Cisco WAP131 Wireless-N Dual Radio Access Point

with PoE

Cisco WAP351 Wireless-N Dual Radio Access Point

with 5 Ports Switch

ADMINISTRATION

GUIDE

Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks,

go to this URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner

does not imply a partnership relationship between Cisco and any other company. (1110R)

Cisco WAP131 and WAP351 Administration Guide 3

Contents

Chapter 1: Getting Started 9

Getting Started with the Configuration 9

Supported Browsers 9

Browser Restrictions 9

Launching the Web-based Configuration Utility 10

Logging Out 11

Using the Access Point Setup Wizard 11

Configuring Cisco WAP131 Setup Wizard 12

Configuring Cisco WAP351 Setup Wizard 13

Changing the Default Password 16

Quick Start Configuration 17

Window Navigation 18

Configuration Utility Header 18

Navigation Pane/Main Menu 18

Management Buttons 19

Chapter 2: Status and Statistics 20

System Summary 20

Network Interfaces 22

Traffic Statistics 25

WorkGroup Bridge Transmit/Receive 25

Associated Clients 26

Radio Statistics 28

Email Alert Status 29

View Log 30

TSPEC Client Associations 30

TSPEC Status and Statistics 32

TSPEC AP Statistics 34

Cisco WAP131 and WAP351 Administration Guide 4

Contents

Chapter 3: Administration 35

System Settings 36

User Accounts 36

Adding a User 37

Changing a User Password 37

Time Settings 38

Automatically Acquiring the Time Settings through NTP 38

Manually Configuring the Time Settings 39

Log Settings 40

Configuring the Persistent Log 40

Configuring Remote Log Server 41

Email Alert 42

Configuring Email Alert Settings 43

Email Alert Examples 44

HTTP/HTTPS Service 45

Configuring HTTP and HTTPS Services 45

Managing SSL Certificates 47

Management Access Control 48

Manage Firmware 48

Swapping the Firmware Image 49

TFTP Upgrade 49

HTTP/HTTPS Upgrade 50

Manage Configuration File 51

Backup Configuration File 51

Download Configuration File 52

Copy/Save Configuration 53

Configuration Files Properties 54

Reboot 54

Discovery—Bonjour 55

Packet Capture 56

Packet Capture Configuration 56

Cisco WAP131 and WAP351 Administration Guide 5

Contents

Local Packet Capture 57

Remote Packet Capture 59

Packet Capture Status 62

Packet Capture File Download 62

Support Information 63

Spanning Tree Settings 63

Chapter 4: LAN 65

Port Settings 65

Configuring Port Settings for Cisco WAP131 65

Configuring Port Settings for Cisco WAP351 66

VLAN Configuration 67

Configuring VLAN Settings for Cisco WAP131 67

Configuring VLAN Settings for Cisco WAP351 68

IPv4 Setting 69

IPv6 Setting 70

Chapter 5: Wireless 74

Radio 74

Rogue AP Detection 81

Viewing the Rogue AP List 82

Saving the Trusted AP List 84

Importing a Trusted AP List 84

Networks 85

SSID Naming Conventions 85

VLAN IDs 86

Configuring VAPs 86

Configuring Security Settings 89

None (Plain-text) 89

Static WEP 89

Static WEP Rules 91

Dynamic WEP 91

Cisco WAP131 and WAP351 Administration Guide 6

Contents

WPA Personal 93

WPA Enterprise 94

Scheduler 97

Adding Scheduler Profiles 97

Configuring Scheduler Rules 98

Scheduler Association 99

Bandwidth Utilization 99

MAC Filtering 100

Configuring a MAC Filter List Locally on the WAP device 100

Configuring MAC Authentication on the RADIUS Server 101

WDS Bridge 102

Configuring STP for Cisco WAP131 103

Configuring Untagged VLAN for Cisco WAP351 103

Configuring WDS Bridge 104

WEP on WDS Links 105

WPA/PSK on WDS Links 105

WorkGroup Bridge 106

Quality of Service 109

Chapter 6: System Security 113

RADIUS Server 113

802.1X/802.1X Supplicant 115

Configure 802.1X Supplicant for Cisco WAP131 115

Configure 802.1X for Cisco WAP351 117

Password Complexity 120

WPA-PSK Complexity 121

Chapter 7: Quality of Service 122

Global Settings 122

Configuring QoS Settings for Cisco WAP131 122

Configuring QoS Settings for Cisco WAP351 123

Cisco WAP131 and WAP351 Administration Guide 7

Contents

Class Map 124

Configuring an IPv4 Class Map 124

Configuring an IPv6 Class Map 127

Configuring a MAC Class Map 129

Policy Map 131

QoS Association 133

QoS Status 133

Chapter 8: ACL 135

ACL Rule 135

IPv4 and IPv6 ACLs 135

MAC ACLs 136

Workflow to Configure ACLs 136

Configure IPv4 ACLs 136

Configure IPv6 ACLs 140

Configure MAC ACLs 142

ACL Association 144

ACL Status 145

Chapter 9: SNMP 147

General 147

Groups 151

Users 153

Targets 154

Chapter 10: Captive Portal 156

Global Configuration 157

Local Groups/Users 158

Local Groups 158

Local Users 159

Cisco WAP131 and WAP351 Administration Guide 8

