Elite

SERIES

Owner’s Guide

For Model:

ca1155E

IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is

applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR

SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.

Vehicle Security and

Keyless Entry System

2ca1155E Owners revA

Table of Contents

Using Your Remote Control.................................................................... 3

Arming the Security System .............................................................. 3

Bypassing the Shock Sensor ............................................................ 3

Disarming the Security System ......................................................... 3

Two Stage Door Unlock (optional)..................................................... 3

Activating Trunk Release (optional)................................................... 3

Activating AUX 1 (optional)................................................................ 4

Using the Progressive Car Finder Feature........................................ 4

Using the Personal Protection Alarm................................................. 4

Valet Mode ........................................................................................ 4

User Selectable Notication Chirps................................................... 4

User Selectable LED ......................................................................... 5

Manually Overriding the Security System ......................................... 5

Carjack Mode .................................................................................... 5

Status LED, Light Flashes and Siren/Horn Indications ....................... 6

Remote Control Buttons & Functions ................................................... 7

Replacing Remote Control Batteries..................................................... 7

Warranty Information .............................................................................. 8

Arming the Security System

To arm the system, exit the vehicle, close all doors, then press the button. The

parking lights will ash 2 times, indicating the system is armed, has locked the doors

(if equipped and connected) and activated the starter disable feature. The LED status

indicator will blink steadily, once per second.

NOTE: The system is equipped with a feature called Silent Choice. If enabled, the

system requires a second press of the button to activate an audible arming

response from the vehicle.

Bypassing The Shock Sensor

To arm the system and ignore the shock sensor press button, then within 5

seconds press + , the system will respond with 1 long chirp.

NOTE: The system will only change the shock sensor setting for one arm cycle and

will be defaulted back to normal operation the next time the system is armed.

Disarming the Security System

To disarm the system press the button. The parking lights will ash 1 time,

indicating the system is disarmed and has unlocked the doors (if equipped and

connected).

NOTE: The system is equipped with a feature called Silent Choice. If enabled, the

system requires a second press of the button to activate an audible disarming

response from the vehicle. If your system is set up for 2 step unlock, a third press of

unlock will activate the audible response.

Two Stage Door Unlock (Optional)

If this feature is enabled on your system, pressing the button one time will unlock

only the driver’s door. Press again within three seconds to unlock the remaining

doors.

Activating the Trunk Release Feature (Optional)

If this feature is enabled on your system, pressing and holding the button for 3

seconds will open the vehicle’s trunk or hatch.

*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more

than 2 seconds.

Using Your Remote Control

4ca1155E Owners revA

Activating the AUX 1 Output (Optional)

If this feature is enabled on your system, pressing the and buttons

simultaneously will activate an optional feature. This feature can be programmed for a

wide range of functions like power window or sunroof automation, please consult your

installing dealer to determine the functionality of your system.

Using the Progressive Car Finder Feature

Press the button to locate your vehicle. The system will ash the parking lights

and sound 5 times at low volume, increasing in volume each time the button is

pressed.

Using the Personal Protection Alarm (Panic)

Press and hold the button for 3 seconds to activate the personal protection alarm.

During panic mode, the normal function of the transmitter buttons will be suspended.

The transmitter’s and buttons can be used to lock and unlock the door (if the

option is installed). To stop the alarm, press and hold the button on the transmitter

again for 3 seconds. The system will automatically stop after 30 seconds.

Valet Mode

When valet mode is activated the status LED will light solid, and all security functions

will be disabled. To enter or exit valet mode simply follow the steps outlined below:

1. Turn the vehicle’s ignition ON.

2. Push and hold the programming/valet button.

3. The LED will turn on solid when valet mode is active

4. Release the programming/valet button.

User Selectable Notication Chirps

System ARM / DISARM chirps can be toggled ON or OFF without entering the

programming feature banks.

1. Turn the ignition ON then OFF.

2. Press and release the valet/programming button 3 times. The system

will respond with 1 chirp for ON or 2 chirps for OFF.

Carjack Mode (Anti-Hijack Mode)

This feature must be turned on in system programming, please consult your installing

dealer.

