Code Alarm CA 671 Manual de usuario

IMPORTANT NOTE: TheoperationoftheSecurityandConvenienceSystem asdescribedinthis

manualisapplicabletomostvehicles.However, due to theconfigurationof some vehicles, some

functionsAND/ORSAFETYPRECAUTIONS may not apply. Please see your installingdealerformore

information.

Owner's Manual

CA 671

Remote Vehicle Control System

Deluxe Vehicle Security and Remote

Start System with Two Way

Confirming LCD Remote Control

Table of Contents

Using Your Remote Control................................................................................................................ 3

Armingthe security system

Pre-armmode

Disarmingthe security system

Disabling/Enabling confirmation chirps

Attemptedintrusion identification

Twostage door unlock*

Activatingthe trunk releasefeature*

Using Your Remote Control, continued....................................................................................... 4

Turningonthe vehicle’s headlights*

Activatingoptional AUX 1*

Activatingoptional AUX 2*

Activatingoptional AUX 3*

Activatingoptional AUX 4*

Using the progressive car finder feature

Usingthepersonalprotectionalarm(Panic) 2-way remote

Usingthepersonalprotectionalarm(Panic) 1-way remote

Using Your Remote Vehicle Starter ............................................................................................... 5

Remotestarting your vehicle

Enteringyourvehicle while it is running via remote vehicle start

Usingthesafety(red handled) control switch

Preheating or Precooling the vehicle’s interior

Usingthe “quick-stop” feature

Using Your Remote Vehicle Starter, continued ........................................................................... 6

Operatingthe2/4hour start up timer mode

Operatingthe temperature startmode

Using Your Remote Vehicle Starter, continued ........................................................................... 7

Operatingthe daily start timer

Remotestartsafetyfeatures

Usingvalet mode

Usingthe optional Turbo Timer feature*

Additional LCD Remote Control Features ................................................................................... 8

Additional LCD Remote Control Features, Continued .............................................................. 9

LCDremote control options menu

Quick Reference Button Operation Guide.................................................................................. 10

Replacingremotecontrolbatteries

LCD Remote Control Icons and their Indications ................................................................... 11

OptionalSong Bird feature

Emergency Override Procedure ................................................................................................... 12

Warranty Information ................................................................................................................... 13

* Mayrequire additional installation labor, components and installation cost

Using Your Remote Control

Arming the Security System

Toarm the system, exit the vehicle, close all doors, thenpresstheLOCKbutton on the remote control. The

systemwillsound2timesand the parking lights will flash 2 times, indicating the system is armed, has locked the

doors(if equipped and connected) and activated the starter disable feature. The status indicator (blue warning

lighton the antenna) will blink steadily, once per second. To armthesystemsilently, press and hold the LOCK

buttonfor 1 second. The parking lights will flash 2 times,indicating the system is armed, has locked the doors(if

equippedand connected) and activated the starter disable feature. The status indicator (blue warning light on the

antenna)will blinksteadily,onceper second.

Pre-arm Mode

Ifthesystem sounds 1 time and the parking lights flash only1time,this indicates that the vehicle’s interior light is

onor an entrance is left open. Check to see thatalldoorshoodandtrunkareclosedproperly. Once all entrances

aresecured (and the interior light isoff), this system will sound/flash again. The systemis now fully armed. (If

theentranceis not secured within 4 minutes, the system will arm and ignore the unsecured entrance until it is

closed.)

Disarming the Security System

Todisarm thesystem pressthe UNLOCKbutton. Thesystemwillsound and the parkinglights will flash once,

andthe doors will unlock (if equipped and connected). To disarm the system silently, pressandholdthe

UNLOCKbuttonfor 1 second. The parking lights will flash, indicating the system is disarmedandhasunlocked

thedoors (if equipped andconnected).

Disabling/Enabling Confirmation Chirps

1. Turnthe ignitionkey ON then OFF.

2. Within10 seconds pushandrelease the valet/override button3times.

3. Thesystemwillsound2timestodisable confirmation chirps or 1 time to enable confirmation chirps.

Attempted Intrusion Identification

Thissystem will inform you ifanintrusion attempt has occurred while youwereaway from the vehicle. If an

intrusionattemptoccurred,the system will sound 4 times and the parking lights will flash 3 timeswhen disarming

thesystem. Enter the vehicleanobserve the dash mountedstatusLED to Identify whichzonewas triggered.

1. ShockSensor-1 flash, pause 1 flash, etc.

2. HoodorTrunk Pin switch - 2 flashes, pause 2 flashes, etc.

3. DoorEntry - 3 flashes, pause 3 flashes, etc.

Theintrusion warning indicators are stored in the system’s memory and will be erased when the ignition key is

turnedon.

Two Stage Door Unlock (Optional)

Ifthis feature is enabled on your system, pressing theUNLOCKbuttonone time on the remote control will unlock

onlythe driver’s door. Press UNLOCK again to unlock theremainingdoors.

Activating the Trunk Release Feature (Optional)

Ifthisfeatureisenabledonyoursystem,pressingandholdingtheTRUNKbutton on the remote control for 2

secondswill open the vehicle’s trunk or hatch.

*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for

morethan2seconds.

Using Your Remote Control, continued

Turning on the Vehicle’s Headlights (Optional)

Ifthis feature is enabled on your system, pressing and holding the LOCK button on the remotecontrolfor3seconds

willturnonthevehicle’sheadlights for 30 seconds.

Activating Optional AUX 1 (Optional)

Ifthis feature is enabled onyoursystem, pressing and holding theLOCKbuttonand the Trunk button ontheremote

controlsimultaneously for 2 seconds will activate anoptionalfeature.This feature can be programmed for awide

rangeof functions like power windoworsunroofautomation, please consult your installing dealertodetermine

functionalityofyour system.

Activating Optional AUX 2 (Optional)

Ifthis feature is enabled on your system, pressing and holding the OPT button on the remote control for 2 seconds

willactivate an optional feature. This feature can be programmedforawide range of functions like power window or

sunroofautomation, please consultyourinstalling dealer to determinefunctionalityof your system.

Activating Optional AUX 3 (Optional)

Ifthis feature is enabled onyoursystem, pressing and holding theLOCKbutton and the OPT button ontheremote

controlsimultaneously for 2 seconds will activate anoptionalfeature.This feature can be programmed for awide

rangeof functions like power windoworsunroofautomation, please consult your installing dealertodetermine

functionalityofyour system.

Activating Optional AUX 4 (Optional)

Ifthis feature is enabled on your system, pressing andholdingtheUNLOCK button and the OPT button on the

remotecontrol simultaneously for 2 seconds will activate an optional feature.Thisfeaturecanbe programmed for a

widerange of functions like power windoworsunroofautomation, please consult your installing dealertodetermine

functionalityofyour system.

Using the Progressive Car Finder Feature

Pressthe LOCK button and theUNLOCKbuttonon the remote control tolocateyour vehicle. The system will sound

5times at low volume increasing in volume each of 3timesthebuttonis pressed.

Using the Personal Protection Alarm (Panic) 2-Way Remote

Pressand hold the LOCKbuttonandthe UNLOCK button on theremotecontrol for 2 seconds toactivatethe

personalprotection alarm. The system will sound for 30 seconds. Pressing any button on the remote control will

turnthe personal protection alarm off.

Using the Personal Protection Alarm (Panic) 1-Way Remote

Pressand hold the PANICbutton on the remote control for2secondstoactivate the personal protection alarm. The

systemwill sound for 30 seconds. Pressing any button on the remote control will turn the personal protection alarm

off.

Using Your Remote Vehicle Starter

Remote Starting Your Vehicle

Toactivate the remote vehiclestartfunction,press and release the OPTbutton on the remote control 2times

within2seconds. Thesystem will sound, the parking lights will flash 1 time and the system will check the vehicle

toensure it is safe to start,if all safety parameters are correct,the vehicle will start within 5seconds (diesel

vehicles will take longer). The vehicle’s parking lights will turn on (or flash depending on system settings) as a

visualindication that the vehicle has started and is running. Press and release the OPT buttonontheremote

control2 times within 2 seconds again to turn the vehicle off.

Ifyour vehicle stalls or does not start, the system will pause 5 seconds, then try 3 more times tostartthevehicle(a

totalof 4 attempts). The systemwillpause 5 seconds between eachstartattempt. If the vehicle doesnotstart

afterthe 4th attempt, thesystemwill abort the remotevehiclestart process.

Entering the Vehicle while it is running via Remote Vehicle Start

1. Unlockthevehicle’sdoors.

2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!

3. Insertthe key into the ignition switch and turn totheON or RUN position.

4. Press the brake pedal. The remote vehicle starterwill disengageandthevehiclewilloperatenormally.

Using the Safety (Red Handled) Control Switch

Thesafety (red handled) control switch allows you to temporarily disable the remote vehicle starter feature,thisis

especiallyhelpfulwhen having yourvehicleserviced or valetparked. Todisabletheremote start,move thesafety

(redhandled)control switch to the OFF position.

Preheating or Precooling the Vehicle’s interior

Beforeexiting the vehicle, set the temperaturecontrolstothe desired setting and operation. After the system

startsthevehicle, the heater or air conditioning will activate and heat or cool the vehicle’sinterior toyoursetting.

Using the “Quick-stop” Feature

Ifyou want to make ashortstopand keep your vehicle running(tokeepthe interior warm or cool),thequick-stop

featureallows youto dothiswhile keepingyourvehicle secureand your keyswith you.

To engage quick stop:

1. Stopthe vehicle and place the transmission in PARK.

2. Withyour foot off thebrakepedal, press and release theOPTbutton on

the remote control 2 times within 2 seconds. The parking lights will turn

onindicating the vehicle is now running via remotevehiclestart.

3. Removethe keys from the ignitionandexit the vehicle. Press the LOCK

buttonon the remote control to lock the vehicle’s doors if desired.

Note: Donotleavechildrenoranimals unattended in the vehicle when using the

quick-stop feature.

Using Your Remote Vehicle Starter, continued

Operating the 2 / 4 Hour Start Up Timer Mode

Thesystem has the ability to start the vehicle every 2 or 4 hours over a 48 hour period. This feature is especially

usefulin cold climates where the only means to keep the engine and enginefluidswarmistoperiodically start

theengine.

WARNING!

Becertain that the vehicle is outdoors before using this oranyremote starting device. A running engine

producesdangerous carbon monoxide fumes which canbeharmfulor fatal if prolonged exposure occurs. DO

NOT remote start the vehicle if it is garaged.

Selecting between 2 and 4 hour start up: (default 4 hour)

1. Beginwith the safety (red handled) control switch in theONposition.

2. Turn the ignition switch ON then OFF.

3. Within10seconds move the safety (red handled) control switch OFF, ON, OFF, ON (2switch

cycles) to select a 2 hour start timer. After 10 seconds the parking lights will flash and the system

will sound 2 times indicating that the 2 hour start timer is selected.

3a. Within10seconds move the safety (red handled) control switch OFF,ON, OFF,ON, OFF,ON,

OFF, ON (4 switch cycles) to select a 4 hour start timer. After 10 seconds the parking lights will

flash and the system will sound 4 times indicating that the 4 hour start timer is selected.

To begin the 2 / 4 hour start up timer mode:

1. Turn the ignition key ON then OFF.

2. Within10 seconds press the OPT button on the remote control four (4) times.

Theparking lights will flash and the systemwill sound 4 times indicating the 2/ 4 hour start up timer

modehas been activated. The vehicle will start every 2 or 4 hours and run for the preset time limit(5,

10,15or20 minutes) and then shutdown. This will continue for 48 hours unless the 2 / 4 hour start up

timeris cancelled.

To begin the 2 / 4 hour start up timer mode from the remote control:

1. Activatethe remote vehicle start feature usingtheremotecontrol.

2. Shutdownthe remote vehicle starter using the remotecontrol.

3. Within10 seconds press OPT button ontheremote control 4 times.

Theparking lights will flash and the systemwill sound 4 times indicating the 2/ 4 hour start up timer

modehas been activated. The vehicle will start every 2 or 4 hours and run for the preset time limit(5,

10,15or20 minutes) and then shutdown. This will continue for 48 hours unless the 2 / 4 hour start up

timeris cancelled.

To cancel the 2 / 4 hour start up timer mode:

1. Startthevehicleusingthe ignition key, then press thebrakepedal.

2. Activatethe remote vehicle start feature usingtheremotecontrol.

Operating the Temperature Start Mode

Thesystem has the ability to start the vehicle when the temperature reaches 0degrees. Totoggle this feature

ON/OFFusingtheremote control press the UNLOCK and OPT buttons simultaneously for 1 second.

Note: Thisfeature must be turned ON in options programming. Checkwith your installing dealer to insure this

featureis set to the ON position.

Using Your Remote Vehicle Starter, continued

Operating the Daily Start Timer

Thesystem has the ability to start your vehicle based on a 24-hour countdown timer. This feature requiresatwo-

partactivation sequence. From the remote, pressing both the LOCK & OPT buttons together willactivatethe24

hourcountdown timer (thismaybe done atanytime). Next, When you arefinished operating the vehicleforthe

day, perform the followingstepstocomplete the process.

1. Turn the ignitionON/OFF (vehicle must be disarmed).

2. Within 10 seconds, while pressing the brake, press and release the TRUNK button twice.

3. The vehicle will flash the parking lights 2 times.

Remote Start Safety Features

Forsafety and security reasons, the systemwillshutdownor prevent the remote vehicle starter fromactivatingif

anyof the following occur:

1. Thevehicle’shoodisopen.

2. Thebrake pedal is pressed prior to turning theignition key to the ON position.

3. Theengine reaches 3 times its normal idle speed.

4. Thesafety(redhandled)controlswitchis moved to the OFF position.

Using Valet Mode

To engage valet mode:

1. Turntheignition key to the ON position.

2. Pressand hold the emergency overridebutton.

3. Theblue LED will light solid indicatingthat the system is in valet mode.

Whenvalet mode is activated the dash mounted status LED will light solid, and all security functionswillbe

disabled.

To disengage valet mode:

1. Turntheignition key to the ON position.

2. Pressand release the emergency overridebutton.

3. Theblue LED will turn off indicating that the system has exited valet mode.

Whenthe valet modehasbeen deactivated the statusLEDwill turn offandall security functions willbeenabled

thenext timethe systemisarmed.

Using the optional Turbo Timer Feature

To engage the turbo timer feature:

1. With thevehiclerunning via the ignitionkey, and your footoffof thebrakepedal.

2. Engagethevehicle’sparking brake.

3. Thevehicle’sparkinglightswillturnontoverifytheturbotimerfeaturehasbeenactivated.

4. Turnthe ignitionkey OFF, the vehicle will continue to run for an additional 5 minutes.

To disengage the turbo timer feature:

1. Pressthe vehicle’s brake pedal.

2. Turnthesafety(redhandled) control switch to the OFF position.

Additional LCD Remote Control Functions

LCD Remote Control Display Illumination

Pressandreleasethe“F”buttonontheLCDremotecontrol one time. The display will illuminate for 10 seconds.

LCD Remote Control Vibrate or Tones

Pressand release the “F” button and the UNLOCK button on the LCD remotecontrolsimultaneouslyonetimeto

togglebetween beep tones and vibrate mode. TheLCDremotecontrol will either beep or vibratetoindicatewhich

modeis selected.

Page Call Out

Fromwithin the vehicle, press and hold the emergency override button for4seconds,theLCD remote control will

emita beep tone to indicate thatsomeoneiscalling you to the vehicle.

Out of Range

If the LCD remote control is within operating range of the vehicle the antenna or IN-RANGE INDICATOR icon will

bedisplayed after any button is pressed. If this icon disappears after a button is pressed the vehicle is out of range

ofthe remote control.

Countdown Timer

TheLCD remote control is equippedwitha countdown timer for situations whereanalert tone may be neededto

remindyou of something important. Thecountdowntimer allows you tosetthe timer up to19hours and 59 minutes.

Refer to page 9 for programming.

Parking Meter Timer

TheLCD remote control is equipped with a parking meter timer that allows you to set a countdown timer for 10, 20,

30,60,90or120minutes. TheLCDremotecontrolwillemitabeeptonewhenthetimerexpires. Press”F”and

OPTsimultaneouslytoselect desired time.

