Owner's Manual

CA 170

Remote Vehicle Control System

Vehicle Security System with Two

Way Confirming LCD Remote

Control

Table of Contents

Using Your Remote Control .......................................................... 3

Arming the security system

Passive Arming

Hidden alarm function

Disarming the security system

Two stage door unlock*

Automatic rearm

Valet mode

Using Your Remote Control, continued .................................... 4

Activating trunk release*

Activating optional AUX 1*

Using the car finder feature

Using the personal protection alarm

2-car mode

Anti-car jacking mode

Additional LCD Remote Control Features ............................... 5

LCD Icons and their Indications ............................................... 6

LED and Siren/Horn Indications ............................................... 7

Replacing Remote Control Batteries ....................................... 8

Emergency Override Procedure .............................................. 9

Warranty Information.............................................................. 10

* May require additional installation labor, components and installation cost

Using Your Remote Control

Arming the Security System

To arm the system, exit the vehicle, close all doors, then press the LOCK icon button on the remote

control. The system will sound once and the parking lights will flash once, indicating the system is

armed. The doors will also lock at this time (if equipped and connected). The status indicator (red

warning light on the dash) will blink steadily, once per second. To arm the system silently, press the

LOCK and UNLOCK icon buttons for 1 second. The parking lights will flash 1 time, indicating the

system is armed, has locked the doors (if equipped and connected) and activated the starter disable

feature. The status indicator (red warning light on the dash) will blink steadily, once per second.

Passive Arming Bypass

If passive arming is enabled on your system, while the system is disarmed, Press the TRUNK button

twice, the system will respond with [1] chirp and the LED will turn “ON”. The security system will remain

in this temporally by-passed state for as long as you wish. To exit passive by-pass, press the

transmitter LOCK or UNLOCK button and the system will return to normal status.

Hidden Alarm Function

Press the TRUNK button first, within 3 seconds press the LOCK button to activate the hidden alarm

function. The security system will arm and with “Hidden Alarm Function”. The siren / horn will be

silenced even if the system is triggered while in the armed status but the 2-way remote will respond.

Disarming the Security System

To disarm the system press the UNLOCK icon button. The system will sound twice and the parking

lights will flash twice, and the doors will unlock (if equipped and connected). To disarm the system

silently, press the LOCK and UNLOCK icon buttons for 1 second. The parking lights will flash,

indicating the system is disarmed and has unlocked the doors (if equipped and connected).

Two Stage Door Unlock (Optional)

If this feature is enabled on your system, pressing the UNLOCK icon button one time on the remote

control will unlock only the driver’s door. Press UNLOCK again within three seconds to unlock the

remaining doors.

Automatic Re-Arm

If this feature is enabled on your system, the security system will automatically re-arm itself 60 seconds

after disarming with remote transmitter. The Automatic Re-Arm feature will cancel if any door is opened

before the 60 second timer has elapsed.

Valet Mode

To engage valet mode:

1. Turn the ignition key to the ON position.

2. Press and hold the emergency override button.

3. The red dashboard mounted LED will light solid indicating that the system is in valet mode.

When valet mode is activated the dash mounted status LED will light solid, and all security functions

will be disabled.

To disengage valet Mode:

1. Turn the ignition key to the ON position.

2. Press and release the emergency override button.

3. The red dashboard mounted LED will turn off indicating that the system hasexited valet

mode.

*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for

more than 2 seconds.

Using Your Remote Control, continued

Activating the Trunk Release Feature (Optional)

If this feature is enabled on your system, pressing and holding the TRUNK icon button on the remote

control for 2 seconds will open the vehicle’s trunk or hatch.

Activating Optional AUX 1 (Optional)

If this feature is enabled on your system, pressing the LOCK and TRUNK icon buttons on the remote

control simultaneously will activate an optional feature. This feature can be programmed for a wide

range of functions like power window or sunroof automation, please consult your installing dealer to

determine the functionality of your system.

Using the Car Finder Feature

When the system is armed press the LOCK icon button on the remote control to locate your vehicle.

The system will sound 6 times and the parking lights will flash 12 times.

Using the Personal Protection Alarm (Panic)

Press and hold the LOCK icon button on the remote control for 3 seconds to activate the personal

protection alarm. To stop the panic alarm press LOCK or UNLOCK on the transmitter one time. The

system will automatically stop after 30 seconds.