Triggering Carjack mode: While the ignition is ON and press and hold + for 2

seconds, the parking lights will ash 1 time and the system will act as follows;

1. 50 seconds after being triggered the siren will chirp for 15 seconds,

during this 15 seconds you will be alerted to push the valet button to

turn off Carjack mode. If Carjack mode is not turned off at this time it

will advance to the next step.

2. Following the 15 second chirps (total time now 65 seconds) the siren

will go into full sound and the parking lights will start ashing.

3. 90 seconds after trigger in, addition to the siren and parking lights, the

system will activate the starter kill. THE SYSTEM WILL REMAIN IN THIS

STATE UNTIL THE BATTERY IS DEPLETED.

OVERRIDE THE SYSTEM TO TURN OFF CARJACK MODE: Turn the ignition OFF

then On and press the valet button within 10 seconds.

Manually Overriding the Security System

Your system can be disarmed without the use of the transmitter. This is necessary,

since you will need the ability to operate your vehicle if the transmitter is lost or its

battery fails. To by-pass the alarm system;

1. Open the vehicle door. The alarm will sound.

2. Turn the ignition key to the ON position.

3. Within 10 seconds, press and release the valet push button switch.

The alarm system will stop sounding and enter the (by-passed) mode. You can now

start and operate the vehicle normally.

User Selectable LED

This feature will control whether the LED is ON or OFF when the system is Armed/

Locked and can be toggled ON or OFF without entering the programming feature

banks.

1. Turn the ignition ON, OFF, ON, OFF.

2. Press and release the valet/programming button 3 times. The system

will respond with 1 chirp for ON or 2 chirps for OFF.

6ca1155E Owners revA

Status LED, Light Flashes, and Siren/Horn Indications

Status LED Flash Indications

LED Flashes Function

OFF Disarmed

Slow Flash Armed

Fast Flash Passive Arming Countdown

ON (Solid) Valet Mode

2 Flashes Zone 2 Trigger, Hood / Trunk

3 Flashes Zone 3 Trigger, Door

4 Flashes Zone 4 Trigger, Shock Sensor

5 Flashes Zone 5 Trigger, Ignition

6 Flashes Zone 6 Trigger, Tilt Sensor

Siren/Horn Chirp Indications

Chirps Function

1 Disarm

2 Arm

3 Door Ajar Upon Arming

4 Disarm / Triggered

5 Car Find

Parking Light Flash Indications

Flashes Function

1 Disarm

2 Arm

3 Disarm / Triggered

5 Car Find

Remote Control Buttons & Functions

4-Button

Transm itterLock Unlock Trunk Car Find /

PanicOperation Method

Lock XPress and Release

Unlock X Press and Release

Trunk XPush and Hold (3 Sec)

Car Finde

Press and Release

Pani

Push and Hold (3 Sec)

AUX 1 XX Push and Hold (3 Sec)

Shock Bypass XX

Press and Release Lock then Pre

Lock + Car Find (within 5 Sec)

Replacing Remote Control Batteries

4 Button Remote Control - Model CAT4ME

The batteries inside each remote control should last approximately 1 year under normal

use. When the batteries become weak you will notice the remote control range (the

distance from the vehicle the remote control will work) deteriorate and the small LED on

the remote control will dim. To replace the remote control batteries:

1. Remove 1 screw then disassemble the halves of the remote

control by unsnapping the back of the case.

2. Remove the old battery, observing the +/- symbols on the

batteries and replace with a new battery.

3. Reassemble the halves of the remote control and reinstall 1 screw.

4. Test operation of the remote control.

8ca1155E Owners revA

LIMITED LIFETIME WARRANTY

Applies to Code Alarm Series Control Modules, Sirens, Sensors, and Relays.

Voxx Electronics Corporation (the Company) warrants to the original purchaser of this

product that should this product or any part thereof, (other than transmitters) under nor-

mal use and conditions, be proven defective in material or workmanship during the life-

time of the vehicle, in which it was originally installed from the date of original purchase

such defect(s) will be repaired or replaced with new or reconditioned product, (at the

Company’s option) without charge for parts or repair labor. A transmitter is warranted for

12 months from the date of original purchase.

To obtain repair or replacement within the terms of this Warranty, the product is to

be delivered with proof of warranty coverage (e.g. dated bill of sale), specication of

defect(s), transportation prepaid, to an approved warranty station. This Warranty is not

transferable.

This Warranty does not cover damage to the vehicle’s electrical system or costs

incurred for removal or reinstallation of the product. This Warranty does not cover bat-

teries, broken LCD or OLED display screens, nor apply to any product or part thereof

which, in the opinion of the Company, has suffered or been damaged through alteration,

improper installation, mishandling, misuse, abuse, neglect, accident, or by removal or

defacement of the factory serial number/bar code label(s).

This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WAR-

RANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, SHALL

BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. IN NO CASE

SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL

DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY. No person or rep-

resentative is authorized to assume for the Company any liability other than expressed

herein in connection with the sale of this product.

The company does not warrant that this product cannot be compromised or circum-

vented. THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY

IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO

EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID

BY PURCHASER FOR THE PRODUCT WITHOUT COST OF INSTALLATION.

Some states do not allow limitations on how long an implied warranty lasts or the

exclusion or limitation of incidental or consequential damage so the above limitations or

exclusions may not apply to you. This Warranty gives you specic legal rights and you

may also have other rights which vary from state to state.

Voxx Electronics Corporation, 180 Marcus Blvd., Hauppauge, New York 11788 / 1-800-645-4994

128-9445

10 ca1155E Owners revA

Tabla de contenidos

Otros manuales de Alarma de coche de Code Alarm

Code Alarm

Code Alarm CA 420A Manual de usuario

Code Alarm

Code Alarm ca1555 Manual de usuario

Code Alarm

Code Alarm Professional ca6153 Manual de usuario

Code Alarm

Code Alarm CA-120 Manual de usuario

Code Alarm

Code Alarm CA 420 Manual de usuario

Code Alarm

Code Alarm ca 1051 Manual de usuario

Code Alarm

Code Alarm ca 1552 Professional Series Manual de usuario

Code Alarm

Code Alarm F20 Manual de usuario

Code Alarm

Code Alarm ca 5152 Manual de usuario

Code Alarm

Code Alarm ca 2051 Manual de usuario

Code Alarm

Code Alarm CA 6151 Manual de usuario

Code Alarm

Code Alarm CA 110 Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES Manual de usuario

Code Alarm

Code Alarm CATX2LED Instrucciones de funcionamiento

Code Alarm

Code Alarm CA 6151 Manual de usuario

Code Alarm

Code Alarm CA-140 Manual de usuario

Code Alarm

Code Alarm 420A Manual de usuario

Code Alarm

Code Alarm CA100 Manual de usuario

Code Alarm

Code Alarm F50 Manual de usuario

Code Alarm

Code Alarm Car Alarm CA-310 Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES CA 1551 Manual de usuario

Code Alarm

Code Alarm CA611 Manual de usuario

Code Alarm

Code Alarm 2000 Manual de usuario

Code Alarm

Code Alarm ca6355E Manual de usuario

Manuales populares de Alarma de coche de otras marcas

Clifford

Clifford 3606X Manual de usuario

Ultra Start

Ultra Start 2500M SERIES Manual de usuario

Ultra Start

Ultra Start 650 Series Manual de usuario

Audiovox

Audiovox Prestige Platinum+ APS-511C Manual de usuario

Sparkrite

Sparkrite SRA8 Manual de usuario

Viper

Viper 4708V Manual de usuario

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manual

Falcon

Falcon Predator XL3 Guía del usuario

Audiovox

Audiovox Auto Security XR91 Instrucciones de funcionamiento

Clifford

Clifford Sabre II Manual de usuario

CrimeStopper

CrimeStopper CS-8717 Guía de inicio rápido

Ultra Start

Ultra Start 450 SERIES Manual de usuario

Scytek electronic

Scytek electronic Vectra X3 Manual de usuario

Excalibur

Excalibur AL-1860-EDPB Manual de usuario

Clifford

Clifford CYBER 2 Manual de usuario

Gemini

Gemini 7057 Manual de usuario

FlashLogic

FlashLogic FLRSBA PRESTIGE Manual de usuario

Magicar

Magicar FAI-440 Manual de usuario
