Concept Pro VCP7238-AHD Manual de usuario

VCP7238-AHD

USER MANUAL

AHD body camera with

CVBS output

1. This installation should be made by a qualified service person and should

abide to all local codes.

2. Do not disassemble the camera - this is to prevent electronic shock

and/or malfunction. Do not loosen any screws on the camera body.

3. Do not touch the front glass directly. If necessary, use a soft cloth to wipe off

dust or debris.

4. Avoid installation on surfaces subjected to frequent vibration or shocks.

5. Do not operate the camera beyond its temperature range or power source

ratings.

6. Should any damage or suspected damage occur, shutdown the power

source, unplug and contact your service provider.

7. Do not install the camera under unstable lighting conditions. Severe

lighting change or flicker can cause the camera to work improperly.

8. Never use the camera close to a gas or oil leak.

9. Do not drop the camera or subject the unit to physical shocks.

10. Never keep the camera facing directly to strong light.

11. Do not install near devices which emit a strong electro-magnetic field.

12. Unplug the camera from the power source before maintenance.

13. Use a soft cloth only for cleaning.

14. If the camera may be exposed to weather conditions, dust particles or

moisture install in an IP rated housing suitable to the conditions.

PLEASE FOLLOW THE ABOVE CAUTIONS – FAILURE TO DO SO MAY

INVALIDATE THE WARRANTY OR CAUSE SERIOUS INJURY.

CAUTION

INSTALLATION

IMPORTANT: ENSURE ALL CAUTIONARY PROCEDURES ARE

OBSERVED DURING INSTALLATION.

It is recommended the VCP7238 is tested during the most

demanding environmental conditions such as low light or bright

sunlight to ensure continuity of effective CCTV monitoring.

Remove the camera unit carefully from the box, reserving the

accessory contents in a safe place.

Point the Camera towards the intended area to be monitored.

Check the power supply voltage and connect your power supply into

the power port on the Camera.

Attach a test monitor to the video out BNC port and adjust the lens

to give the required image

Adjust the Camera picture using the OSD menu as necessary.

TROUBLESHOOTING

Ensure all power and cable connections are correct between the

Camera, power source, monitor, telemetry devices and DVR if used

Example

CONNECTION EXAMPLE

LENS ADJUSTMENTS

PSU

Built in Lens

Top Cover

Zoom Handle

Focus Handle

OSD

OSD Controller

How to change the video:

To change the video output of the VCP7238-AHD press and hold the

OSD buttons on the rear of the camera for 4 seconds:

•Press and hold left for CVBS

•Press and hold right for AHD

•Press and hold down to switch PAL / NTSC

MAIN MENU

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY & NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

OFF

AT W

EXT

SAVE&END

* Set SHARPNESS, MONITOR, LSC, VIDEO OUT

* Save & END

* ATW(Auto Tracking White Balance)

* AWC -> SET : White Balance is xed at the value when

*(enter) is pressed and keep the value

* INDOOR : White Balance is xed about 3100K

* OUTDOOR : White Balance is xed about 5100K

* Manual : Adjustable value of BLUE and RED

* AWB

* AUTO : DAY or NIGHT is setting automatically by light level

coming through lens.

DELAY TIME, D -> N and N -> D, can set in the menu

* COLOR : Color video output

* B/W : B/W video output regardless of light level

(removes IR cut lter automatically)

* EXT : Day(Color) or Night(B/W) is decided by external light

sensor(CDS sensor)

All IR LED cameras should set EXT.

* Set 2 DNR, 3 DNR

Select OFF, BLC, HSBLC

OSD

EXPOSURE

1. SHUTTER

2. AGC

3 . S E N S - U P

4. BRIGHTNESS

5. D-WDR

6. DEFOG

7. RETURN

1 / 3 0

OFF

RET

6 6

1 5

Set mounted Lens type, DC, VIDEO, MANUAL or P-IRIS.

DC Lens : * MODE : Set INDOOR or OUTDOOR

* If camera is equipped auto iris lens, recommend to set AUTO.

* In the region NTSC but 50Hz power, set to FLK(Flickerless).

In the FLK mode, sensitivity will be downed under low light.

* x2 ~ x30, SENS-UP is working at selected frame integration rate

regardless of light level.

* If set to AUTO, can set limitation of maximum integration frame

rate in the x2 ~ x30

* Higher SENS-UP rate is higher sensitivity but slower refresh rate.

* Due to long accumulation by long shutter time, some white dots

may appear.

* Usable at AUTO or 1/60(1/50) set up

Under lowest light level, AGC is maximized by Automatic Gain Controller

Can set AGC level 1~15

* Control Brightness level. The higher, the brighter.

* Brightness is controlled by iris of auto iris lens or shutter speed of

xed iris lens.

* This is to enhance visibility in the foggy environment but the

performance is limited.

* Can set Position / Size and Gradation, if set ON.

BLC

1. LEVEL

2. AREA

3. DEFAULT

4. RETURN

MIDDLE

RET

Select Backlight mode, BLC or HSBLC, OFF

3-2. HSBLC

HLC ON

HLC OFF
