Code Alarm CA 6551 SST Manual de usuario

PROFESSIONAL

SERIES

Owner’s Guide

For Models:

CA 6551

CA 6551 SST

IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is

applicable to most vehicles. However, due to the configuration of some vehicles, some functions AND/OR

SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.

Deluxe Vehicle Security and

Remote Start System with 2 Way

Confirming LCD Remote Control

Table of Contents

Using Your Remote Control ............................................................... 3

Arming the Security System ............................................................ 3

Passive Arming Bypass ................................................................... 3

Bypassing the Shock Sensor .......................................................... 3

Hidden Alarm Function ...................................................................... 3

Disarming the Security System ........................................................ 3

Two Stage Door Unlock (optional) ................................................... 4

Activating Trunk Release (optional) ................................................ 4

Activating Optional AUX 1 (optional) ............................................... 4

Using the Progressive Car Finder Feature ...................................... 4

Using the Personal Protection Alarm ............................................... 4

Programmed Transmitter Notification .............................................. 4

Valet Mode ........................................................................................ 5

Eliminating Arm / Disarm Notification Chirps .................................... 5

Manually Overriding the Security System ....................................... 5

Car Jack Mode .................................................................................. 6

Using Your Remote Vehicle Starter ................................................. 6

Remote Starting Your Vehicle .......................................................... 6

Remote Start Shutdown ................................................................... 6

Entering Your Vehicle while it is Running via Remote Start ........... 7

Preheating or Precooling the Vehicle’s Interior ............................... 7

User Programmable Run Time / Run Time Extension ...................... 7

Using the “Quick-Stop” Feature ....................................................... 7

Operating the 2 / 3 Hour Start Up Timer Mode ................................ 8

Turbo Timer Mode (optional) ............................................................ 8

Operating the Daily Start Timer ........................................................ 9

Remote Start Safety Features ......................................................... 9

LED and Siren/Horn Indications ....................................................... 10

Additional 2-Way LCD Remote Control Functions ...................... 11

LCD Remote Control ICON’s ............................................................ 13

Transmitter Button Functions ......................................................... 14

Replacing Remote Control Batteries ............................................. 16

Warranty Information ......................................................................... 17

Arming the Security System

To arm the system, exit the vehicle, close all doors, then press the button. The

parking lights will flash 2 times, indicating the system is armed, has locked the

doors (if equipped and connected) and activated the starter disable feature. The

LED status indicator will blink steadily, once per second.

NOTE: The system is defaulted with Silent Choice enabled, which requires a

second press of the button to activate an audible arming response from the

vehicle.

Passive Arming Bypass

If passive arming is enabled on your system, while the system is disarmed, press

+ , the system will respond with 1 chirp and the LED will turn on. The

security system will remain in this temporally bypassed state for as long as you

wish. To exit passive bypass, press the or button and the system will return

to normal status.

Bypassing The Shock Sensor

To arm the system and ignore the shock sensor press button, then within 5

seconds press + , the system will respond with 1 long chirp.

NOTE: The system will only change the shock sensor setting for one arm cycle

and will be defaulted back to normal operation the next time the system is armed.

Hidden Alarm Function

Press the button first, within 3 seconds press the button to activate the

hidden alarm function. The security system will arm with “Hidden Alarm Function”

in which the siren / horn will be silenced if the system is triggered.

Disarming the Security System

To disarm the system press the button. The parking lights will flash 1 time,

indicating the system is disarmed and has unlocked the doors (if equipped and

connected).

NOTE: The system is defaulted with Silent Choice enabled, which requires a

second press of the button to activate an audible arming response from the

vehicle. If your system is set up for 2 step unlock, a third press of will activate

the audible response.

*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more

than 2 seconds.

Using Your Remote Control

Using the Progressive Car Finder Feature

Press the button to locate your vehicle. The system will sound 5 times at low

volume, increasing in volume each time the button is pressed.

