Americas Headquarters:

Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA

Release Notes for

Cisco Configuration Professional Express 1.0

May 19, 2008

These release notes support Cisco Configuration Professional Express (Cisco CP Express) 1.0. They

should be used with the documents listed in the “Related Documentation” section on page 15 and in

particular, the Release Notes for Cisco Configuration Prefessional.

These release notes are updated as needed. To ensure that you have the latest version of these release

notes, go to http://www.cisco.com/go/ciscocp. In the Support box, click General Information >

Release Notes. Then, find the latest release notes for your release.

Contents

This document contains the following sections:

•Introduction, page 1

•System Requirements, page 2

•Installation Notes, page 8

•Limitations and Restrictions, page 9

•Important Notes, page 9

•Caveats, page 12

•Related Documentation, page 15

Introduction

Cisco CP Express is a graphical configuration tool that enables a user to configure a LAN and WAN

connection, make security settings to protect the router, and, configure a basic firewall, and Network

Address Translation. Cisco CP Express is installed in Flash memory on routers shipped with Cisco

Configuration Professional (Cisco CP).

Release Notes for Cisco Configuration Professional Express 1.0

OL-16652-01

System Requirements

This sections describes PC and router system requirements. It contains the following parts:

•PC System Requirements, page 2

•Router System Requirements, page 2

•Cisco IOS Releases, page 6

•Cisco CP Ordering Options, page 7

PC System Requirements

Cisco CP Express can run under the native Java Virtual Machine in the supported browsers, and also

JRE.

Table 1 lists the system requirements for a PC running Cisco CP Express including Web browser

versions and Java runtime environment versions.

Router System Requirements

•Supported Routers, page 2

•Supported Adapters, Cards and Network Modules, page 4

•Cisco IOS Releases, page 6

Supported Routers

This section lists the routers that Cisco CP Express supports, by series.

Table 1 PC System Requirements

System Component Requirement

Operating System Any of the following:

•Microsoft Windows Vista Business Edition. Microsoft

recommends this operating system be installed in administrator

mode.

•Microsoft Windows Vista Ultimate Edition. Microsoft recommends

this operating system be installed in administrator mode.

•Microsoft Windows XP with Service Pack 2

Browser Cisco CP Express can be used with the following browsers:

•Firefox 1.0.6 and later versions

•Internet Explorer 5.5 and later versions

•Netscape 7.1, 7.2, and 9.0

Screen Resolution 1024 X 768

Java Runtime Environment Cisco CP Express can run under the native Java Virtual Machine in the

supported browsers, and also under the Java Runtime Environment.

Release Notes for Cisco Configuration Professional Express 1.0

OL-16652-01

System Requirements

Note Cisco CP Express does not support Telco/CO router models.

Cisco 800 Series

Cisco CP Express is supported on the following Cisco 800 series routers:

•Cisco 815

•Cisco 861

•Cisco 881

•Cisco 888

Cisco 1800 Series

Cisco CP Express is supported on the following Cisco 1800 series routers:

•Cisco 1801

•Cisco 1801W

•Cisco 1801W-M

•Cisco 1801M

•Cisco 1802

•Cisco 1802W

•Cisco 1803

•Cisco 1803W

•Cisco 1805

•Cisco 1811

•Cisco 1811W

•Cisco 1812

•Cisco 1812W

•Cisco1812J

•Cisco 1812W-J

•Cisco 1812W-P

•Cisco 1841

•Cisco 1861

Cisco 2800 Series

Cisco CP Express is supported on the following 2800 series routers:

•Cisco 2801

•Cisco 2811

•Cisco 2821

•Cisco 2851

Release Notes for Cisco Configuration Professional Express 1.0

OL-16652-01

System Requirements

Cisco 3800 Series

Cisco CP Express is supported on the following Cisco 3800 series routers:

•Cisco 3825

•Cisco 3845

Supported Adapters, Cards and Network Modules

This section contains support information about adapters, cards, and network modules

Network Modules

Cisco CP Express supports the following network modules:

•NM-4T

•NM-1FE2W-V2

•NM-1FE-FX-V2

•NM-2FE2W-V2

•NM-1FE-FX

•NM-4A/S (synchronous only)

•NM-8A/S (synchronous only)

•NM-CIDS-K9

•NM-16ESW

•NM-16ESW-1GIG

•NM-16ESW-PWR

•NM-16ESW-PWR-1GIG

•NMD-36ESW-PWR

•NMD-36ESW-PWR-2GIG

Cisco CP Express supports the following EtherSwitch Service Network Modules:

