Creative Muvo V200_QSG Manual de usuario

Your Player At A Glance

Liquid Crystal

Display (LCD)

Play/Pause

Microphone

Scroller

Volume

Increase

Volume

Decrease

Front View Side View

Earphone

connector

Volume

Increase

MuVo TX_CLE.book Page 1 Wednesday, December 17, 2003 2:06 PM

Getting Started

Install the Software

Your Creative NOMAD MuVo TX comes with software that helps you create audio tracks,

manage your music library and use your player.

1. Make sure that your player is not connected to your computer.

2. Insert the Installation CD into your CD-ROM drive.

3. The disc supports Windows AutoPlay mode and starts running automatically. If not, click

Start -> Run. In the Open box, type d:\ctrun\ctrun.exe (replace d:\ with the drive letter

of your CD/DVD-ROM drive), and then click the OK button.

4. Click the Install software for NOMAD MuVo TX to select it.

5. Click the OK button.

6. Follow the instructions on the screen.

7. When prompted, restart your system.

For Windows 2000/XP users:

To install the software, you must log in as the computer administrator. For more

information, refer to your operating system's online Help.

Step 1

MuVo TX_CLE.book Page 2 Wednesday, December 17, 2003 2:06 PM

Connect the USB Flash Drive to your computer

Do not press the buttons on your USB Flash Drive while connecting it to your computer.

Step 2

USB port

Battery

module

USB port

USB Flash

Drive

MuVo TX_CLE.book Page 3 Wednesday, December 17, 2003 2:06 PM

Transferring tracks or files.

1. After connecting the USB Flash Drive to your computer, you will see

Figure 1 on the player's LCD screen.

2. On your Desktop, right-click the My Computer icon, and then click

Explore. The USB Flash Drive appears as a removable disk icon

(Figure 2).

3. Drag and drop files into your player. During the transfer, Figure 3

appears on the LCD screen.

You can use other applications such as Creative MediaSource (included with the Installation

CD) to manage the music tracks in your player.

You must install the software (Step 1) before transferring tracks or files.

For Windows 98 SE users only:

Do not remove the USB Flash Drive until Figure 1 appears on the screen again for at least

five seconds.

For other Windows operating system users only:

Make sure you stop your player properly, using the Eject or Safely remove USB Mass

Storage Device option, before disconnecting it from your computer. Failure to

disconnect the player properly can result in corrupted files or music tracks. See the

“Troubleshooting” section in this booklet for details.

Music tracks in the root directory are played back first, followed by music tracks in each

folder. They are played back in alphanumeric order. Your player can recognize tracks

stored in the root directory and in only one level of sub folders.

Step 3

Figure 1

Figure 2

Figure 3

MuVo TX_CLE.book Page 4 Wednesday, December 17, 2003 2:06 PM

Formatting Your Player

If you need to format your player, backup the files in your player first. When you format your

player, all songs and files will be deleted. By default, your player is already formatted.

1. Connect your player to your computer's USB port.

2. Launch Windows Explorer on your computer. Your player is recognized as a Removable

Disk in Windows Explorer.

3. Right-click the Removable Disk icon and

click the Format option. The Format F:\

dialog box appears (replace F:\ with the

drive letter of your player).

4. Follow the instructions on the screen to

format your player.

5. After the formatting is complete, make sure you stop your player before disconnecting it

from your computer.

For more information about using Windows Explorer, refer to its online Help.

Your player does not support the FAT32 (32-bit File Allocation Table) file system. Format

your player with the FAT file system only.

Windows 98 SE users must install the NOMAD MuVo TX drivers before formatting the

player.

Windows 2000 and Windows XP users must select FAT, instead of FAT32, in the Format

F:\ dialog box before formatting the player.

MuVo TX_CLE.book Page 5 Wednesday, December 17, 2003 2:06 PM

How To Use Your Player

Remember to unplug the USB Flash Drive from your computer and insert it into the battery

module before turning on the player. For more usage information, refer to the PDF User's

Guide. Go to d:\manual\<language>\manual.pdf (replace d:\ with the drive letter of your

CD\DVD-ROM drive and <language> with the language the document is in).