Using the Personal Protection Alarm (Panic)

Press and hold the button for 3 seconds to activate the personal protection

alarm. During panic mode, the normal function of the transmitter buttons will be

suspended. The transmitter’s and buttons can be used to lock and unlock the

door (if the option is installed). To stop the alarm, press and hold the button on

the transmitter again for 3 seconds. The system will automatically stop after 30

seconds.

Two Stage Door Unlock (Optional)

If this feature is enabled on your system, pressing the button one time will

unlock only the driver’s door. Press again within three seconds to unlock the

remaining doors.

Activating the Trunk Release Feature (Optional)

If this feature is enabled on your system, pressing and holding the button for 3

seconds will open the vehicle’s trunk or hatch.

Activating Optional AUX 1 (Optional)

If this feature is enabled on your system, pressing the and buttons

simultaneously will activate an optional feature. This feature can be programmed

for a wide range of functions like power window or sunroof automation, please

consult your installing dealer to determine the functionality of your system.

Programmed Transmitter Notification

As a security precaution each time the vehicle’s ignition is turn on the status LED

light with flash the number of transmitters programmed into the system. This helps

to identify unauthorized transmitters from accessing your vehicle. If you believe an

unauthorized transmitter has been programmed to your system, contact your

installing dealer for assistance.

Valet Mode

When valet mode is activated the status LED will light solid, and all security

functions will be disabled. To enter or exit valet mode simply follow the 4 steps

outlined below:

1. Turn the vehicle’s ignition ON.

2. Push and hold the programming/valet button.

3. The LED will turn on solid when valet mode is active

4. Release the programming/valet button.

Manually Overriding the Security System

Your system can be disarmed without the use of the transmitter. This is

necessary, since you will need the ability to operate your vehicle if the transmitter

is lost or its battery fails. To by-pass the alarm system;

1. Open the vehicle door. The alarm will sound.

2. Turn the ignition key to the ON position.

3. Within 10 seconds, press and release the valet push button switch.

The alarm system will stop sounding and enter the (by-passed) mode. You can

now start and operate the vehicle normally.

Eliminating Arm / Disarm Notification Chirps

System ARM/DISARM chirps can be toggled ON or OFF without entering the

programming feature banks.

1. Turn the ignition ON then OFF.

2. Press and release the valet/programming button 3 times. The system

will respond with 1 chirp for ON or 2 chirps for OFF.

Using Your Remote Vehicle Starter

Car Jack Mode

This feature must be turned on in system programming, please consult your

installing dealer.

Triggering Car Jack mode: While the ignition is ON and press and hold + for 2

seconds, the parking lights will flash 1 time and the system will act as follows;

1. 50 seconds after being triggered the siren will chirp for 15 seconds,

during this 15 seconds you will be alerted to push the valet button to

turn off Car Jack mode. If Car Jack mode is not turned off at this time it

will advance to the next step.

2. Following the 15 second chirps (total time now 65 seconds) the siren

will go into full sound and the parking lights will start flashing.

3. 90 seconds after trigger in, addition to the siren and parking lights, the

system will activate the starter kill. THE SYSTEM WILL REMAIN IN THIS

STATE UNTIL THE BATTERY IS DEPLETED.

OVERRIDE THE SYSTEM TO TURN OFF CAR JACK MODE: Turn the ignition OFF

then On and press the valet button within 10 seconds.

Remote Starting Your Vehicle

To activate the remote vehicle start function, press and release the button 2

times within 2 seconds. The system will sound, the parking lights will flash 1 time

and the system will check the vehicle to ensure it is safe to start. If all safety

parameters are correct, the vehicle will start within 5 seconds. The vehicle’s

parking lights will turn on (or flash depending on system settings) as a visual

indication that the vehicle has started and is running.

If your vehicle stalls or does not start, the system will pause 5 seconds, then try 2

more times to start the vehicle (a total of 3 attempts). The system will pause 5

seconds between each start attempt. If the vehicle does not start after the 3rd

attempt, the system will abort the remote vehicle start process.

Remote Start Shutdown

Press and hold the button for 3 seconds to turn the vehicle off.

