CAS IE-100 Manual de usuario

CONTENTS

SAFETYGUIDE................................................4

PRECAUTION...................................................4

PRODUCT CHARACTERISTICS................5

SPECIFICATION..............................................5

MODEL...............................................................6

SIZEAND NET WEIGHT...............................7

OPERATION......................................................8

ELECTRICALPRINCIPLE DIAGRAM...10

DISPLAY MESSAGE .....................................11

TROUBLESHOOTING.................................12

REMOTE CONTROLLER...........................13

SAFETY GUIDE

Read carefully the following instruction and advice before using this scale.

■ Over-loading this scale is harshly prohibited

■ Refrain from long-time loading that could lead to excessive fatigue on loadcell

used inside the scale. Excessive fatigue that on loadcell would decrease the

accuracy and shorten the life of scale.

■ Check the shackle and hook regularly.

■ Check the battery power level before/after use and recharge the scale in time.

■ In order to maximize the battery life, periodic recharging is necessary for scales even not

in use for long time.

■ Do not try to repair the scale by yourselves.

■ Use privately attached charger only.

PRECAUTION

■ The crane scale is a kind of precise weighing instrument, pay attention on

operantion and maintenance.

■Rotate the load instead of machine otself if necessary for operation.

■Stop using the machine under the circumstances of thunder & rain.

■Check periodicly if the clips/pins and screws of the machine are loose or broken

before use.

■ If low battery signal appeare & LED annunciator goes green while charging,

please check the battery.

■ Hang the machine instrad for storage while not in use in order to prevent from

unnecessary load in the weight sensor inside.

■ Do not subject the scale to sudden to sudden temperature changes.

■ Avoid from the shock of excessive weight.

PRODUCT CHARACTERISTICS

Model Display characteristics

30mm(1.2″)LED

IE Series 30mm(1.2″)LCD

High accuracy, small volume,

easy to bring

■ High quality: The process management is operated according to OIMLR76,

GB/T11883-2002, and get the European CE certificate.

■ Safty installation:Aluminum Die-Casting Case, high intensity hook and shackle,

special loadcell for safty installation.

■ High reliability: Using high quality components on PCB circul board to board to insure

long time stability.

■ Broad applicability: 30mm high character display, 25M distance eyeshot, can be used

in storage industry, textile industry, metallurgy industry etc.

■ Simple operation: Check battry voltage automatically, wireless remote controller,

separate battery space, small volume, easy to bring.

■ Complete function: Kg/Lb conversion, Hold,Tare, Division choice, Stablity regulation,

Accumulation/Search, Gross/Net conversion, parameter regulation etc.

SPECIFICATION

Standard GB/T11883-2002《Electrical Crane Scale》

Accuracy class OIML class III

Display 30mm(1.2″) 5digits LCD/LED

Zero Range 4% full capacity

Tare Range 100% Full capacity

Stable Time ≤10 seconds

Overload Indication 100% Max. capacity + 9e

Max. Safety Load 125% Max. capacity

Ultimate Load 400% Max. capacity

Battery Life ≥50 hours

Battery Type Fully sealed Lead-Acid battery, 6V/5Ah

Adapter DC9V/1500mA

Operating Temp. - 10 ~ + 40℃℃

Operating Humidity ≤85% RH under 20℃

Remote Controller Distance Min. 10m

Battery of Remote Controller 5# battery, 1.5V 2ⅹ

MODEL

Model Max. capacity

(kg / lb) Min. capacity

(kg / lb) Division

(kg / lb) Total display

(kg / lb)

IE-100 50/100 0.5/1 0.02/0.05 n=2000

IE-200 100/200 1/2 0.05/0.1 n=2000

IE-500 200/500 2/4 0.1/0.2 n=2500

IE-1000 500/1000 4/10 0.2/0.5 n=2000

IE-2000 1000/2000 10/20 0.5/1 n=2000

SIZE AND NET WEIGHT

Max.Capacity L

(mm) A

(mm) B

(mm) C

(mm) Net

weight

100kg 335 20 65 20 4.0

200kg 335 20 65 20 4.0

300kg 335 20 65 20 4.0

500kg 360 25 75 20 4.2

1000kg 360 25 75 20 4.2

※ Notice: If there’s any modification, all the date are subject to the scale itself.

