Creative MUVO TX FM Manual de usuario

P/N : 03PD051100007 Rev B

Quick Start

English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Français. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Brasileiro. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87

Türkçe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

Language TOC.fm Page 1 Thursday, May 20, 2004 4:34 PM

Language TOC.fm Page 2 Thursday, May 20, 2004 4:34 PM

English

Your Player At A Glance

Liquid Crystal

Display (LCD)

Play/Pause

Microphone

Scroller

Volume

Increase

Volume

Decrease

Front View Side View

Earphone

connector

Volume

Increase

MuVo TX FM QSB English 20th May.fm Page 1 Wednesday, May 19, 2004 4:44 PM

English

Getting Started

1Install the Software

Your Creative MuVo TX FM comes with software that helps you create audio tracks, manage

your music library and use your player.

1. Make sure that your player is not connected to your computer.

2. Insert the Installation CD into your CD-ROM drive.

3. The disc supports Windows AutoPlay mode and starts running automatically. If not, click

Start →Run. In the Open box, type d:\ctrun\ctrun.exe (replace d:\ with the drive

letter of your CD/DVD-ROM drive), and then click the OK button.

4. Click the Install software for Creative MuVo TX FM to select it.

5. Click the OK button.

6. Follow the instructions on the screen.

7. When prompted, restart your system.

For Windows 2000/XP users:

To install the software, you must log in as the computer administrator. For more

information, refer to your operating system's online Help.

MuVo TX FM QSB English 20th May.fm Page 2 Wednesday, May 19, 2004 4:44 PM

2Connect the USB Flash Drive to your

computer

Do not press the buttons on your USB Flash Drive while connecting it to your computer.

USB port

Battery

module

USB port

USB Flash

Drive

MuVo TX FM QSB English 20th May.fm Page 3 Wednesday, May 19, 2004 4:44 PM

3Transferring tracks or files

1. After connecting the USB Flash Drive to your computer, you will see

Figure 1 on the player's LCD screen.

2. On your Desktop, right-click the My Computer icon, and then click

Explore. The USB Flash Drive appears as a removable disk icon

(Figure 2).

3. Drag and drop files into your player. During the transfer, Figure 3

appears on the LCD screen.

You can also use applications such as Creative MediaSource (included with the Installation CD)

to manage the music tracks in your player.

For Windows 98 SE users only:

Do not remove the USB Flash Drive until Figure 1 appears on the screen again for at least

five seconds.

For other Windows operating system users only:

Make sure you stop your player properly, using the Eject or Safely remove USB Mass

Storage Device option, before disconnecting it from your computer. Failure to

disconnect the player properly can result in corrupted files or music tracks. See the

“Troubleshooting” section in this booklet for details.

Music tracks are played in alphanumeric order starting with the tracks in the root level

followed by those in folders. The MuVo TX FM will only play supported music tracks that

are stored in either the root level or the first level of a folder. Tracks stored in sub-folders

of a folder will not be recognized.

Figure 1

Figure 2

Figure 3

MuVo TX FM QSB English 20th May.fm Page 4 Wednesday, May 19, 2004 4:44 PM

Formatting Your Player

If you need to format your player, back up the files in your player first. When you format your

player, all songs and files will be deleted. By default, your player is already formatted.

1. Connect your player to your computer's USB port.

2. Launch Windows Explorer on your computer. Your player is recognized as a Removable

Disk in Windows Explorer.

3. Right-click the Removable Disk icon and

click the Format option. The Format F:\

dialog box appears (replace F:\ with the

drive letter of your player).

4. Follow the instructions on the screen to

format your player.

5. After the formatting is complete, make sure you stop your player before disconnecting it

from your computer.

For more information about using Windows Explorer, refer to its online Help.

Your MuVo TX FM must be formatted in the FAT or FAT16 file system only. Do not select

FAT32 or NTFS. Those formats are not recognized by your MuVo TX FM.

Windows 98SE users must have MuVo TX FM drivers installed before formatting the

player.

MuVo TX FM QSB English 20th May.fm Page 5 Wednesday, May 19, 2004 4:44 PM

How To Use Your Player

Remember to unplug the USB Flash Drive from your computer and insert it into the battery

module before turning on the player. For more usage information, refer to the PDF User's

Guide. Go to d:\manual\<language>\manual.pdf (replace d:\ with the drive letter of your

CD\DVD-ROM drive and <language> with the language the document is in).

Inserting the battery

The life of a battery depends on the type of battery used. It is recommended that you use

an alkaline battery. With an alkaline battery, you can play up to fourteen hours worth of

.MP3 files or eleven hours of .WMA files.

abc

MuVo TX FM QSB English 20th May.fm Page 6 Wednesday, May 19, 2004 4:44 PM

Using Your Scroller

"Scroll Select", indicates that you should use the Scroller to scroll through options, and then

select the option by pressing the Scroller.

Using Your Player

Turning on the player

Press and hold the Play/Pause button for a few seconds. The Creative logo appears

on the screen, followed by the Creative MuVo TX FM logo, and there is music playback.

If your player contains no audio tracks, the message "No Music" or "No Recording" will appear

onscreen, depending on whether you are in Music or Recordings mode.

Turning off the player

Press and hold the Play/Pause button for a few seconds until after the Power off

message disappears

1. Use the Scroller to scroll through

options.

3. Press the Scroller to select the option.

2. Scroll to an option. 4. The selection appears.

MuVo TX FM QSB English 20th May.fm Page 7 Wednesday, May 19, 2004 4:44 PM