•NME-16ES-1G-P

•NME-X-23ES-1G-P

•NME-XD-24ES-1S-P

•NME-XD-48ES-2S-P

WAAS Modules

Cisco CP Express supports the following Wide Area Application Services (WAAS) modules:

•NME-WAE-502-K9

•NME-WAE-522-K9

•NME-WAE-302-K9

WAN Interface Cards

Cisco CP Express supports the following WAN interface cards:

•WIC-1T

Release Notes for Cisco Configuration Professional Express 1.0

OL-16652-01

System Requirements

•WIC-2T

•WIC-2A/S (Frame Relay, PPP, HDLC, no asynchronous)

•WIC-1ADSL

•WIC-1SHDSL

•WIC-1DSU-T1-V2

•WIC-1B-S/T-V3

•WIC-1AM

•WIC-2AM

•WIC-4ESW

•WIC-1SHDSL-V2

•WIC-1SHDSL-V3

•WIC 1ADSL-DG

•WIC 1ADSL-I-DG

Cisco CP Express supports the following high-speed WAN interface cards (HWICs):

•HWIC-4T

•HWIC-4A/S

•HWIC-4ESW

•HWIC-8A/S-232

•HWICD-9ESW

•HWIC-16A

•HWIC-AP-G-X

•HWIC-AP-AG-X

•HWIC-ADSL-B/ST

•HWIC-ADSLI-B/ST

•HWIC-1ADSL

•HWIC-1ADSLI

•HWIC1-ADSL-M

•HWIC-1CABLE-D

•HWIC-1CABLE-E/J

•HWIC-1FE

•HWIC-2FE

•HWIC-2SHDSL

•HWIC-4SHDSL

AIM Modules

Cisco CP Express supports the following advanced integration modules (AIMs):

•AIM-VPN/BPII-PLUS

•AIM-VPN/HPII-PLUS

Release Notes for Cisco Configuration Professional Express 1.0

OL-16652-01

System Requirements

•AIM-VPN/EPII-PLUS

•AIM-VPN/SSL-1

•AIM-VPN/SSL-2

•AIM-VPN/SSL-3

Cisco IOS Releases

Cisco CP Express is compatible with the Cisco IOS releases listed in Table 2.

Determining the Cisco IOS Release

To determine the release of Cisco IOS software currently running on your Cisco router, log in to the

router and enter the show version EXEC command. The following sample output from the show version

command indicates the Cisco IOS release on the second output line:

Router> show version

c3845-1#show version

Cisco IOS Software, 3800 Software (C3845-ADVENTERPRISEK9-M), Version 12.4(11)XW2, RELEASE

SOFTWARE (fc1)

Technical Support: http://www.cisco.com/techsupport

Compiled Tue 03-Jul-07 00:49 by prod_rel_team

Memory Requirements

Table 3 shows how much memory is required to support Cisco CP Express and related applications.

Table 2 Cisco CP Express-Supported Routers and Cisco IOS Versions

Router Model Earliest Cisco CP Express-Supported Cisco IOS Versions

Cisco 815 •12.4(11)T

Cisco 860 series

Cisco 880 series

•12.4(15)XZ

Cisco 1801

Cisco 1802

Cisco 1803

•12.4(9)T

•12.5(1)M

Cisco 1805 •12.4(15)XY

Cisco 1811

Cisco 1812

•12.4(9)T

•12.5(1)M

Cisco 1841 •12.4(9)T

•12.5(1)M

Cisco 1861 •12.4(11)XW

Cisco 2800 •12.4(9)T

•12.5(1)M

Cisco 3800 •12.4(9)T

•12.5(1)M

Release Notes for Cisco Configuration Professional Express 1.0

OL-16652-01

System Requirements

Cisco CP Ordering Options

Cisco CP Express is shipped with every ordering option under which Cisco CP can be ordered. Table 4

on page 7 describes the Cisco CP ordering option. Ordering options are also referred to as SKUs.

Table 3 Cisco CP Express File List

Filename Size Description

cpexpress.tar 2.17 MB

2,281,472 bytes

Cisco CP Express application file

home.shtml 1.01 KB

(1,038 bytes)

Cisco CP Express support file

home.tar 110 KB Cisco CP Express support file

cpconfig-modelnum.

