1

CAS POScale Series

User’s Manual

(English)

Ver. 2004. 01.

2

PRECAUTIONS ……………………………………………..3

PREFACE ……………………………………………………..5

CHANGING THE PRINTER ROLL…………..………….5

NAME AND FUNCTIONS …………………………………6

OPERATIONS ……………………………………………….11

I. SAELS MODE …………………………………………….11

Chapter 1 Basic Operation …………………….14

Chapter 2 Sales for Weighed item……………….21

Chapter 3 Sales for non-weighed item………...22

Chapter 4 Clerk Operation …………………………25

Chapter 5 Discount & Payment…………………..34

Chapter 6 Sales Transactions Simulation……..42

II. PROGRAM MODE …………………………………….48

Chapter 7 PLU Programming ……………………..52

Chapter 8 Report ……………………………………..57

Chapter 9 SET 1 (Discount, Barcode & HW Setting).64

Chapter 10 SET 2 (Date, Time & Default Setting)..…73

Chapter 11 Options (Receipt Formatting)..…..77

Chapter 12 Clerk ……………………………………...84

Chapter 13 Logo …………………………………….…88

Chapter 14 Tax Rate Group …………………….…91

Chapter 15 Test …………………………………….…94

CODE (MS 1252 Window Latin-1) …………………97

ERROR MESSAGES ………………………………………98

SPECIFICATION ………………………….……………...99

TABLE LIST ……………………………………………….100

CASH DRAWER INTERFACE DAWING…………….100

PROGRAM MENU MAP …………….……………….....101

3

PRECAUTIONS

static electricit

y

.

4

Risk of explosion if battery is replaced by an

incorrect type. Dispose of used batteries

according to the instruction.

Correct type of battery

5

PREFACE

Thank you for the purchasing of CAS POScale series.

This series have been designed with CAS reliability, under rigid quality

control and with outstanding performance. Your specialty departments

can enjoy with CAS product. We hope that CAS product meets your

needs.

The user manual is designed to guide you to understand product

operation and proper care of product.

CHANGING THE PRINTER ROLL

Recommended size for thermal paper;

58mm (Width) / 65μm(Thickness) /60mm (Maximum Diameter)

6

NAME AND FUNCTIONS

OVERALL VIEW

STANDARD TYPE

;

POLE TYPE

7

DISPLAY

KEYBAORD

Rear Display (Customer-side display)

Front (Clerk-side display) & Pole Display

8

Table 1: Symbols on Display

SYMBOLS DESCRIPTION

CHARGE ( ) The battery is being charged.

PAPER ( ) When blinks there is some problem with paper roll in

the printer.

∑( ) In the subtotal mode

SHIFT ( ) SHIFT key pressed

◀0▶To adjust the weight to zero.

Stable

NET Tare on

MODE Program mode

Low battery warning when it is below 7.3 voltage

9

Table 2: Key Functions

KEYS FUNCTIONS

SALES MODE PROGRAM MODE

~ To input all of numerical data

To input double zero

To clear all of numbers input on the display

To select clerk 1

To select clerk 2

To set zero

To set or clear tare value

To go to program mode

To call up a PLU with numeric key

To input non-weighed item

To alternate key functions

To turn on or off the power / backlight

To show subtotal / total / payment sum

~ Direct PLU keys

* PLU # 1~8 may be used for both of the direct and indirect PLUs.

Most commonly used 8 items are recommended to be used for

direct PLUs at users’ convenience.

+ To select clerk 3

+ To select clerk 4

09

00

C

C1

C3

C2

C4

◀0▶

◀T▶

PLU

X

SHIFT

∑

1

D

R

C2

C4

SHIFT

C1

C3

SHIFT

M

8

10

KEYS FUNCTIONS

SALES MODE PROGRAM MODE

+ To open cash drawer

+ To feed the paper

+ To make discount

After pressing After pressing

To finalize the payment in

cash

To print receipt

To print current data

To pay in c as h

+ To pay in credit

To make discount for

subtotal

Sales list - To go to the previous menu

Sales list + To go to the next menu

To delete a specific sale in

sales list

To go back to the higher

level of menu

To go into the lower level of

menu

Fast selection of PLU (-) in

the PLU mode

Fast selection of PLU (+)in

the PLU mode

X

∑

∑

3 PAY

3 PA

Y

SHIFT

3 PAY

4

%-

4

%-

1

D

R

SHIFT

SHIFT

2

LF

4

%-

SHIFT

5

◀

6

▶

7 ←

8

M