Inserting the battery

The life of a battery depends on the type of battery used. It is recommended that you use

an alkaline battery. With an alkaline battery, you can play up to fourteen hours worth of

.MP3 files or eleven hours of .WMA files.

abc

MuVo TX_CLE.book Page 6 Wednesday, December 17, 2003 2:06 PM

Using Your Scroller

"Scroll Select", indicates that you should use the Scroller to scroll through options, and then

select the option by pressing the Scroller.

Using Your Player

Turning on the player

Press and hold the Play/Pause button for a few seconds. The Creative logo appears

on the screen, followed by the MuVo TX logo, and there is music playback.

If your player contains no audio tracks, the message "No Music" or "No Voice" will appear

onscreen, depending on whether you are in Music or Voice mode.

Turning off the player

Press and hold the Play/Pause button for a few seconds until after the Power off

message disappears

1. Use the Scroller to scroll through

options.

3. Press the Scroller to select the option.

2. Scroll to an option. 4. The selection appears.

MuVo TX_CLE.book Page 7 Wednesday, December 17, 2003 2:06 PM

Stopping/Pausing a music track

Press the Play/Pause button .

Skipping folders (Albums)

1. Press the Scroller.

2. Scroll Select Skip Folder (Figure 4).

3. The Skip Folder menu appears.

4. Scroll to the folder that you want to skip to.

5. To resume normal playback, press the Scroller again.

Making a voice recording

1. Press the Scroller. Scroll Select Recording (Figure 5).

2. The recording bar appears onscreen.

3. Press the Play/Pause button to start the recording.

4. Press the Play/Pause button again to end the

recording.

5. A name is automatically assigned to your recording and is saved in your player. The naming

convention typically used is: VOC [Current File Number].

For easy navigation, store your albums as folders in the root directory.

When recording, the available recording time is determined by:

- available memory space in your player.

- battery power remaining in your player.

Figure 4

Figure 5

MuVo TX_CLE.book Page 8 Wednesday, December 17, 2003 2:06 PM

Software Included

Creative MediaSource

Creative MediaSource allows you to rip CDs and create high quality digital audio files, play and

organize media files on your computer as well as transfer music tracks or files seamlessly to

and from your player. Special features such as SMARTFIT, using intelligent track management

and WMA compression, enables you to transfer a higher number of music tracks to your

player. For more information, refer to the Creative MediaSource online Help.

Go to Start -> Programs/All Programs -> Creative -> Creative MediaSource ->

Creative MediaSource Organizer.

MuVo TX_CLE.book Page 9 Wednesday, December 17, 2003 2:06 PM

Troubleshooting

When you turn on the player, an error message “File system error”

appears before the player turns off.

Try formatting your player. See section "Formatting Your Player".

After playing the first few music tracks, the player skips a music track.

The player will only play .MP3, .WMA or .WAV recordings. Other files will be skipped.

Files or music tracks are corrupted when transferred to the player.

After the transfer is complete, make sure you stop your player before disconnecting it from

your computer.

To stop your player in Windows 98 SE, do not remove the USB Flash

Drive until Figure 1 appears on the LCD screen again for at least five

seconds.

To stop your player in Windows 2000, Windows Me or Windows XP, click the Safely

Remove Hardware icon on the Taskbar, click Safely remove USB Mass Storage

Device, and disconnect your player when you are prompted to do so.

The player turns off immediately after it is turned on.

Check that the battery is not depleted.

I have to change the battery quite often. Is there anything I can do to

make it last longer?

Some operations consume more battery power:

• a long backlight timeout setting. A shorter timeout conserves battery power.

• too much use of fast forward/reverse.

• turning the player on/off too many times.

• use of passive speakers or high-powered headphones.

• playback of .WMA files.

MuVo TX_CLE.book Page 10 Wednesday, December 17, 2003 2:06 PM