For example:

cpconfig-180x.cfg

2.82 to 3.33 KB Default Configuration File

securedesktop-ios-3.1.1.45-

k9.pkg

1.61 MB

(1,697, 952 bytes)

Cisco Secure Desktop client software for SSL VPN

clients.

sslclient-win-1.1.4.176.pkg 406 KB

(415,956 bytes)

Full tunnel client software for SSL VPN clients

wlanui.tar 2.13 MB

(2, 242, 560 bytes)

Wireless Application

128MB.sdf 515 KB

(527, 849 bytes)

Signature Definition File (SDF) used by Cisco IOS

IPS

256MB.sdf 775 KB

(793, 739 bytes

Signature Definition File (SDF) used by Cisco IOS

IPS

Table 4 Cisco CP Ordering Options

Ordering Option (SKU) Description

CCP-CD Cisco CP: Shipped on CD

Cisco CP Express: Shipped in router flash memory

SSL Signature File: Shipped in router flash memory

Default Configuration File: Shipped in router flash memory and in NVRAM

CCP-CD-NOCF Cisco CP: Shipped on CD

Cisco CP Express: Shipped in router flash memory

SSL Signature File: Shipped in router flash memory

Default Configuration File: Shipped in router flash memory.

Note This ordering option does not provide the default configuration file

for Cisco 800 series routers.

Release Notes for Cisco Configuration Professional Express 1.0

OL-16652-01

Installation Notes

This section contains important information regarding installation of Cisco CP Express.

Downloading Cisco CP Express From Cisco.com and Installing It On the Router

If Cisco CP Express is not currently installed on the router, and you want to install it, complete the

following steps:

Step 1 Go to http://www.cisco.com/go/ciscocp, and click Download Software in the Support box.

Step 2 If a login page appears, enter your login credentials. In the Software Download page, click Cisco

Configuration Professional.

Step 3 In the next download page that appears, click the release number that you want to download.

Step 4 Click on the Cisco Configuration Professional package link. The zip file contains the Cisco CP, and

Cisco CP Express installation files.

Uninstalling Cisco CP Express Files

If you want to remove Cisco CP Express from flash memory or from a router disk file system, you can

do so by logging onto the router and completing the following steps in EXEC mode:

Step 1 Change to the directory in which the Cisco CP Express files are located.

If the router has a flash file system, use the following command:

router# cd flash:

CCP-EXPRESS Cisco CP: Not shipped

Cisco CP Express: Shipped in router flash memory

SSL Signature File: Shipped in router flash memory

Default Configuration File: Shipped in router flash memory and in NVRAM

CCP-EXPRESS-NOCF Cisco CP: Not shipped

Cisco CP Express: Shipped in router flash memory

SSL Signature File: Shipped in router flash memory

Default Configuration File: Shipped in router flash memory.

Note This ordering option does not provide the default configuration file

for Cisco 800 series routers.

Table 4 Cisco CP Ordering Options

Ordering Option (SKU) Description

Release Notes for Cisco Configuration Professional Express 1.0

OL-16652-01

Limitations and Restrictions

If the router has a disk file system, use the following command:

router# cd diskN

Replace Nwith the actual number of the disk. Use the slot keyword instead of the disk keyword if

necessary.

Step 2 Use the delete command to remove the Cisco CP Express files. The example below deletes the file

cpexpress.tar:

router# delete cpexpress.tar

Delete filename [cpexpress.tar]?

Delete flash:cpexpress.tar? [confirm]

Press Return to confirm the deletion.

Step 3 Use the delete command to remove the remaining Cisco CP Express files.

Step 4 Reclaim memory space by using the squeeze flash: command:

router# squeeze flash:

It is not necessary to use the squeeze flash: command on DOS-based file systems.

Limitations and Restrictions

This section describes the following restrictions and limitations that may apply to Cisco CP Express:

•Cisco CP Express Does Not Support Cisco 7000 Series Routers, page 9

Cisco CP Express Does Not Support Cisco 7000 Series Routers

Cisco CP Express does not support the Cisco 7204VXR, Cisco 7206VXR, and Cisco 7301 Routers and

is not shipped with those routers.

Important Notes

This section contains important information for Cisco CP Express. It contains the following sections:

•Cisco IOS Enforces One-Time Use of Default Credentials

•Cisco CP Express May Not Operate with Custom Configuration File

•Popup Blockers Disable Cisco CP Express Online Help

•Disable Proxy Settings

•Security Alert Dialog May Remain After Cisco CP Express Launches

Cisco IOS Enforces One-Time Use of Default Credentials

To address CSCsm25466, Cisco IOS images included with recent shipments of Cisco 800, Cisco 1800,

Cisco 2800, and Cisco 3800 routers, enforce the one-time use of the default username and password

provided in the default configuration file shipped with Cisco CP Express and Cisco CP. If you bypass

Release Notes for Cisco Configuration Professional Express 1.0

OL-16652-01

Important Notes

Cisco CP Express and use a console or Telnet connection to log into the router, the login and exec

banners warn you that you must change the username “cisco” and password “cisco” before you log off

of the router. If you do not change the credentials as directed, you will not be able to log on to the router

the next time that you attempt to do so.