↕

OPERATION

■ TURN ON

Operation Display Illustration

【OFF/ON】【8.8.8.8.8 】Display two times

【500.0 】Display capacity two times

【U X.XX 】Display the voltage of battery

【- - - - - 】Wait stable signal

【0】“STB” light, can hang the weight

※Notice: To guarantee the accuracy, leave scale alone for 3~5 minutes after turning on.

■ ZERO

Operation Display Illustration

Press【→0←】on scale 【0】

Press 【ZERO 】on

controller 【0】

After turn on, generally display

【0】, if not for 【0】

Can operate like this

■ TARE

Operation Display Illustration

Press【→T←】on scale 【0】

Press 【TARE 】on

controller 【0】

Press this key to deduct the weight of

Container, while “TARE” light on, the

Scale will show the net weight of load

※Notice:As crane scale deduct the weight of container automatically, so it will show the

net weight of load every time, you needn’t press this key to get net weight until you change

the container or turn off.

※ OVERLOADWARNING

The display will show【-OL-】once the load (Net +Tare) exceeds Max. capacity.

Make sure that theload are withinthe capacity range, otherwise it’s very dangerous.

■ CHECK BATTERY

Press【OFF/ON】on scale, when turn on or turn off, it shows【U X.XX】

Press 【OFF】on controller 2 seconds

Stable after 15 minute, it show【】, after 60minutes, it turn off automatically.

■ HOLD THE WEIGHT READING

Press “HOLD” key on the remote controller to hold the displayed weight reading.

At this moment, “HOLD” light on, Press this key again will disable hold function.

■ LOW BATTERY WARNING

When the battery voltage lower then【U 5.8.0】,thedisplayflash,butthescalecanstillworkuntilthe

displayshow 【-Lb- 】,oneminutelater,itwillturnoffautomatically,youneedtorechargethebatteryto

useagain.

■ POWER SAVING

The display will show 【━】whentheloadareatstablestatusinexcessof15minutesand

revert to normal weighing readings while load changes. When the load are at stable status

in excess of 60 minutes, the scale will turn off automatically

■ RECHARGING BATTERY

1. Turn off, connect the adapter with 220VAC power supply, also insert the plug in the socket

which located in the rearof scale.The light become green, it means it’s recharging automatically,

until the green light become red,that means recharging is finished.

2. Whenyou need to use crane scale hour after hour, take off the rear cover, change the battery with

recharged battery.

Attention:Generally, the time of recharging should not lower than 8 hours,this scale have recharging

protection function, long time recharging will not damage the battery.

■ TURN OFF

Press【OFF/ON】on scale 2 seconds

Press【OFF】on controller 2 seconds

Stable after 15minutes, it show【】, after 60minutes, it turn off automatically.

ELECTRICAL PRINCIPLE DIAGRAM

Control key Control

distance

Load cell Signal

enlarges

A/D

CPU LED or LCD

display

Battery

DISPLAY MESSAGE

Display Illustration

【- - - - -】Waiting stable

【Err10】Accumulated weight not exceed Min. Capacity

【Err11】Accumulated times exceed, (can’t accumulate after 30times)

【Err12】Accumulated weight exceed (can’t accumulate after 99999)

【CLr】Ask if you really want to delete accumulated weight, in case error deletion

【noCLr】Give up deletion

【88888】Confirm deletion

【noACC】No any accumulated value (when you check)

【SHIFt】Conversion, when you press SHIFT in controller

【UX.XX】The voltage of current battery

【SCALE】Enter weight adjustment

【SEtUP】Enter parameter adjustment

【UAdJ 】Enter voltage adjustment

【-OL- 】Overload warning

【-Lb- 】Low battery warning

【End 】End, when parameter adjustment ready

【OFF 】Turn off