Alarm Clock

TheLCDremotecontrolisequippedwithabuilt in alarm clock that can be set to beep at a certaintime each day.

Thealarmclock must be set, and the feature turned on. Refer topage10for programming time. Press ”F” and

TRUNKsimultaneouslytoturnON and OFF if the desired time has already been set.

Bypassing The Shock Sensor

Thereare3 additional modes of operation in which your system will react to the shock sensor, FULL TRIGGER

ONLY, ALL OFF, or CITY MODE.

PressLOCK once to arm the system.

PressingLOCK again within 2 seconds will setthe system to FULLTRIGGER ONLYin whichthe system will

ignore the light touch setting.

PressingLOCK again within 2 seconds will set the system toALLOFF. In this mode the system will not react to

theshock sensor and the2-wayLCDremote will display theshocksensoricon.

PressingLOCK again within 2 seconds will set the system toCITYMODE. In this mode the light touch horn output

isextendedtoafull10secondsandfulltriggerhornoutputisshortened to 15 seconds, no icon is displayed.

NOTE:The system will only change the shock sensorsettingforone arm cycle and will be defaulted back tonormal

operationthenexttime thesystem isarmed.

Additional LCD Remote Control Functions, cont.

Check Vehicle Status

PresstheLOCK,TRUNKandOPT buttons simultaneously for 1 second. The LCD remote control will display the

system’scurrent status.

Check Temperature

Press the TRUNKand OPT buttons simultaneously for1 second. The LCDremote control will displaythe vehicle’s

interiortemperature.

Battery Save Mode

Pressthe LOCK and “F” buttonssimultaneouslywhenthe system is disarmed. Note thatinthis mode the remote

willnot send or receivevehiclestatusunless you press a buttononthe remote.

Temperature Display

Pressand release the TRUNKandOPT buttonssimultaneouslyto change the temperaturedisplaybetween

Fahrenheit or Celsius.

LCD Remote Control Options Menu

Accessing the Options Menu

1.Press and hold the “F” button for 5 seconds.

2. Press the “F” button to select the setting to change.

3. Use the TRUNK or OPT button to change the digits.

4.Press “F” to keepsettingandadvance to the next item.

5.Pressandhold“F”for5secondstoexitoptionsmenu.

Selectable Features in the Options Menu

1 Time Set - Hours

Time Set - Minutes

2 Alarm Clock - Hours

AlarmClock - Minutes

3 AlarmClock Melody

4 Alarm Clock - ON / OFF

5 CountdownTimer- Hours

CountdownTimer - Minutes

6 CountdownTimer/Remote StartShutdown Melody

7 Countdown Timer - ON / OFF

8 RemoteStart Melody

Quick Reference Button Operation Guide.

Replacing Remote Control Batteries

2-way LCD Remote Control:

The AAA alkaline batteryinsidethe 2-way LCD remotecontrolshould last approximately 1 yearundernormal

use. Whenthe battery becomesweakyou will noticetheremote control range(thedistance from thevehiclethe

remotecontrolwillwork)deteriorate and the BATTERYicon on the LCD remote control will display.To replace

theremotecontrolbattery:

1. Liftand slide the battery cover off of the remote control.

2. Removethe oldAAAbattery, observing the+/-symbols on thebattery,and replace with anewAAA

battery.

3. Gentlyslide the battery cover onto the back of the remotecontroluntilitlocks into place.

4. Testoperation of the remote control.

1-Way 6 Button Remote Control:

Thetwo3 volt lithium batteries (model CR2032 or Code Alarm part#6BA) inside each remote control

shouldlast approximately1year undernormaluse. When thebatteriesbecome weakyouwill noticetheremote

controlrange(the distance from the vehicle the remote control will work) deteriorate and the small LED on the

remotecontrolwill dim. To replace the remote control batteries:

1. Usingasmall(#1) philips screwdriver, remove the screw on the back of the remote control.

2. Gentlyunsnap the halvesofthe remote control apart.

3. Slidethelithium batteries out of the circuit board, observing the +/- symbolsonthebatteries

andreplace with new lithium 3 volt batteries(model CR2032 or Code Alarm part #6BA)

4. Gentlysnap the halves of the remote control back together andreinstallthephilipsscrew on the

back of the remote control.