2 Car Mode

It is possible to program your remote transmitter to operate 2 vehicles with a CA 170 installed in

each. To active 2 car mode first enter TRANSMITTER FUNCTION MODE by pressing and holding the

TRUNK and STAR buttons for 3 seconds, the transmitter will give a loud beep, then press and

release the ”IIII

IIII

II” icon button. The LCD screen will display the ”IIII

IIII

II” icon and will now operate vehicle

#2. NOTE: The transmitter must first be programmed to the second vehicle.

Car Jack Mode

ACTIVE Car Jack mode: With ignition ON press and hold the LOCK and UNLOCK buttons for 2

seconds. The parking lights will turn on for 1.5 seconds to indicate Car Jack mode has been entered.

PASSIVE Car Jack mode: Turn the ignition ON, Car Jack mode is automatically entered.

TRIGGERING Car Jack mode: Car Jack mode will be triggered when a door is opened then closed.

When Car Jack mode is on and the system will act as follows;

1. 50 seconds after being triggered the siren will chirp for 15 seconds, during this 15

seconds you will be alerted to push the valet button to turn off Car Jack mode. If Car Jack

mode is not turned off at this time it will advance to the next step.

2. Following the 15 second chirps (total time now 65 seconds) the siren will go into full

sound and the parking lights will start flashing.

3. 90 seconds after trigger in, addition to the siren and parking lights, the system will activate

the starter kill. THE SYSTEM WILLREMAIN INTHIS STATE UNTILTHE BATTERYIS

DEPLETED.

OVERRIDE THE SYSTEM TO TURN OFF CAR JACK MODE: Turn the ignition OFF then On and press

the valet button within 10 seconds. NOTE: If you have activated the password pin code you will need

to use your pin code to override Car Jack mode. (see your dealer about the password pin code

feature).

Additional 2-Way LCD Remote Control Functions

Check Vehicle Status

Press and release the TRUNK button and then simultaneously press the LOCK and UNLOCK buttons,

the transmitter will respond with one melody sound and display the current status of the vehicle.

LCD Remote Control Display Illumination

Press and release the TRUNK button on the LCD remote control one time. The display will illuminate for

5 seconds.

LCD Remote Control Vibrate or Tones

First enter TRANSMITTER FUNCTION MODE by pressing and holding the TRUNK and STAR buttons for 3

seconds, the transmitter will give a loud beep, then press and release VIBRATE icon button.

Page Call Out

With the ignition OFF, press the valet programming button for two seconds, the vehicle will chirp one time

and the 2-way transmitter will play the paging melody and display the call icon.

Bypassing The Shock Sensor

Press LOCK to arm the system then within 3 seconds press LOCK again.

NOTE: The system will only change the shock sensor setting for one arm cycle and will be defaulted back to

normal operation the next time the system is armed.

Battery Save Mode

While in POWER SAVE MODE the 2-way LCD transmitter will NOT look for any incoming signals from the

main unit until a button is pressed. The LCD screen will display SAVE to indicate that power save mode is

ON. To enter power save mode first enter TRANSMITTER FUNCTION MODE by pressing and holding the

TRUNK and STAR buttons for 3 seconds, the transmitter will give a loud beep, then press and release

the SAVE icon button.

Clear Flashing Icons and Melody Sound

Press the TRUNK button, within 3 seconds simultaneously press the LOCK and STAR buttons. This will

clear the melody sound and flashing icons on the LCD screen.

Stopping LCD Trigger Melody

To stop the alarm trigger melody if the system has been triggered WITHOUT disarming the system, press

any button one time only, this will not send a command to the vehicle at this time and the alarm will

continue to sound.

Out of Range Indication

If this option is selected in programming the unit will check if it is within range every 20 minutes. If the

transmitter is within range the ANTENNA icon will be displayed on the LCD screen, if the remote is out

of range the transmitter will sound 5 short beeps and the ANTENNA icon will disappear.

LCD Remote Control ICON’s

IGN

ARM

SAVE

LOCK UNLOCK

SYSTEM ARMED VALET MODE

TRANSMITTING IN-RANGE INDICATOR

HOOD/TRUNK TRIGGER DOOR TRIGGER

WARN AWAY TRIGGER FULL SHOCK TRIGGER

IGNITION ON/TRIGGER ENGINE RUNNING

TIME CONTROL START 2 CAR MODE

BATTERY INDICATOR BATTERY SAVE MODE

PAGE FROM VEHICLE VIBRATE/SILENT MODE

* Some LCD ICON’s may represent features not available on all models.

