 424M, 292M, 259M-C

SDI Transmition Rates 2.970 Gbit/s and 2.970/1.001 Gbit/s

Frequency Bandwidth 165MHz/link

Input Port 1 x BNC (SD/HD/3G-SDI)

Output Port 1 x BNC (SD/HD/3G-SDI),

1 x HDMI, 1 x Coaxial, 1 x L/R (RCA)

SDI Supports SD: 480i, 576i

HD: 720p 50/60, 1080i 50/60, 1080p 24/25/30

3G: 1080p 50/60

Power Supply 5V DC/ 2.6A (US/EU standards, CE/FCC/UL certied)

ESD Protection Human body model: ± 8kV (air-gap discharge)

± 4kV (contact discharge)

SDI Cable Distance 3G up to 100M (BELDEN 1694A)

HD up to 200M (BELDEN 1694A)

SD up to 300M (BELDEN 1694A)

Dimension (mm) 180(W) x 142(D) x 25(H)

Weight (g) 460

Chassis Material Aluminum

Silkscreen Color Gray

Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F

Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F

elative Humidity 20 ~ 90% RH (Non-condensing)

Power Consumption (W) 4

7. Operation Controls and Functions

7.1FrontPanel

1 2 3 4 5 6 7

①. Power LED: This blue LED will illuminate when the device is connected with

power supply.

w. 3G LED: This green LED illuminate when the input SDI signal is with 3G

format.

e. HD LED: This green LED illuminate when the input SDI signal is with HD

format.

r. SD LED: This green LED illuminate when the input SDI signal is with SD

format.

t. MENU: Press this button to enter/exit the OSD menu.

y. ENTER: Press this button to conrm your selection. Press both ENTER and

– buttons together to switch output timing to 720p instantly and press with

+ buttons together to switch output timing to XGA.

u. -/+: Press these buttons to move up or down the OSD selections.

7.2RearPanel

1 2 3 4 5 6

①. SDI IN: This slot is where you connect the SDI source output for SDI signal

sending to be display on screen.

w. SDI OUT: This slot is where you connect the SDI display with SDI cable for

input source display.

e. AUDIO OUT COAXIAL: This slot is where you connect the amplier with

coaxial cable and from amplier to speaker

r. AUDIO OUT R/L: These slots are where you connect the speaker or

amplier with RCA jack for audio signal display.

t. HDMI Out: This slot is where you connect the HDMI / DVI display with HDMI

or HDMI to DVI cable.

y. DC 5V: Plug the 5V DC power supply into the unit and connect the

adaptor to AC wall outlet. Blue LED will illuminate when the power is ON.

6. Specications

SMPTE Standard 425M Level A & B, 424M, 292M, 259M-C

SDI Transmition Rates 2.970 Gbit/s and 2.970/1.001 Gbit/s

Frequency Bandwidth 165MHz/link

Input Port 1 x BNC (SD/HD/3G-SDI)

Output Port 1 x BNC (SD/HD/3G-SDI),

1 x HDMI, 1 x Coaxial, 1 x L/R (RCA)

SDI Supports SD: 480i, 576i

HD: 720p 50/60, 1080i 50/60, 1080p 24/25/30

3G: 1080p 50/60

Power Supply 5V DC/ 2.6A (US/EU standards, CE/FCC/UL certied)

ESD Protection Human body model: ± 8kV (air-gap discharge)

± 4kV (contact discharge)

SDI Cable Distance 3G up to 100M (BELDEN 1694A)

HD up to 200M (BELDEN 1694A)

SD up to 300M (BELDEN 1694A)

Dimension (mm) 180(W) x 142(D) x 25(H)

Weight (g) 460

Chassis Material Aluminum

Silkscreen Color Gray

Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F

Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F

elative Humidity 20 ~ 90% RH (Non-condensing)

Power Consumption (W) 4

8. OSD Menu and Function List

1st Layer 2nd Layer 3rd Layer

Display

Output

NATIVE

800 x 600 @60

1024 x 768 @60

1280 x 768 @60

1360 x 768 @60

1280 x 800 @60

1280 x 1024 @60

1440 x 900 @60

1400 x 1050 @60

1680 x 1050 @60

1600 x 1200 @60

1920 x 1200 @60

720 x 480p @60

1280 x 720p @60

1920 x 1080p @60

720 x 576p @50

1280 x 720p @50

1920 x 1080p @50

1920 x 1080i @60

1920 x 1080i @50

Size

Full

Over Scan

under 1

Under 2

Letter Box

Pan Scan

Exit

Color

Contrast 0~255 (105)

Brrightness 0~192 (96)

R 0~255 (128)

G 0~255 (128)

B 0~255 (128)

R Offset 0~63 (32)

G Offset 0~63 (32)

B Offset 0~63 (32)

Exit

SDI Audio

Group 1

Group 2

Group 3

Group 4

Auto

Off

Factory Reset Yes

Information Input Timing, Output Timing & Version

1. Display

 Output Timings: There are total 20 timings available for user’s selec-

tion.

 Size: Adjust the display’s screen size from full, over scan, under scan,

letter box or Pan scan to t the different timing’s display and make

the viewing become more pleasure.

2. Color

Adjust screen color RGB’s Contrast and or Brightness.

3. SDI Audio

Select SDI audio output from 4 different group and each group contents

2CH or from auto which contain up to 7.1Ch follow by input source signal.

If no audio output is require the audio can also be mute by selecting off.

4. Factory Reset

Select YES to return to the factory setting. Factory setting on display is at

1280 x 720p @60Hz with full size screen, Color setting are as the bracket in

the OSD chart and SDI audio is on auto.

5. Information

Displaying both input source and output display timing with software rm-

ware version.
