CAS LDT Manual de usuario

1

LDT(Low Deck truck scale)

로고

입력

제품 사진 삽입

제품 사진 삽입

2

Introduce

Easy Installation ( block type assembly )

Deck height is less than 300mm

Load Cell : WBK ( Lighting Protection circuit )

Number of load cell :

• 3 x 10m – 6 loadcell

• 3 x 12m – 6 loadcell

• 3 x 15m – 8 loadcell

• 3 x 18m – 8 loadcell

Indicator : CI - 5010A + PC ( option )

TM -7500 ( Ticket or Sprocket )

3

Truck Scale Type

Truck Scale are PITTLESS and PIT type.

Pittless truck scale structure is turn over the

pit type scale ( general ).

Water drain ( Natural )

4

Construction ( foundation )

Dig down the ground

Sand + pebble spread ( about 150 ~ 200mm )

Steel fiber ( Φ16mm ) + Φ6mm steel mesh

– for the strength.

Concrete strength( 8kg / cm2).

Angle ( steel angle ) - ramp.

– Come in & out going

Lamp slope.

– Small angle - large space.

– large angle - load cell damage.

5

1. Foundation

6

Level adjust

Each load cell level ( use the rig ).

Lamp to load cell

Water level.

– height

– horizontal

Shim ( steel plate 0.1 to 2mm )

Shrinkless cement

7

2. Level adjust

8

2. Level adjust ( height & horizontal )

9

2. Level adjust ( load cell set )

10

Main frame assembly

Load cell bolting.

Water level ( height & horizontal )

Shim ( steel plate 0.1 to 2mm )

By pass strap - lighting & welding protect

Load cell insulation resistance check

– 2,000Mohm (min 1,000Mohm)
