AGPtek C2 Manual de usuario

CONTENT

English

Deutsch

Français

Italiano

Español

日本語

01/09

10/19

20/29

30/39

40/49

50/58

Charge the Player

Buttons and Controls

1. Use 5V/500mA Charger

Plug one end of the micro USB cable into the USB port of a charger, the other

end to the port on your device. After fully charged, disconnect the cable from

your device by pulling it straight outward.

2. Charge by Computer

Connect the device to a running computer via included USB cable.

Note:

To prevent battery deterioration, you are supposed to charge the battery at

least once every half a year or every year.

1. Menu

2. Back

3. Move up; Lyrics on/off

4. Move down

5. Previous/Fast backward

6. Next/Fast forward

7. Enter/Play /Pause

8. Power button; Screen on/off

9. Volume up

10. Volume down

11. USB interface

12. Micro SD card slot

13. Headphone jack

Quick Guide

Music

1. Power On/Off:

Long press the power button for 3 seconds to turn on/off the player.

Short press the power button to turn on/off the screen display.

2. Home Menu:

The Home menu is the starting point of each application. There are 9 main

functions on the home menu: Music/ Bluetooth/Folder View/ Recordings / FM

radio/Tools/ Video / EBook/ Settings.

3. Basic Operation:

Tap the button / / / to choose its 9 different functions on

main interface, and tap the middle button to enter it; tap to go back;

hold to go back to the main interface directly.

Note: When is on main menu and there is music/radio playing/paused in the

background, tap to go back to music/radio playing interface.

4. Import and Transfer Music

Connect the computer via the USB cable. Copy the music and other files you

need to transfer in the computer, and then paste in the player, or just drag and

drop the music files or folders directly when connected to computer.

Note: Do not disconnect your player during the transferring process. If you do,

the file being transferred will be damaged.

Find “Music” on Home menu and press the button to access to its function.

The related list will show, including: All Songs, Last played, Artists, Albums,

Genres, Playlists, Update playlists, Local folder and Card folder. Choose from

the menu, and tap the button to play the music.

- “Last played”, take you back to the song or audio file you are playing now or

played last time.

- “Update Playlists”, update music file.

Note: Local folder and card folder function is only available when memory card

inserted.

Operations on music playing interface

- While it’s on music playing interface, hold the button to fast forward,

tap to switch to next song; hold the button to fast rewind, tap to

switch to the previous song.

- Tap button to play/pause.

- Long press the button to turn on/off the lyrics display when lyrics file is

included.

Submenu

While it’s on music playing interface, tap button to access to the

submenu.

The related list will show:

- "Home", go back to main interface.

- "Shuffle", choose to turn on/off shuffle mode.

- "Repeat", choose to repeat 1, repeat all, and preview or turn off repeat

function. The player would only play the first 10 seconds of a track and then

skip if you select option "preview".

- "Equalizer", choose from the 6 sound effects, or choose "off" to turn off

equalizer

Note: You can also find "Equalizer" in "Set">"Sound settings".

- "Bookmarks", choose to add, delete or go to bookmark.

- "Variable speed playback", tap button / to adjust playback speed from

-8(Slowest) to +8(Fastest) and tap button to confirm.

-“Repeat settings”, A-B repeat settings:

1) Choose the option “Replay Mode”, tap button to confirm the starting

time A when A is flashing. Then tap the button to set the ending time

B when B is flashing. The passage from time A to B will be repeated

automatically. The icon for A-B indication will appear on the screen. Tap

button again to back to normal playback.

2) Replay times: Set the replay times from 1 to 10. Tap button / to

adjust the value and tap button to confirm.

FM Radio

Bluetooth

3) Replay intervals: Set the replay interval from 1 to 10 (seconds). Tap button

/ to adjust the value and tap button to confirm.

- "Delete", choose to delete the song that is playing now.

- "Add to playlist"/"Remove from Playlist", choose to add to or remove from

the 3 playlists.

- "Play music from…", choose to play songs from all songs/artist/album.

While it’s on radio playing interface, tap to access to its submenu which

includes: Home, Start FM radio recording, Stationlist, Save to preset, Clear

preset, Auto tune, Turner Region and FM Recording.

Auto tune/save to/Clear preset

- “Auto tune”, search stations automatically. You can see the searched stations

in “Stationlist”. While is on radio playing interface, tap to switch among

preset stations.

- “Save to preset”, save the station you are listening to “Stationlist” .

- “Clear preset”, click “Clear preset” to enter the preset list, choose the

station you want to clear, then tap and choose yes to clear the preset

station.

Start FM radio recording

Choose "Start FM Radio Recording", tap button to pause/continue, tap

The button and select “yes” to save the recording file.

Find the radio recordings in FM radio > FM recording. The radio recordings will

also be saved in Recordings > Recordings library.

Turn off radio background

While it’s on radio playing interface, tap and choose “Yes” to turn off the

radio playing background.

Find “Bluetooth” on Home menu and tap to access to its function.

Bluetooth On/Off:

Choose to enable or disable Bluetooth.

Recordings

Search for device:

When the Bluetooth is enabled, choose “Search for device” to search the

nearby devices, then all of the devices which has opened its Bluetooth will be

listed.