LED and Siren/Horn Indications

LED Display Indications

LED Function

OFF DISARMED

SLOW FLASH ARMED

FASTFLASH PASSIVEARMING

ON (SOLID) VALETMODE

2FLASH... PAUSE ZONE 2 TRIGGER, HOOD/TRUNK

3FLASH... PAUSE ZONE 3 TRIGGER, DOOR

4FLASH... PAUSE ZONE 4 TRIGGER, SHOCK

5 FLASH... PAUSE ZONE 5 TRIGGER, IGNITION

Siren/Horn Indications

Chirps Function

1 ARM

2 DISARM

3 DOORAJAR UPONARMING

4 DISARM/ TRIGGERED

6 CAR LOCATOR

Parking Light Flash Indications

Flashes Function

1 ARM

2 DISARM

3 DISARM/ TRIGGERED

12 CAR LOCATOR

Replacing Remote Control Batteries

2-way LCD Remote Control:

The AAA alkaline battery inside the 2-way LCD remote control should last approximately 1 year under

normal use. When the batteries become weak you will notice the remote control range (the distance

from the vehicle the remote control will work) deteriorate and the BATTERY icon on the LCD remote

control will show.

1. Slide the small release tab on the back of the remote control to the unlock position.

2. Gently slide the battery cover off of the remote control.

3. Remove the old AAA battery, observing the +/- symbols on the battery,

and replace with a new AAA battery.

4. Gently slide the battery cover on to the back of the remote control and lock the release tab in

place.

5. Test operation of the remote control.

1-Way 4 Button Remote Control:

The 12 volt battery (model GP23a) inside each remote control should last approximately 1 year under

normal use. When the batteries become weak you will notice the remote control range (the distance

from the vehicle the remote control will work) deteriorate and the small LED on the remote control will

dim. To replace the remote control batteries:

1. Gently unsnap the halves of the remote control apart.

2. Remove the 12 volt battery out of the circuit board, observing the +/- symbols on the

batteries and replace with new 12 volt battery.

3. Gently snap the halves of the remote control back together.

4. Test operation of the remote control.

Emergency Override Procedure

If your transmitter is lost or disabled, it will be necessary use the emergency override button to turn the

security system off. There are two types of emergency override procedures. Check with your installing

dealer to find out what has been activated on your system.

Standard Emergency Override Procedure

1. Enter the vehicle, the security system will trigger.

2. Turn the ignition key to the ON position.

3. Press and release the emergency override button. The security system will turn off.

Note: If the automatic arming feature is enabled on your system. The security system will re-arm the next

time the ignition key is turn off and the vehicle’s doors are closed.

Coded Override Procedure

The system has an optional override mode that allows you to program a 2-digit personal code using the

emergency override button offering a higher level of security. This feature must be enabled by your

installing dealer. (see install manual for pin code programming)

1. Enter the vehicle, the security system will trigger.

2. Turn the ignition switch to the ON position.

3. Within 5 seconds press the emergency override button the number of times

corresponding to the first digit of your personal code. If correctly entered the

systems siren/horn will stop.

4. Within 15 seconds turn the ignition key OFF, then ON.

5. Within 15 seconds press the emergency override button the number of times

corresponding to the second digit of your personal code.

6. Within 5 seconds turn the ignition key OFF.

7. If entered correctly the security system will chirp 4 times and the parking lights will

flash 3 times to indicate the system has been disarmed.

NOTE: You must override the system within 60 seconds or the system will automatically re-arm

Code Systems, Inc. Limited Lifetime Warranty

Code Systems Inc. (“CODE”) warrants to the ORIGINAL PURCHASER of this CODE vehicle security product

(the “Product”), purchased from an authorized CODE dealer, that (except as provided below) should this Product under

normal use and conditions, be proven defective in material or workmanship DURING THE LIFETIME OF THE VEHICLE IN

WHICH IT WAS ORIGINALLYINSTALLED, such defect(s) will be repaired or replaced (at CODE’s option) without charge for

parts directly related to repairs of the defect(s).

