CAS PD-II Manual de usuario

9002 - PD2- 0011- 1

2004. 8

PD -

ECR Interface Scale

O W NER’SMA NUAL

CONTENTS

PRECAUTIONS4

PREFACE 6

NAMESANDFUNCTIONS6

OPERATIONS8

General Weighing 9

ECRInterface 9

ERRORMESSAGE10

SPECIFICATIONS11

For consistent and accurate reading,

maintain periodical check by your

CAS authorized dealer.

Avoid sudden shock to the scale.

Internal mechanism could be damaged.

Place the scale on firm and temperature

consistent environment.

Keep the scale away from other

electromagnetic generating devices.

This may interfere with accurate

reading.

Grab on the bottom of the scale when

moving. Do not hold by the platter.

Attention

If the scale is not properly level, please adjust

the 4 legsat the bottom of the scale

(turn legs clockwise or counterclockwise)

so as to center the bubble of

the leveling gauge

inside the indicated

circle.

Do not disassemble the scale.

When any damage or defect occurs,

contact your CAS

authorized dealer

immediately for

proper repair.

Do not overload beyond the maximum

weight limit.

Do not pull the plug by its cord when

unplugging. Damaged cord could cause

electric shock or fire.

To prevent from fire occurring, Do not

place or use the scale near flammable or

corrosive gas.

Avoid placing the scale near heater

or in direct sunlight.

Scale must be grounded to minimize

electricity static. This will minimize

defect or electric shock.

Insert plug firmly to wall outlet to

prevent electric shock.

To reduce electric shock or incorrect

reading, Do not spill water on the scale

or place it in humid condition.

Warning

PRECAUTIONS

Toensurethatyou getthemostfromyourscale

pleasefollowthese

instruction

Thesocket-outletshall beinstalledneartheequipmentand shall beeasily

accessible

Make suretoplug yourscale intotheproperpoweroutlet

For

maximumperformance

plug intoapoweroutlet30 minutesbeforetheusagefor

warmup

PREFACE

NAMESANDFUNCTIONS

Thank you for purchasing your CAS PD-II sacle.

CAS scales are designed and produced under rigid quality control to deliver

outstanding performance, reliability and long life.

This manual will help you with the proper operation and care of your new

CAS PD-II.

Please review the PD-II sacle manual before you use the scale and keep it handy

for future reference.

OVERALL VIEW

PLATTER

DISPLAY

ADJUSTING BOLT

SIDE PLATE

KEYBOARD

POWER SWITCH

PARALLEL PORT

RS232

PLATTER

DISPLAY

ADJUSTING BOLT

POLE TYPE

DISPLAY CABLE

POLE TYPE DISPLAY

KEYBOARD

KEYBOARD

DISPLAY

Makesurethatpoweris OFF.Whilepressing "#"key,

turnon thepower.“EcrSEt”is shownon thedisply.And then

currentECRtypeis shownon thedisplay as “tYPE-2”.

ECRInterface

PD-II can interface with most ECRs by selecting TYPE 0 to TYPE 6.

ECRTypeSelection

OPERATIONS

General Weighing

The display indicates ZERO symbol, if weight is at ZERO.

When the display is not zero though there is nothing on the platter, press the

ZERO key.

Turnon thepower.Thedisplay shows 0.00 or0.000.

MakesurethatST(Stable)and ZEROlamps areOn.

Placeanitemon theplatter.WhentheST(Stable)lampis

0n,readtheweight.

KEY FUNCTIONS

Usedtosetthezeropointto0.00 or0.000.

Usedas ESC key inSetup Mode.

Usedas ENTERkey inSetup Mode.

Usedas Scroll key inSetup Mode.

KEY DESCRIPTION

Ifyou selectECRtype5,press the" " key until thedisplay

shows “tYPE-5”. (RefertoTable1.)

TosavecurrentECRtype,press theZEROkey.

SPECIFICATIONS

ERRORMESSAGE

FailureofA/DModule

Anerrorofinitialzerorange

Call yourCASdealer

Settheplatterempty

Makesurethereis aplatteron thescale

ERRORREASONS SOLUTIONS

Err

Err 1

MostPOS,ECRs and Some

TEC POS System

SharpER-Axxx,New Sanyo

ECRs using RS-232 others

MostPOS System

Samsung,CRS,NCR2170 and

otherECRs

NCI General.

MostPOS Software

Samsung ER-670

TEC 4 Digit4BitParallel

(New kg)

TEC 4 Digit4BitParallel

(Oldkg)

Universal4 BitParallel

ECR-TYPE 0

ECR-TYPE 1

ECR-TYPE 2

ECR-TYPE 3

ECR-TYPE 4

ECR-TYPE 5

ECR-TYPE 6

key

4-BitParallelRS-232 Serial

Serial Communication

9600 Baud Rate, 7 Date bit, Even Parity. 1 Stop bit

Table1.

MODEL

DIVISION

INTERNALRESOLUTION

EXTERNALRESOLUTION

DISPLAY

DISPLAY LAMP

INTERFACE

PRODUCT SIZE

PLATTERSIZE

PRODUCT WEIGHT

TEMPERATURE RANGE

POWERSUPPLY

15 lb30 lb60 lb150 lb

6lb0.002 lb15 lb0.005 lb30 lb0.01lb60 lb0.02 lb

15 lb0.005 lb30 lb0.01 lb60 lb0.02 lb150 lb0.05 lb

1/90,000

1/3,000 DUAL

VFD6 DIGITS

ST(STABLE),ZERO

RS-232C,4-BitParallelCommunication (ECRInterface)

380(W)280(D)79(H)[mm]

380(W)280(D)[mm]

6.7kg

10°C 40°C

AC 120V /60Hz

DUALINTERVAL