Device List:

Choose from the available devices and select to connect/disconnect. Select the

device you want to connect, and then click to connect. After successfully

connected, this player is ready to play music or FM radio by Bluetooth

earphones, Bluetooth speaker, etc.

Note:

- Please open the Bluetooth of the device at first if you want to connect with

the player.

- Record/ Video/Picture function is not available while using Bluetooth

function.

Find “Recordings” on the Home menu, tap button to access to its function.

The related list will show, including: Start Voice Recording, Recordings Library,

Storage(only available when memory card inserted), Record Format, VOR set.

Choose “Start Voice Recording” and tap button to start voice recording,

press again to pause. Tap the button and choose “yes” to save the

recording file.

Find the saved recordings in Recordings >Recordings library.

“Storage” , choose to store your recordings in internal or external memory.

Confirm your selection with button .

Record Format: Choose the record format between MP3/PCM.

VOR set: When you start recording under VOR mode, the recorder will start

recording automatically if sound is detected and stop recording when no

sound detected.

Video

EBook

Tools

Find "Video" on Home menu, tap button to access to its function. You will

need to choose from local folder or card folder if the memory card is inserted.

Tap button to watch videos, tap / to go to previous/next video or

hold down to fast backward/forward.

When it’s on video playing interface,tap button to access to its

submenu, including: Brightness, Repeat, Delete Video. Set according to

your preference.

Find "EBook " on main interface, tap button to access to its function.

While it’s on text playing interface, Tap button / to turn the pages.

Tap to play automatically, click again to stop.

While it’s on book reading interface, tap to enter its submenu and set

your preference, including Playsetting(set the automatic playing interval),

Page select, Bookmark select, Background color, Delete ebook, etc. Set

according to your preference.

Note: The device can only recognize the article in “txt” format.

Find "Tools" on main interface, tap button to access to its function. A

related list will show “Alarm”, "Pictures".

Pictures.

- Tap to view pictures, tap / to go to previous/next picture.

- When it’s on picture viewing interface, tap to access to its

submenu,including: Brightness, Backlight timer, Slideshow settings, Delete

picture and. Set according to your preference.

Alarm

- Select Alarm and click button to enter, set the alarm switch/ time/ cycle/

music/ volume you want.

Settings

Help and Troubleshooting

Note:

The device only supports pictures in JPG, BMP and GIF format.

Find “Settings” on main menu with the button to enter to its function. A

related list will show, including: Language, Date and time, Display settings,

Sound settings, Button lights, Shutdown settings, Information, Format Device,

Factory Settings.

Date and time: Choose “Date settings” to set date format and date. Tap

button / to switch among year|month|day, tap button /

to adjust the value of year|month|day and confirm with button .Set time

under “Time setting” and adjust the time in the same way.

Display settings: Set Brightness, Backlight timer and Screensaver.

Sound settings: Set equalizer for music playback.

Button lights: Choose to turn/off the button lights.

Shutdown settings

- Power Off: When there is no operation on the device, the device will shut off

automatically when reaches the set time;

- Sleep timer: The device will shut down automatically when reaches the set

time.

Information: check player information and disk space about your player;

Format device/Factory settings: Format the device or restore to factory

settings.

Note: Before formatting the device, please backup the file so as not to lose any

files.

Can’t turn on the player

- Please check whether the player is run out of power, connect the player to an

adapter and try again after charging.

Can’t charge the battery

- Disconnect the player, and then reconnect it.

- Charge the battery under an proper temperature within the range of 5℃(41

℉) to 35℃(95 ℉).

- Turn on the computer.

Can’t download files from computer

- Please confirm whether it’s connected properly;

- Please check whether the storage space of the internal memory is full;

- Please check whether the USB cable is damaged.

Can’t recognize the player when connected to the computer via USB

cable.

- Disconnect the player, wait for a few minutes, and then reconnect it.

- Disconnect the player, restart the computer, and then reconnect the player.

- Connect your player to another USB port on your computer.

- If the player has not been used for a long period of time, charge the player

for about 10 minutes, after which it should start operating normally again.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Reproductor de MP3 de AGPtek

Manuales populares de Reproductor de MP3 de otras marcas

Blaupunkt

Blaupunkt Compact Drive MP3 Manual de usuario

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manual de usuario

Meizu Electronic Technology

Meizu Electronic Technology E5 Manual de usuario

Naxa

Naxa NMV-173NX Manual de usuario

Philips

Philips PSA250 Manual de usuario

Zipy

Zipy go! Waving Manual de usuario

Sylvania

Sylvania SMPK4068 Manual de usuario

Sony

Sony NW-MS7 - Memory Stick Walkman Manual de usuario

Irradio

Irradio RF-42UC Manual de usuario

NABAIJI

NABAIJI SWIM MUSIC 100 Manual de usuario

Laser

Laser MP3-A9-4GB Manual de usuario

Samsung

Samsung YP-T7F Manual de usuario

Savant

Savant SMS-1001-00 Guía de referencia rápida

Trevi

Trevi XP 71 BT Manual de usuario

MobiBlu

MobiBlu DAH-1500i Manual de usuario

Denver

Denver MPS-201 Manual de usuario

Steren

Steren MP3-002 Manual de usuario

Kenwood

Kenwood M1GD50 Manual de usuario
