CAS CCB Series Manual de usuario

NOTE

(1) The unauthorized copying of some or all of this manual is prohibited.

(2) The information contained herein is subject to change without notice.

(3) If there are any questions such as wrong or missing parts of the contents

listed in this manual, please contact us.

(4) To improve the product performance, functions can be changed with no

notice.

(5) Please understand that CAS does not have responsibility for a demand

related to loss, lost profit etc. caused by operating the product, regardless

of the third clause.

This is warning & caution mark

This is hazard alert mark

This is useful information mark

CONTENTS

1. Precautions.....................................................5

2. Main Features................................................5

3. Specifications..................................................6

4. Description of Panels and Symbols...........8

5. How to Use a Rechargeable Battery .........9

6. General Functions.......................................10

7. Setting Mode................................................11

8.Test Mode......................................................16

9. IR Remote Controller................................17

10. Wireless Specification (Fmodel)............17

11. Real Time Clock (Fmodel)......................18

12. Wireless Pairing (Fmodel)......................19

13. Check Message..........................................20

1. Precautions

Please be informed that we’re not responsible for any incident or

mishap caused by partial modification of this product. To avoid such

situation, customers need to contact our customer service team or

system installation staff in advance, and any modification should be

conducted under our surveillance.

Do not put too much pressure to keys. Light touching is enough to operate products.

Do not use inflammable substances for cleaning.

Do not use the product in the rain. Keep it dry.

Avoid sudden changes of temperature if possible

Do not use the product in a place with a high-voltage current or severe electronic

noise.

Keep the product in a dry place.

Do not use the product in a place with strong direct sunlight and dust.

Do not use the product in a place with severe vibration.

Check the supply voltage.

Please check if the safety hook is connected well before you install our CCB,

so that the SHACKLE is not separated.

2. Main Features

Swivel hook

Big size display

Easy to exchange battery pack (Li-Po battery)

Standard IR remote controller

LAN communication is possible using the ZigBee (F model)

ZigBee wireless application and real time clock (F model)

3. Specifications

◆Overallview

◆Dimensions

MODEL

Max

(kg/lb)

e=d=

(kg/lb)

Weight

(kg)

DIMMENSION(mm)

CCB-1TL(F)

1,000/2,000

0.2/0.5

8.9

407

CCB-3TL(F)

2,500/5,000

0.5/1

15.2

525

CCB-5TL(F)

5,000/10,000

1/2

16.7

525

CCB-10TL(F)

10,000/20,000

2/5

26.9

697

101

(F) means that ZigBee wireless option is applied to product.

◆Specifications

MODEL

CCB-L

Display

6 digit FSTNLCD 30mm &LEDbacklight

Operatingtime

Approx. 12 hr

Battery

3.7V

Poweradaptor

5V 1A

Displaylamp

Lowbattery, Zero, Tare, Hold, Stable

Function

ON/OFF,Zero,Tare, HOLD, *

Temperature

-20℃~ +60℃

Max. tare weight

FullTare

Safetyoverload

150% ofcapacity

Zero point

Within 2% of Maximum Weight

Initial zeroband

Within 10% of MaximumWeight

Parts

Infraredcontroller, Power adaptor, Manual

◆Parts

[Rechargeableadaptor]

[Cranescale] [Infraredremotecontroller]

4. Description of Panels and Symbols

◆Display

Displaytheweightdata&message

Displayedwhentheweightisstable

Indicatestheweighingunit

IndicateswhentheZigBeecommunicatesdata

Indicateswhentheweightiszero

Indicateswhenthetareisincluded

Indicateswhentheholdfunctionisset

Indicateswhenabatteryhastoberecharged

◆Keypad

Poweronandoffthescale.

Returnthedisplaytozero

Usedtoweighanitembyusingthecontainer

Usedtochangeunit

Usetoturnonandoffthebacklight/holdfunction

5. How to Use a Rechargeable Battery

(1)Methodofrechargebattery

■ Checkthepowersupplyvoltage.

■ Ifadaptorisstillbeingcharged,theREDlampisonasbelowpicture.

■Ifachargingiscompleted,theREDlampisoff.

Thebatterychargingtimetakesabout6hours.

(Thebatterychargingtimeissubjecttobechangedaccordingtobatterycondition.)

Clamp

(2)Methodofexchangebatterypack

■ Turnclampsthatexitonbothsidesofchargertotherightinaquarter

■ Pulloutabatterypack

■ Insertingisinreverse

(3) Batterypackspecifications

Nominalcapacity

4000mAH

Nominalvoltage

3.7V

(4) Lowbatterylamp

Inordertopreventtheelectricdischarge,after LOW BATTERY LAMP ison, thepower will

beturnedoffautomaticallyafterabout1~5hours.

(It’s subjected to be changed according to using conditions.)

6. General Functions

(1)Zerofunction

Use to correct drifted zero value when the scale is unloaded, and motion is not detected.

ThisfunctionworkswhenZEROKEYispressed,andtheZEROLAMPison.

(2) Settingtareweightfunction.

PresstheTARE KEY. Then, thescalewill memorize the weight ofthetareand willdisplay

zerovalue ‘0’kg. The TARELAMPwillbeon.

To escape this function, remove everything from the scale, and press the TARE or ZERO

KEY.Then,theTARELAMPwillbeoffandthisfunctionisterminated.

(3) Holdfunction(F08ofsettingmodemustbesetto4)

Automaticholdfunction

■ Press *KEYwhenthescaleisempty(Initialzerostate).

■ The weight display will indicate .HOLDLAMPison.

■ After loading a thing, if the weight turns stable then, a display shows and

averageweightwillappear.

■ The weight of a loadedthingisdisplayed.

■ To escape the automatic hold mode, when zero point is on, press * KEY.

Then,themessageof isdisplayedandHOLDLAMPisoffandnormal

weighing modeisreverted.

Manualholdfunction

■ Press *KEYloadingathing.

■ This messageof isdisplayedandsequentiallythemessageof is

shownwithappearingtheaverageweight.

■ The weight of a loaded thing is displayed.

■ To escape the manual hold mode, remove everything from a hook, or press the *KEY.

Then,HOLDLAMPwillbeoffandthescalechangesfromaholdmodetoanormal

mode.

7. Setting Mode

(1)Howtoenterthismode

PresstheON/OFFKEYwhilepressingtheTAREKEY.

Changedvaluesaresavedafterruntothefinalmenu.

(2) Keyboard

: Usedtosetupaninitialzerovalue(0).

: Used tomovetheinputvaluetotheleftorrightbyoneplace.

: Usedtoincreasethesettingconstantonebyone.

: Usedtosavethevalueandtomovenextmenu.

(3) Menu

■F01: Number of scales to be linked wireless (1~9)

Setting Menu

Description

F01-1

Very fast

F01-5

Normal

F01-9

Very slow

■F02: Weight backup (0,1)

Setting Menu

Description

F02-0

Not used

F02-1

Used

■F03: Stable condition set of weight (1~9)

Setting Menu

Description

F03-1

Sensitive

F03-5

Normal

F03-9

Insensitive

■F04: Automatic zero condition (00~99)

Setting Menu

Description

F04-00

No compensation

F04-23

Compensation for gradual change below 1d for 3 sec.

F04-99

Compensation for gradual change below 4.5d for 9 sec.
