OPERATION & MAINTENANCE

INSTRUCTIONS

ORIGINAL INSTRUCTIONS GC03/23ORIGINAL INSTRUCTIONS GC03/23

2KW ELECTRIC FAN HEATER

MODEL NO: DEVIL 2000PTC-B

PART NO: 6925591

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for purchasing this CLARKE product. Please read this manual

carefully, in doing so you guarantee the safety of yourself and that of others

around you, and you can look forward to your purchase giving you long and

satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt as proof of

purchase.

This guarantee is invalid if the product is found to have been abused,

tampered with, or not used for the purpose for which it was intended. Faulty

goods must be returned to their place of purchase, no product can be

returned to us without prior permission.

This guarantee does not effect your statutory rights.

PRODUCT SPECIFICATIONS

Product: Depth x Width x Height 210 x 160 x 217 mm

Product weight 1.6 kg

Operating Voltage and Frequency: (V / Hz) 230 V / 50Hz

Required power; Fan only

Fan& heat setting 1

Fan& heat setting 2

0.11 A

4.94 A

8.89 A

Operating Temperature: (Min/Max) (°C): -15 to 25°C

Heat Output: (kW): Fan only

Fan& heat setting 1

Fan& heat setting 2

0.025 W

1 kW

2 kW

Max Air Output: (m3/h) 197m3/h

Safety Device: Thermal cut-out

Duty Cycle Classification: S1 Continuous duty

Electrical Insulation Class I

Ingress Protection rating IP20

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

THE FOLLOWING TABLE ADDRESSES THE

INFORMATION REQUIREMENTS OF REG.2015/1188

Item Symbol Value Unit

Heat output

Measured seasonal space heating energy efficiency 36%

Nominal heat output Pnom 2.0 kW

Minimum heat output (indicative) P min 1.0 kW

Maximum continuous heat output P max 2.0 kW

Auxiliary electricity consumption

At nominal heat output elmax n/a kW

At minimum heat output el min n/a kW

In standby mode elSB n/a kW

Type of heat input for electric storage local heaters only

Manual heat charge control with integrated thermostat No

Manual heat charge control with room and/or outdoor temperature

feedback

Electronic heat charge control with room and/or outdoor temperature

feedback

Fan assisted output No

Type of heat output/room temperature control (select one)

Single stage heat output, no temperature control No

Two or more manual stages, no temperature control No

With mechanical thermostat temp control Yes

With electronic temperature control No

Electronic temperature control with day timer No

Electronic temperature control with week timer No

Other control options (multiple selections possible)

Room temperature control with presence detection No

Room temperature control with open window detection No

Room temperature control with distance control option No

Room temperature control with adaptive start control No

Room temperature control with working time limitation No

Room temperature control with black bulb sensor No

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

SAFETY

Make sure that you read, understand and comply with the following

guidance. These safety symbols should appear on the heater.

GENERAL

•DO NOT operate the heater when you are tired or under the influence of

alcohol, drugs or intoxicating medication.

•DO NOT stand on the heater.

•DO NOT use the heater with wet hands or when there is water on the

power cable.

• Turn the heater off when not in use and keep it in a safe, dry, childproof

location.

• The heater is designed to heat enclosed areas such as workshops and

other industrial areas. DO NOT use the heater for any other function. It is

not suitable for drying clothes or laundry.

ELECTRICAL SAFETY

• Regularly inspect the power cable / plugs for damage/looseness. DO

NOT use the heater it the power cable is damaged.

• Minimise the risk of electric shock by installing a RCCB (Residual Current

Circuit Breaker) and a suitable isolator into the main distribution board.

• Make sure that the voltage on the rating label is the same as the voltage

of the power supply. If in doubt, consult a qualified electrician.

•DO NOT abuse the electrical cable. DO NOT use the cable for pulling or

unplugging the heater.

• Keep the cable away from sources of heat, oil, sharp edges or moving

parts. Damaged or tangled cables increase the risk of electric shock.

•DO NOT use extension cables with this heater.

Hot Surface,

Do Not Touch

Read the

manual

Do Not Cover

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

POSITIONING

• This heater is designed for indoor use only.

•DO NOT place the heater close to a bath, wash basin, shower, swimming

pool or any other water-filled area or wet surface. DO NOT place the

heater against any surface such as a wall, door or furniture etc.

•DO NOT place the heater immediately below any electrical outlet.

•NEVER place the heater near combustible materials etc. Allow 2 metres

clearance all round this heater.

•DO NOT place the heater on a raised surface or anywhere it could

topple over.

• Take care to ensure that the grille cannot be blocked.

•DO NOT operate fan heater in explosive atmospheres such as in the

presence of flammable liquids, gasses or dust such as in a paint spray

booth, or any explosive environment. Electric motors create sparks

which may ignite dust or fumes.

OPERATION

• The heater must only be used by people who have read these

instructions and have been trained in its use.