Using the “Quick-stop” Feature

If you want to make a short stop and keep your vehicle running (to keep the

interior warm or cool), the quick-stop feature allows you to do this while keeping

your vehicle secure and your keys with you.

To engage quick stop:

1. Stop the vehicle and place the transmission in PARK.

2. With your foot off the brake pedal, press and release the button 2

times within 2 seconds. The LED will flash 3 times to confirm quick

stop is entered.

3. Remove the keys from the ignition and exit the vehicle. Press the

button to lock the vehicle’s doors if desired.

Note: Do not leave children or animals unattended in the vehicle when using the

quick-stop feature.

Entering the Vehicle while it is Running via Remote Vehicle Start

1. Unlock the vehicle’s doors.

2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!

3. Insert the key into the ignition switch and turn to the ON or RUN

position.

4. Press the brake pedal. The remote vehicle starter will disengage and

the vehicle will operate normally.

Preheating or Precooling the Vehicle’s interior

Before exiting the vehicle, set the temperature controls to the desired setting and

operation. After the system starts the vehicle, the heater or air conditioner will

activate and heat or cool the vehicle’s interior to your setting.

User Programmable Run Time / Run Time Extension

The system has the ability to allow the user to extend the time the vehicle will be

running under control of the remote start. This will only extend the run time back to

the current run time setting during the current remote start cycle. If your system is

set to run 15 minutes and the time remaining is 4 minutes, extending the run time will

reset the countdown timer to 15 minutes and your vehicle will continue to run for

another 15 minutes. Follow the steps below to extend the vehicle’s run time.

1. The remote start must already be active.

2. Press and release the button 4 times.

3. The system will chirp to confirm that the run time has been reset.

Operating the 2 / 3 Hour Start Up Timer Mode

The system has the ability to start the vehicle every 2 or 3 hours for a 48 hour

period. This feature is especially useful in cold climates where the only means to

keep the engine and engine fluids warm is to periodically start the engine. The

default setting is 3 hour, Selection between 2 or 3 hour is made in option

programming.

WARNING!

Be certain that the vehicle is outdoors before using this or any remote starting

device. A running engine produces dangerous carbon monoxide fumes which

can be harmful or fatal if prolonged exposure occurs. DO NOT remote start the

vehicle if it is garaged.

To begin the 2 / 3 hour start up timer mode:

1. Turn the vehicle’s ignition ON then OFF.

2. Press and hold the valet button.

3. Press the button 4 times, the system will;

a. When set for 3 Hour (default) - chirp 2 times and flash the

parking lights 4 times.

b. When set for 2 Hour - chirp 1 time and flash the parking

lights 2 times.

4. Release the valet button.

To exit the 2 / 3 hour start up timer mode:

1. Turn the vehicle’s Ignition ON.

1. Activate the remote vehicle start feature using the remote control.

Turbo Timer

This option will keep the engine running to allow the vehicle’s turbo to properly cool

down before shutting the engine off.

To engage the Turbo Timer feature:

1. With the vehicle running via the ignition key and your foot off of the

brake pedal.

2. Engage the vehicle’s parking brake and press the and

buttons simultaneously.

3. The vehicle’s parking lights will turn on to verify the Turbo Timer

feature has been activated.

4. Turn the ignition key OFF, the vehicle will continue to run until the pre-

programmed time has elapsed (1, 3, or 5 minutes)

To disengage the turbo timer feature, press the vehicle’s brake pedal.

Remote Start Safety Features

For safety and security reasons, the system will shutdown or prevent the remote

vehicle starter from activating if any of the following occur:

1. The vehicle hood is open.

2. The brake pedal is pressed prior to turning the ignition key to the ON

position.

3. The engine is over-revved (tach checking only).

4. Valet mode is active.

Operating the Daily Start Timer

The system has the ability to start your vehicle based on a 24-hour countdown

timer. This feature requires a two-part activation sequence. From the remote,

pressing both the & buttons together will activate the 24 hour countdown

timer (the vehicle will start 24 hours from this time). Next, When you are finished

operating the vehicle for the day, perform the following steps to complete the

process.