The following Cisco IOS releases enforce the one-time use of the default credentials:

•12.4(11)T or later

•12.4(11)SW, 12.4(11)SW1, 12.4(11)XV, 12.4(11)XJ

•12.4(9)T5, 12.4(9)T6

•12.3(21), 12.3(22)

Follow the procedure in this section to secure the router by creating a new username and password, to

remove the login banner and exec banner warnings, and to save the configuration changes to the router

startup configuration.

Note If you login to the router using a Telnet or a console connection but do not complete the steps in this

procedure, be aware of the following:

•If you do not change the default username and password, and then log off the router, you will not be

able to log into the router again without entering the reload command. No additional warning is

given before you log off.

•If you do not change the default username and password, but do enter the write memory command

before ending the session, future logins will be disabled. In this case, you will need to follow the

password recovery procedure at the following link:

http://www.cisco.com/en/US/products/sw/iosswrel/ps1831/products_tech_note09186a00801746e6.sht

To secure the router, remove the banner warnings and save the changes to the router startup config,

complete the following steps:

Step 1 Connect the light blue console cable, included with your router, from the blue console port on your router

to a serial port on your PC. Refer to your router’s hardware installation guide for instructions.

Step 2 Connect the power supply to your router, plug the power supply into a power outlet, and turn on your

router. Refer to your router’s quick start guide for instructions.

Step 3 Use HyperTerminal or a similar terminal emulation program on your PC, with the terminal emulation

settings of 9600 baud, 8 data bits, no parity, 1 stop bit, and no flow control, to connect to your router.

Step 4 When prompted, enter the username cisco, and password cisco.

Step 5 Enter configuration mode by entering the following command:

yourname# configure terminal

Step 6 Create a new username and password by entering the following command:

yourname(config)# username username privilege 15 secret 0password

Replace username and password with the username and password that you want to use.

Step 7 Remove the default username and password by entering the following command:

yourname(config)# no username cisco

Otros manuales para 1811W - Integrated Services Router Wireless

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Software de Cisco

Cisco

Cisco TELEPRESENCE MANAGEMENT SUITE EXTENSION 2.2 - FOR MICROSOFT... Manual de servicio

Cisco

Cisco CiscoWorks 1105 Manual de usuario

Cisco

Cisco CTS-500 Manual de usuario

Cisco

Cisco XO Manual de usuario

Cisco

Cisco CRS-1 - Carrier Routing System Router Manual de instrucciones

Cisco

Cisco ROUTER-SDM-CD Manual de usuario

Cisco

Cisco IP Communicator Manual de instrucciones

Cisco

Cisco 2600 Series Cómo utilizar

Cisco

Cisco Servers Manual de usuario

Cisco

Cisco 6503-E - Catalyst Chassis With Supervisor Engine 32... Manual de instrucciones

Cisco

Cisco IPS-4240-K9 - Intrusion Protection Sys 4240 Manual de usuario

Cisco

Cisco Signaling Interface H.323 Manual de usuario

Cisco

Cisco TELEPRESENCE MANAGEMENT SUITE SECURE SERVER - CONFIGURATION GUIDE... Manual de usuario

Cisco

Cisco AP775A - Nexus Converged Network Switch 5010 Manual de servicio

Cisco

Cisco SGACL Manual de usuario

Cisco

Cisco ACTIVE NETWORK ABSTRACTION - BROCHURE WHATS NEW IN RELEASE... Manual de usuario

Cisco

Cisco Cisco Access Registrar 4.2 Manual del operador

Cisco

Cisco UC520-24U-8FXO-K9 Guía de instalación

Cisco

Cisco 11.0 BT Cómo utilizar

Cisco

Cisco GO GREEN Manual de usuario

Cisco

Cisco CONFERENCING EXTENSIONS - ADMINISTRATOR GUIDE FOR MICROSOFT... Manual de servicio

Cisco

Cisco 881 SRST - EN Security Router Manual de usuario

Cisco

Cisco Router IOS XR Manual de usuario

Cisco

Cisco DVD-ROM Manual de instalación y operación

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

Avaya

Avaya NULL One-X for RIM Blackberry Manual de usuario

HP ProLiant BL420c Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Avaya

Avaya Interaction Center Manual de usuario

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Canon

Canon Vixia HF21 Manual de usuario

Canon

Canon ZR950 Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario
