Clarke DEVIL 9000PTC Manual de instrucciones
Only suitable for well insulated areas and not designed
to be the primary heat source
OPERATION & MAINTENANCE
INSTRUCTIONS
DL1123 -Rev 2
ORIGINAL INSTRUCTIONS
400V ELECTRIC FAN HEATER
MODEL NO: DEVIL 9000PTC
PART NO: 6925238
2
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
INTRODUCTION
Thank you for purchasing this CLARKE product.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
FUNCTION AND OPERATING PARAMETERS
This is a forced air heater. It’s intended use is for drying and the warming of
commercial/industrial buildings and areas where adequate ventilation is
provided.
• It must be operated as prescribed in the operating manual.
• It is not intended to be used for domestic use or for the heating of
habitable areas.
• It is not intended to be used to reach and maintain a certain level of
human thermal comfort within an enclosed space in which the heater is
situated.
• It is not intended to be used in enclosed areas with restricted ventilation.
• It is not intended for warming animals or live stock.
3
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
THE FOLLOWING TABLE ADDRESSES THE
INFORMATION REQUIREMENTS OF REG.2015/1188
Item Symbol Value Unit
Heat output
Measured seasonal space heating energy efficiency 36%
Nominal heat output Pnom 9kW
Minimum heat output (indicative) P min 6kW
Maximum continuous heat output P max 9kW
Auxiliary electricity consumption
At nominal heat output elmax n/a kW
At minimum heat output el min n/a kW
In standby mode elSB n/a kW
Type of heat input for electric storage local heaters only
Manual heat charge control with integrated thermostat n/a
Manual heat charge control with room and/or outdoor temperature
feedback
n/a
Electronic heat charge control with room and/or outdoor temperature
feedback
n/a
Fan assisted output n/a
Type of heat output/room temperature control (select one)
Single stage heat output, no temperature control No
Two or more manual stages, no temperature control No
With mechanical thermostat temp control Yes
With electronic temperature control No
Electronic temperature control with day timer No
Electronic temperature control with week timer No
Other control options (multiple selections possible)
Room temperature control with presence detection No
Room temperature control with open window detection No
Room temperature control with distance control option No
Room temperature control with adaptive start control No
Room temperature control with working time limitation No
Room temperature control with black bulb sensor No
4
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
SAFETY SYMBOLS
The following symbols appear on the unit.
SAFETY RULES
Make sure that you read, understand and comply with the following.
ELECTRICAL SAFETY
1. Electrical appliances must match the power outlet. NEVER modify the plug
in any way. DO NOT use adaptor plugs with earthed (grounded)
appliances. Correct plugs and outlets will reduce the risk of electric shock.
2. DO NOT abuse the electrical cable. NEVER use the cable for pulling or
unplugging the heater. Keep the cable away from sources of heat, oil,
sharp edges or moving parts. Damaged or tangled cables increase the risk
of electric shock.
3. Keep the power cable well away from machines and ensure an adequate
electrical supply is close at hand so that the operation is not restricted by
the length of the cable.
4. ALWAYS disconnect from the power supply before moving the heater or
performing any cleaning or maintenance tasks.
5. Inspect the mains cable regularly for signs of damage. DO NOT use if it is
damaged, and ALWAYS keep it away from the source of heat.
6. Check the heater for damage before use. DO NOT use if the heater tubes/
elements are damaged or broken. Any damage should be properly
repaired or the part replaced. If in doubt, DO NOT use. Consult your local
CLARKE dealer.
Hot
Surface,
Do Not
Touch
Do Not
Cover
High
Voltage
WARNING: THIS HEATER MUST BE EARTHED
5
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
MAINTENANCE.
1. Check that the heater is in good working order. Take immediate action to
repair or replace damaged parts.
2. DO NOT allow the heating elements to become covered with dust which
could become a fire hazard. If used in a dusty workplace it should be
cleaned as described under Cleaning and Maintenance.