•DO NOT obstruct the air inlet and outlet sections of the heater.

•DO NOT cover the heater.

•DO NOT touch the heater casing or grille when first switched off, as these

will be very hot and will take time to cool.

•DO NOT get the heater wet or use in areas of high condensation.

•DO NOT allow the power lead to touch hot surfaces.

•DO NOT connect other appliances to the same mains socket as the

heater.

• Only use the heater in a level position.

•DO NOT use this heater with a programmable timer used to switch it on

automatically.

WARNING: DO NOT USE THE HEATER NEAR FLAMMABLE MATERIAL,

LIQUIDS, SOLIDS, GASSES OR COMPRESSED GAS CYLINDERS ETC.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ELECTRICAL CONNECTIONS

Before switching the product on, make sure that the voltage of your electricity

supply is the same as that indicated on the rating plate. Connecting it to any

other power source may cause damage.

If it is necessary to change the fuse in the plug, the fuse cover must be refitted.

If the fuse cover becomes lost or damaged, the plug must not be used until a

suitable replacement is obtained.

If the plug has to be changed due to damage, a replacement should be

fitted, following the wiring instructions shown below. The old plug must be

disposed of as insertion into a mains socket could cause an electrical hazard.

If the colors of the wires in the power cable of this product do not correspond

with the markings on the terminals of your plug, proceed as follows.

•TheBlue wire must be

connected to the

terminal which is

marked Nor coloured

Black.

•TheBrown wire must

be connected to the

terminal which is

marked Lor coloured

Red.

•TheYellow/Green wire

must be connected to

the terminal which is marked Eor coloured Green.

We strongly recommend that this machine is connected to the mains supply

via a Residual Current Device (RCD)

If in any doubt, consult a qualified electrician. DO NOT attempt any repairs

yourself.

WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY

BEFORE CONNECTING THE HEATER TO THE MAINS SUPPLY.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

OPERATION

1. Place the heater in a level position

on a flat surface and at a safe

distance from flammable

materials. Keep 2m clearance all

round.

2. Connect the heater to a suitable

power supply.

3. Set the thermostat control to the

maximum setting (fully clockwise).

4. Set the mode selector to one of

the following settings:

• The heater will take up to three minutes to reach optimum temperature.

5. Once the room reaches the required temperature, turn the thermostat

control slowly counter-clockwise until the thermostat clicks, leave the

control in this position.

• The room temperature will be maintained at this setting. The heater will

continue to operate until the power switch is turned to the OFF position.

WARNING: DO NOT USE THIS HEATER IN SMALL ROOMS WHEN THEY ARE

OCCUPIED BY PERSONS NOT CAPABLE OF LEAVING THE ROOM ON THEIR

OWN, UNLESS CONSTANT SUPERVISION IS PROVIDED.

CAUTION: PARTS OF THIS HEATER CAN BECOME VERY HOT AND CAUSE

BURNS. PARTICULAR ATTENTION HAS TO BE GIVEN WHERE CHILDREN

AND VULNERABLE PEOPLE ARE PRESENT.

Off

Fan Only

Fan + Heat Setting 1

Fan + Heat Setting 2

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

6. For fan only operation, turn the power switch to the fan only setting and set

the thermostat to its minimum setting.

7. When not in use, disconnect the heater from the mains supply. Store it in a

safe, dry, childproof location.

ADJUSTING THE ANGLE

1. Loosen both adjusting knobs.

2. Adjust to the required angle.

3. Retighten the adjusting knobs.

THERMOSTATIC PROTECTION

The Devil 2000PTC has a thermal cut

out to prevent it from overheating.

If the temperature of the front grille

gets too high the thermal cutout will

turn off the heating elements. When

the fan has cooled the unit sufficiently, normal operation will resume.

FAULTFINDING

Problem Possible Cause Remedy

Heater does not

operate,

although

plugged in with

the switch and

thermostat

switched on.

Plug is loose/bad

connection.

Pull the plug out & check the

connection of the plug and socket.

Fuse blown or

circuit breaker trips.

Replace if necessary and investigate

cause. If fuse blows repeatedly, consult

your Clarke dealer.

No power at socket Insert the plug in a functioning socket

Heating element

glowing hot.

Input voltage too

high.

Use a power supply in accordance

with the rating on the label.

Air inlet grille is

blocked

Ensure the heater is kept away from

any objects which could cover the air

inlet or be drawn into it.

Heater has

failed to heat up

so only the air

fan has

operated.

Control switch not

set at a "HEATING"

level.

Turn switch to a heating level.

Thermostat has

tripped.

Turn the thermostat and listen. If there is

no CLICK and the thermostat is not

damaged, the heater will

automatically switch ON when it has

cooled down.

Abnormal noise Heater is not level. Stand heater on a level surface

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

MAINTENANCE.

• Check that the heater is in good working order. Take immediate action

to repair or replace damaged parts.