1. Turn the ignition ON/OFF (vehicle must be disarmed).

2. Within 10 seconds, while pressing the brake, press and release the

button twice.

3. The vehicle will emit 2 chirps.

LED and Siren/Horn Indications

LED Display Indications

LED Function

OFF DISARMED

SLOW FLASH ARMED

FAST FLASH PASSIVE ARMING

ON (SOLID) VALET MODE

2 FLASH... PAUSE ZONE 2 TRIGGER, HOOD/TRUNK

3 FLASH... PAUSE ZONE 3 TRIGGER, DOOR

4 FLASH... PAUSE ZONE 4 TRIGGER, SHOCK

5 FLASH... PAUSE ZONE 5 TRIGGER, IGNITION

Siren/Horn Indications

Chirps Function

1 DISARM

2ARM

3 DOOR AJAR UPON ARMING

4 DISARM / TRIGGERED

5 CAR LOCATOR

Parking Light Flash Indications

Flashes Function

1 DISARM

2ARM

3 DISARM / TRIGGERED

5 CAR LOCATOR

ON (SOLID) REMOTE STARTED

Tabla de contenidos

Otros manuales de Alarma de coche de Code Alarm

Code Alarm

Code Alarm 420A Manual de usuario

Code Alarm

Code Alarm ELITE Series Manual de usuario

Code Alarm

Code Alarm CA 310 Manual de usuario

Code Alarm

Code Alarm F10 Manual de usuario

Code Alarm

Code Alarm CA 6151 Manual de usuario

Code Alarm

Code Alarm ca6355E Manual de usuario

Code Alarm

Code Alarm CATX610 Instrucciones de funcionamiento

Code Alarm

Code Alarm CA 671 Manual de usuario

Code Alarm

Code Alarm CA-130 Manual de usuario

Code Alarm

Code Alarm CA-125 Manual de usuario

Code Alarm

Code Alarm ca 1552 Professional Series Manual de usuario

Code Alarm

Code Alarm CA 110 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 1550 Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES Manual de usuario

Code Alarm

Code Alarm CA 510 Manual de usuario

Code Alarm

Code Alarm CA 180 Manual de usuario

Code Alarm

Code Alarm CA100 Manual de usuario

Code Alarm

Code Alarm CA-160 Manual de usuario

Code Alarm

Code Alarm CA 521 Manual de usuario

Code Alarm

Code Alarm Car Alarm Manual de usuario

Code Alarm

Code Alarm UTXPR Manual del propietario

Code Alarm

Code Alarm Vehicle Security System Manual de usuario

Code Alarm

Code Alarm CA 420A Manual de usuario

Code Alarm

Code Alarm CA 420 Manual de usuario

Manuales populares de Alarma de coche de otras marcas

Clifford

Clifford 3606X Manual de usuario

Ultra Start

Ultra Start 2500M SERIES Manual de usuario

Ultra Start

Ultra Start 650 Series Manual de usuario

Audiovox

Audiovox Prestige Platinum+ APS-511C Manual de usuario

Sparkrite

Sparkrite SRA8 Manual de usuario

Viper

Viper 4708V Manual de usuario

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manual

Falcon

Falcon Predator XL3 Guía del usuario

Audiovox

Audiovox Auto Security XR91 Instrucciones de funcionamiento

Clifford

Clifford Sabre II Manual de usuario

CrimeStopper

CrimeStopper CS-8717 Guía de inicio rápido

Ultra Start

Ultra Start 450 SERIES Manual de usuario

Scytek electronic

Scytek electronic Vectra X3 Manual de usuario

Excalibur

Excalibur AL-1860-EDPB Manual de usuario

Clifford

Clifford CYBER 2 Manual de usuario

Gemini

Gemini 7057 Manual de usuario

FlashLogic

FlashLogic FLRSBA PRESTIGE Manual de usuario

Magicar

Magicar FAI-440 Manual de usuario