3. Only recommended parts should be used. Unapproved parts may be
dangerous and will invalidate the warranty.
4. DO NOT attempt to repair a damaged heater, contact the Clarke service
department.
POSITIONING
1. This heater is designed for indoor use only.
2. DO NOT use this heater in small rooms when they are occupied by persons
not capable of leaving the room on their own unless constant supervision is
provided.
3. DO NOT use this heater in the immediate surrounds of a bath, a shower, a
swimming pool or wet surfaces.
4. NEVER place the heater against or near any surface such as a wall, door,
curtains, furniture or combustible material etc. Allow at least 2 metre
clearance.
5. DO NOT place the heater immediately below any electrical outlet.
6. DO NOT place the heater on a raised surface or anywhere where it could
topple over. ALWAYS use on a horizontal and stable surface.
7. ALWAYS ensure that the grille cannot be blocked.
8. DO NOT operate fan heaters in explosive atmospheres such as in the
presence of flammable liquids, gasses or dust such as in a paint spray
booth or any explosive environment. Electric motors create sparks which
may ignite dust or fumes.
WARNING: SERVICING OR INTERNAL MAINTENANCE MUST ONLY BE
CARRIED OUT BY THE CLARKE SERVICE DEPARTMENT.
WARNING: DO NOT USE THE HEATER NEAR FLAMMABLE MATERIAL,
LIQUIDS, SOLIDS, GASSES OR COMPRESSED GAS CYLINDERS ETC.
6
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
OPERATION
1. This heater is intended for drying & warming of commercial/industrial
buildings where adequate ventilation is provided. It is NOT for domestic use
or for heating habitable areas.
2. The heater should NOT be used by children or persons with reduced
physical, sensory or mental capabilities, or lack of experience and
knowledge.
3. CAUTION: Some parts of this product can become very hot and cause
burns. Particular attention should be given where, animals, children and
vulnerable people are present.
4. The heater must only be used by people who have read these instructions
and have been trained in its use.
5. DO NOT use if dropped.
6. DO NOT use if there is visible signs of damage.
7. DO NOT obstruct the air inlet and outlet sections of the heater.
8. DO NOT cover the heater with anything that could restrict the air flow.
9. DO NOT touch the heater casing or grille when first switched off, as these
will be very hot and will take time to cool.
10. DO NOT get the heater wet or use in areas of high condensation.
11. DO NOT allow the power lead to touch hot surfaces.
12. DO NOT connect other appliances to the same mains socket as the heater.
13. DO NOT use this heater with a programmable timer used to switch it on
automatically.
14. DO NOT leave the heater unattended.
SERVICE & REPAIRS
1. If necessary, have your heater repaired by a qualified person using
identical replacement parts. This will ensure that the safety of the product is
maintained.
2. Please keep these instructions in a safe place for future reference.
7
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
ELECTRICAL CONNECTIONS
This heater MUST be connected to a 400 Volt, 3 phase 50Hz supply through a
suitably rated isolator switch. It cannot be operated from a single phase
supply.
In addition to the cable fitted to the
heater, a DCL16B extension lead can
be used. This is fitted with a red 5 pin
16 amp industrial plug to EN 60309
with 16A socket. (CLARKE part No
6925233).
If in any doubt, consult a qualified electrician. DO NOT attempt any electrical
repairs yourself.
WARNING: THE INSTALLATION OF THIS APPLIANCE SHOULD BE CARRIED
OUT BY A COMPETENT ELECTRICIAN AND BE IN ACCORDANCE WITH THE
CURRENT IEE WIRING REGULATIONS (BS7671-2:2008).
8
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
OPERATION
1. Put the heater in a level position
on a flat surface and at a safe
distance from flammable
materials. Keep a minimum of 2m
clearance all round.
2. Connect the heater to a suitable
power supply.
3. Set the thermostat control to the
maximum setting (fully clockwise).