Contents

Instance Configuration 160

Instance Association 163

Web Portal Customization 164

Configuring CP Authentication Page 164

Uploading and Deleting Images 167

Authenticated Clients 168

Chapter 11: Single Point Setup 170

Single Point Setup Overview 170

Managing Single Point Setup Across Access Points 171

Single Point Setup Negotiation 172

Operation of a Device Dropped From a Single Point Setup 173

Configuration Parameters Propagated and Not Propagated to Single Point

Setup Access Points 173

Access Points 175

Configuring the WAP Device for Single Point Setup 175

Viewing Single Point Setup Information 176

Adding a WAP Device to a Single Point Setup 177

Removing a WAP Device from a Single Point Setup 177

Navigating to Configuration Information for a Specific Device 177

Navigating to a Device Using its IP Address in a URL 178

Sessions 178

Channel Management 180

Configuring and Viewing the Channel Assignments 180

Viewing Channel Assignments and Setting Locks 181

Configuring Advanced Settings 182

Wireless Neighborhood 183

Viewing Neighboring Devices 183

Viewing Details for a Single Point Setup Member 185

Appendix A: Where to Go From Here 186

Cisco WAP131 and WAP351 Administration Guide 9

Getting Started

This chapter provides an introduction to the web-based Configuration Utility of the

Cisco WAP131 and WAP351 Wireless-N Dual Radio Access Points. It includes

these topics:

•Getting Started with the Configuration

•Using the Access Point Setup Wizard

•Changing the Default Password

•Quick Start Configuration

•Window Navigation

Getting Started with the Configuration

This section describes system requirements and how to access the web-based

Configuration Utility.

Supported Browsers

Before you begin to use the configuration utility, make sure that you have a

computer with Internet Explorer 7.0 or later, Firefox 3.0 or later, Chrome 5.0 or later,

or Safari 3.0 or later.

Browser Restrictions

•If you are using Internet Explorer 6, you cannot directly use an IPv6 address

to access the WAP device. You can, however, use the Domain Name System

(DNS) server to create a domain name that contains the IPv6 address, and

then use that domain name in the address bar in place of the IPv6 address.

Getting Started

Getting Started with the Configuration

Cisco WAP131 and WAP351 Administration Guide 10

•When using Internet Explorer 8, you can configure security settings from

Internet Explorer.

-Select Tools -> Internet Options and then select the Security tab.

-Select Local Intranet and then select Sites.

-Select Advanced and then select Add. Add the intranet address of the

WAP device (http://<ip- address>) to the local intranet zone. The IP

address can also be specified as the subnet IP address so that all

addresses in the subnet are added to the local intranet zone.

•If you have multiple IPv6 interfaces on your management station, use the

IPv6 global address instead of the IPv6 local address to access the WAP

device from your browser.

Launching the Web-based Configuration Utility

Follow these steps to access the configuration utility from your computer to

configure the WAP device:

STEP 1 Connect the WAP deviceto the same network (IP subnet) as your computer. The

factory default IP address configuration of the WAP device is DHCP. Make sure

that your DHCP server is running and can be reached.

STEP 2 Locate the IP address of the WAP device.

a. The WAP device can be accessed and managed by Cisconetwork tools and

services including the Cisco FindIT Network Discovery Utility that enables you

to automatically discover all supported Cisco devices in the same local

network segment as your computer. You can get a snapshot view of each

device or launch the product configurationutility to view and configure the

settings. For more information, see http://www.cisco.com/go/findit.

b. The WAP device is Bonjour-enabled and automatically broadcasts its services

and listens for services being advertised by other Bonjour-enabled devices. If

you have a Bonjour-enabled browser, such as Microsoft Internet Explorer with a

Bonjour plug-in, or the Apple Mac Safari browser, you can find the WAP device

on your local network without knowing its IP address.

You can download the complete Bonjour for Microsoft Internet Explorer browser

from Apple’s website by visiting: http://www.apple.com/bonjour/.

c. Locate the IP address assigned by your DHCP server by accessing your router

or DHCP server. See your DHCP server instructions for more information.
