Clarke CWR45 Manual de programación

ASSEMBLY & INSTALLATION

INSTRUCTIONS

GC04/09

WALL RACK

MODEL: CWR45

Part No: 7640000

2

INTRODUCTION

Thank you for purchasing this CLARKE wall rack. Please follow these assembly

instructions carefully.

GUARANTEE

This CLARKE product is guaranteed against faulty manufacture for a period of

12 months from the date of purchase. Please keep your receipt as proof of

purchase. This guarantee is invalid if the product is found to have been

abused or tampered with in any way, or not used for the purpose for which it

was intended. Faulty goods should be returned to their place of purchase, no

product can be returned to us without prior permission. This guarantee does

not effect your statutory rights.

ENVIRONMENTAL PROTECTION

Do not dispose of this product with general household waste. All tools,

accessories and packaging should be sorted, taken to a re-cycling

centre and disposed of appropriately.

SPECIFICATION

• Dimensions (mm) 1130 long x 630 high x 14 deep

• Weight 6.5kg

PARTS & SERVICE

For parts & service, please contact your nearest dealer, or CLARKE Interna-

tional, on one of the following numbers.

PARTS & SERVICE TEL: 020 8988 7400 / FAX: 020 8558 3622

or e-mail as follows:

PARTS: [email protected]

SERVICE: [email protected]

3

PARTS LIST

Unpack your wall rack and check to ensure that no damage was suffered

during transit. Should any damage be apparent, you should contact your

Clarke dealer immediately.

The kit comprises: 5 x panels

9 x assorted tool holders

12 x peg hooks

8 x sets of bolts & nuts

6 screws with rawlplugs

Tools required: power drill with masonry drill bits

x-head screwdriver

5.5mm spanner/ small screwdriver

ASSEMBLY

1. Fix the five panels together, side by side, using the nuts and bolts supplied.

Use two bolts per panel joint. Fully tighten all the nuts.

2. Mark the intended position of the product on the wall. Accurately meas-

ure the distance between the centres of the holes of the integral support-

ing brackets on the back of each panel.

• End and centre panels only should be used for fixing.

3. Mark these hole centres on the wall and drill holes for the rawlplugs

supplied. Secure the screws into each fixing position.

4. The wall rack can now be hung on these screws, ensuring the head of

each screw locates into the supporting bracket on the back of each

panel.

5. After securing the wall rack to the wall, attach the tool holders and peg

hooks into the desired positions to suit your tools.

x x x x

x x x x

Wall fixings

here

Connecting

bolts here