•DO NOT allow the heating elements to become covered with dust

which could become a fire hazard. If used in a dusty workplace it should

be cleaned after every use with a dust extractor.

• ONLY recommended parts should be used. Unapproved parts may be

dangerous and will invalidate the warranty.

•DO NOT attempt to repair a damaged heater, contact the CLARKE

service department.

• Clean the heater with a soft damp cloth once cold. DO NOT use

solvents or abrasives

• No other maintenance is required, should you discover any problem

with the heater, return it to the CLARKE service department for repair.

SERVICE & REPAIRS

Have your heater repaired by a qualified person using identical replacement

parts. This will ensure that the safety of the heater is maintained.

ENVIRONMENTAL RECYCLING POLICY

Through purchase of this product, the customer is taking on the obligation to

deal with the WEEE in accordance with the WEEE regulations in relation to the

treatment, recycling & recovery and environmentally sound disposal of the

WEEE.

• In effect, this means that this product must not be discarded with

general household waste. It must be discarded according to the laws

governing Waste Electrical and Electronic Equipment (WEEE) at a

recognized disposal facility.

WARNING: SERVICING OR INTERNAL MAINTENANCE MUST ONLY BE

CARRIED OUT BY THE CLARKE SERVICE DEPARTMENT.

WARNING: ALWAYS DISCONNECT FROM THE POWER SUPPLY AND ALLOW

THE HEATER IT TO COOL DOWN BEFORE PERFORMING ANY

MAINTENANCE TASKS.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

COMPONENT PARTS

NO DESCRIPTION NO DESCRIPTION

1 Front Grille 12 Control Box

2 Air Outlet 13 Outer Casing

3 PTC Heating Element 14 Cable Fastener

4 Air Flue 15 Back Grill

5 Motor 16 Power Cable

6Fan 17Screw

7 Adjustable Thermostat 18 Rubber Gasket

8 Rotary Switch 19 Steel Pipe

9 Control Knob 20 Feet

10 Indicator Lamp Cover 21 Self-Setting Thermostat

11 Thermostat Knob 22 Thermal Protection

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Calentador de Clarke

Clarke

Clarke 6933980 Manual de instrucciones

Clarke

Clarke XRV100 Guía de solución de problemas

Clarke

Clarke Devil 370B Series Manual de instalación y operación

Clarke

Clarke DEVIL 6025 Manual de instrucciones

Clarke

Clarke DEVIL 2000PTC Manual de instrucciones

Clarke

Clarke DEVIL 5000PTC Manual de instrucciones

Clarke

Clarke IRD40 6920415 Manual de instalación y operación

Clarke

Clarke DEVIL 371SPD Manual de instalación y operación

Clarke

Clarke OFR 9 Manual de instrucciones

Clarke

Clarke 6933985 Manual de instrucciones

Clarke

Clarke Devil 6003 Manual de instrucciones

Clarke

Clarke BR13/250 Manual de instrucciones

Clarke

Clarke DEVIL 350 230V Manual de instalación y operación

Clarke

Clarke DEVIL 7030 Manual de instrucciones

Clarke

Clarke DEVIL 7005 Manual de instrucciones

Clarke

Clarke DEVIL 370PC Manual de instalación y operación

Clarke

Clarke OFR13/250 Manual de instrucciones

Clarke

Clarke CONTRACTOR DEVIL 351C Manual de instalación y operación

Clarke

Clarke Devil 355MD Instrucciones de funcionamiento

Clarke

Clarke XR75 Manual de instalación y operación

Clarke

Clarke DEVIL 371SPC Manual de instalación y operación

Clarke

Clarke DEVIL 370SPD Manual de instalación y operación

Clarke

Clarke XR80 Manual de instrucciones

Clarke

Clarke DEVIL 4035 Manual de instalación y operación

Manuales populares de Calentador de otras marcas

oventrop

oventrop Regucor Series Manual de usuario

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manual de usuario

ELMEKO

ELMEKO ML 150 Manual de usuario

BN Thermic

BN Thermic 830T Manual de usuario

KING

KING K Series Guía

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guía de inicio rápido

Well Straler

Well Straler RC-16B Manual de usuario

EUROM

EUROM 333299 Manual de usuario

Heylo

Heylo K 170 Manual de usuario

Eterna

Eterna TR70W Manual de usuario

IRSAP

IRSAP The Radiator Company Ovali Manual de usuario

Empire Heating Systems

Empire Heating Systems WCC65 Manual de usuario

Wetekom

Wetekom 92 86 43 Manual de usuario

Desa

Desa SPC170-F Manual de usuario

Watlow

Watlow Watrod Electric Tubular Heaters Manual de usuario

Haverland

Haverland ECO-DRY GPS Series Manual de lista de piezas

Stelpro

Stelpro ASILVC2060 Series Manual de usuario

iLO

iLO IHP2424 Manual de funcionamiento