Switches, indicator lights, and transmitter cases are similarly warranted to the original purchaser for a period of

one (1) year from the date of purchase of the Product.

CODE accessories, sold separately, are covered by the applicable warranty accompanying the accessory.

This warranty is non-transferable, non-assignable and is voided when: (1) the Product is removed from the

vehicle in which it was originally installed; or (2) the vehicle in which the Product was originally installed is transferred to

another party.

This warranty does not apply to any product damaged by accident, physical or electrical abuse, improper

installation, alteration, or use contrary to its intended function, fire, flood, or other natural acts.

In order for the Product to be repaired or replaced under the terms of this warranty, the defective Product must

be returned to an authorized CODE dealer and accompanied by a copy of the retail sales receipt. The date of purchase and

year, make and model of the vehicle in which the Product was originally installed must be clearly indicated on the sales

receipt.

This warranty is exclusive and CODE MAKES NO OTHER WARRANTIES EXPRESSED OR IMPLIED. ANY

IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PAR-

TICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. IN NO CASE SHALL

CODE BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER

WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER.

CODE does not warrant that the Product cannot be compromised or circumvented. THE EXTENT OF CODE’S LIABILITY

UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT

SHALL CODE’S LIABILITYEXCEED THE PURCHASE PRICE PAID BY THE ORIGINALPURCHASER OF THE PRODUCT

WITHOUT INSTALLATION LABOR.

Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above

limitation may not apply to you. This warranty gives you specific legal rights and you may also have other rights which

vary from state to state

Otros manuales para CA 170

Tabla de contenidos

Otros manuales de Alarma de coche de Code Alarm

Code Alarm

Code Alarm ca 5152 Manual de usuario

Code Alarm

Code Alarm ca 1151 Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES Manual de usuario

Code Alarm

Code Alarm CATX510 Instrucciones de funcionamiento

Code Alarm

Code Alarm caSEC Manual de instalación y funcionamiento

Code Alarm

Code Alarm CA-160 Manual de usuario

Code Alarm

Code Alarm CA-230 Manual de usuario

Code Alarm

Code Alarm CA 650 Manual de usuario

Code Alarm

Code Alarm CSI-300 Manual de usuario

Code Alarm

Code Alarm Elite ca1155E Manual de usuario

Code Alarm

Code Alarm Car Alarm Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES Manual de usuario

Code Alarm

Code Alarm CA 310 Manual de usuario

Code Alarm

Code Alarm SRT 5500 Manual de usuario

Code Alarm

Code Alarm CA611 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 1050 Manual de usuario

Code Alarm

Code Alarm CA1355E Manual de usuario

Code Alarm

Code Alarm Professional ca6153 Manual de usuario

Code Alarm

Code Alarm ca 1151 Manual de usuario

Code Alarm

Code Alarm CA 610 Manual de usuario

Code Alarm

Code Alarm CA 6551 SST Manual de usuario

Code Alarm

Code Alarm CA100 Manual de usuario

Code Alarm

Code Alarm F20 Manual de usuario

Code Alarm

Code Alarm CA 6151 Manual de usuario

Manuales populares de Alarma de coche de otras marcas

Clifford

Clifford 3606X Manual de usuario

Ultra Start

Ultra Start 2500M SERIES Manual de usuario

Ultra Start

Ultra Start 650 Series Manual de usuario

Audiovox

Audiovox Prestige Platinum+ APS-511C Manual de usuario

Sparkrite

Sparkrite SRA8 Manual de usuario

Viper

Viper 4708V Manual de usuario

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manual

Falcon

Falcon Predator XL3 Guía del usuario

Audiovox

Audiovox Auto Security XR91 Instrucciones de funcionamiento

Clifford

Clifford Sabre II Manual de usuario

CrimeStopper

CrimeStopper CS-8717 Guía de inicio rápido

Ultra Start

Ultra Start 450 SERIES Manual de usuario

Scytek electronic

Scytek electronic Vectra X3 Manual de usuario

Excalibur

Excalibur AL-1860-EDPB Manual de usuario

Clifford

Clifford CYBER 2 Manual de usuario

Gemini

Gemini 7057 Manual de usuario

FlashLogic

FlashLogic FLRSBA PRESTIGE Manual de usuario

Magicar

Magicar FAI-440 Manual de usuario