4. Set the mode selector to one of
the 3 settings:
• The heater will take up to three minutes to reach optimum temperature.
5. Once the room reaches the required temperature, turn the thermostat
control slowly counter-clockwise until the thermostat clicks, leave the
control in this position.
• The room temperature will be maintained at this setting. The heater will
continue to operate until the power switch is turned to the OFF position.
WARNING: DO NOT USE THIS HEATER IN SMALL ROOMS WHEN THEY ARE
OCCUPIED BY PERSONS NOT CAPABLE OF LEAVING THE ROOM ON THEIR
OWN, UNLESS CONSTANT SUPERVISION IS PROVIDED.
CAUTION: SOME PARTS OF THIS PRODUCT CAN BECOME VERY HOT AND
CAN CAUSE BURNS. PARTICULAR ATTENTION HAS TO BE GIVEN WHERE
CHILDREN AND VULNERABLE PEOPLE ARE PRESENT.
Off
Fan Only
Heat Setting 1
Heat Setting 2
9
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
6. For fan only operation, turn the
power switch to the fan only
setting and set the thermostat to
its minimum setting.
7. Adjust the angle by loosening
both adjusting knobs and setting
the required angle.
8. Retighten the adjusting knobs.
9. When not in use, disconnect the
heater from the mains supply.
Store it in a safe, dry, childproof
location.
10
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
TROUBLESHOOTING
Problem Possible Cause Remedy
Heater does not
operate,
although
plugged in with
the switch and
thermostat
switched on.
Plug is loose/bad
connection.
Pull the plug out & check all
connections (cable/plug and socket).
Fuse blown or
circuit breaker
trips.
Replace if necessary and investigate
cause. If fuse blows repeatedly, consult
your CLARKE dealer.
No power at
socket outlet
Insert the plug in a suitable socket.
Heating element
glowing hot.
Input voltage too
high.
Use a power supply in accordance
with the rating on the label.
Air inlet grille is
blocked.
Ensure the heater is kept away from
any objects which could cover the air
inlet or be drawn into it.
The unit has failed
to heat up so only
the air fan has
operated.
Control switch not
set at a "HEATING"
level.
Turn switch to a heating level.
Thermostat has
tripped.
Turn the thermostat and listen. If there is
no CLICK and the thermostat is not
damaged, the heater will
automatically switch ON when it has
cooled down.
Abnormal noise. Heater is not level. Stand heater on a level surface.
Otros manuales para DEVIL 9000PTC
1
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Calentador de Clarke
Clarke
Clarke DEVIL 371PC Manual de instalación y operación
Clarke
Clarke OFR 9 Manual de instrucciones
Clarke
Clarke DEVIL 4035 Manual de instalación y operación
Clarke
Clarke XR55 Manual de instalación y operación
Clarke
Clarke BR13/250 Manual de instrucciones
Clarke
Clarke DEVIL 2000PTC Manual de instrucciones
Clarke
Clarke DEVIL 371SPC Manual de instalación y operación
Clarke
Clarke XR75 Manual de instalación y operación
Clarke
Clarke IQ2000 Manual de usuario
Clarke
Clarke DEVIL 5000PTC Manual de instrucciones
Clarke
Clarke DEVIL 9000PTC Manual de instrucciones
Clarke
Clarke XR80 Manual de instrucciones
Clarke
Clarke DEVIL 371SPD Manual de instalación y operación
Clarke
Clarke CONTRACTOR DEVIL371PD Manual de instalación y operación
Clarke
Clarke CONTRACTOR GSH15 Manual de instrucciones
Clarke
Clarke DEVIL 7005 Manual de instrucciones
Clarke
Clarke DEVIL 350C Manual de instalación y operación
Clarke
Clarke DEVIL 350B 230V Manual de instalación y operación
Clarke
Clarke DEVIL 7030 Manual de instrucciones
Clarke
Clarke OFR 9 Manual de instrucciones