5. Testoperation of the remote control.

Operation Function Lock Unlock Trunk

OPT F Operation Method

Lock X Press and Release

Unlock X Press and Release

Headlight X Press and Hold for 3 seconds

Trunk X Press and Hold for 2 seconds

Car Finder X X Press and Release

Panic X X Press and Hold for 2 seconds

Remote Start X Press two times in 2 seconds

Temp Start X X Press and Release

Daily Start X X Press and Release

AUX1 X X Press and Release

AUX2 X Press and Hold for 2 seconds

AUX3 X X Press and Hold for 2 seconds

AUX4 X X Press and Hold for 2 seconds

Check Status X X X Press both together for 1 second

Check Temp X X Press both together for 1 second

Battery Saver X X Press and Release, When System is Disarmed

Vibrate X X Press and Release

2/4 hour start X Press 4 times after remote start shut down

Shock Bypass X Press and release 2, 3, or 4 times

Parking Meter Timer X X Press and release 1, 2, 3, 4, 5 or 6 times

Alarm clock X X Press and Release

Fahrenheit / Celsius X X X Press and Release

Tabla de contenidos

Otros manuales de Alarma de coche de Code Alarm

Code Alarm

Code Alarm Elite ca1155E Manual de usuario

Code Alarm

Code Alarm CA 510 Manual de usuario

Code Alarm

Code Alarm ca 2051 Manual de usuario

Code Alarm

Code Alarm Professional caSECRS Manual de usuario

Code Alarm

Code Alarm CSI-200 Manual de usuario

Code Alarm

Code Alarm CA 170 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 1050 Manual de usuario

Code Alarm

Code Alarm CSI-300 Manual de usuario

Code Alarm

Code Alarm CA-125 Manual de usuario

Code Alarm

Code Alarm ca1153 Manual de usuario

Code Alarm

Code Alarm Professional ca6153 Manual de usuario

Code Alarm

Code Alarm SRT 5500 Manual de usuario

Code Alarm

Code Alarm CA611 Manual de usuario

Code Alarm

Code Alarm 2000 Manual de usuario

Code Alarm

Code Alarm CATX2LCD Instrucciones de funcionamiento

Code Alarm

Code Alarm SRT 1600 Manual de usuario

Code Alarm

Code Alarm CA-150 Manual de usuario

Code Alarm

Code Alarm CA 680 Manual de usuario

Code Alarm

Code Alarm ca 1552 Professional Series Manual de usuario

Code Alarm

Code Alarm ca 1051 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 1550 Manual de usuario

Code Alarm

Code Alarm ca 1552 Professional Series Manual de usuario

Code Alarm

Code Alarm TW-1 Manual de usuario

Code Alarm

Code Alarm CA 650 Manual de usuario

Manuales populares de Alarma de coche de otras marcas

Clifford

Clifford 3606X Manual de usuario

Ultra Start

Ultra Start 2500M SERIES Manual de usuario

Ultra Start

Ultra Start 650 Series Manual de usuario

Audiovox

Audiovox Prestige Platinum+ APS-511C Manual de usuario

Sparkrite

Sparkrite SRA8 Manual de usuario

Viper

Viper 4708V Manual de usuario

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manual

Falcon

Falcon Predator XL3 Guía del usuario

Audiovox

Audiovox Auto Security XR91 Instrucciones de funcionamiento

Clifford

Clifford Sabre II Manual de usuario

CrimeStopper

CrimeStopper CS-8717 Guía de inicio rápido

Ultra Start

Ultra Start 450 SERIES Manual de usuario

Scytek electronic

Scytek electronic Vectra X3 Manual de usuario

Excalibur

Excalibur AL-1860-EDPB Manual de usuario

Clifford

Clifford CYBER 2 Manual de usuario

Gemini

Gemini 7057 Manual de usuario

FlashLogic

FlashLogic FLRSBA PRESTIGE Manual de usuario

Magicar

Magicar FAI-440 Manual de usuario
