Canon DR-5060F Manual de usuario

Backup

FILME F

FeedingOption

NewFile

Space

CountOnly

Manual

Auto

Semi-Auto

Scanner

DOCUMENT SCANNER

INSTRUCTIONS

NOTICE

transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language in any form or by

anymeans,electronic,mechanical,magnetic,optical,chemical,manual,orotherwise,withoutthepriorpermissionofCANON

ELECTRONICS INC.

wThe contents of this manual are subject to change without notice.

eEvery effort has been made to ensure the accuracy of information presented in this manual. However, Canon Electronics Inc.

and the subsidiaries on the back cover assume no responsibility for any errors or their consequences.

rWe do not assume any responsibility for damage resulting from operations regardless of item e.

Trademarks and RegisteredTrademarks

●Microsoft WindowsRand Microsoft Windows NTR are registered trademark of Microsoft Corporation in the U.S. and in

other countries.

●ISISR is a registered trademark of Pixel Translation, a division of ActionPoint Inc.

●Product names mentioned herein are for identification purposes only and may be trademarks and/or registered trademarks of

their respective companies.

INTRODUCTION

Thank you for purchasing the Canon Document Scanner DR-5060F. This manual

describes how to use Scanning Utility 5060 for scanning in images to the

computer on Document Scanner DR-5060F. Be sure to read this manual and the

separate DR-5060F Instructions before use to ensure that the functions of this

Scanning Utility are effectively utilized.

Scanner drivers such as an ISIS or TWAIN driver are not required as this

Scanning Utility packaged with the DR-5060F uses an exclusive scanner driver.

Introduction

2Introduction

CONVENTIONS

This manual uses the following symbols and indications.

Before you start reading this manual, read the following and familiarize yourself

with their meanings.

WARNING

Read carefully to avoid death or serious injury.

CAUTION

Read carefully to avoid serious injury or damage to the equipment or loss of

valuable data.

NOTE

Read carefully to avoid damage to the equipment.

MEMO

Memos indicate where you will find useful information in this manual.

Contents

INTRODUCTION.................................................................................................................. 1

CONVENTIONS................................................................................................................... 2

Chapter 1 Installation and Basic Operation of Scanning Utility 5060 ....

System Requirements ....................................................................................................... 6

Installing Scanning Utility 5060 ........................................................................................ 7

BeforeYou Begin.......................................................................................................... 7

Installing Scanning Utility 5060 .................................................................................... 7

Uninstalling Scanning Utility 5060.............................................................................. 10

Basic Scanning Utility 5060 Operations ........................................................................ 11

Starting Up Scanning Utility 5060 .............................................................................. 11

Explanation of the Scanning Utility 5060 Screen ....................................................... 12

Exiting Scanning Utility 5060 ..................................................................................... 18

Chapter 2

Scanning a Document..........................................................19

BeforeYou Start Scanning .............................................................................................. 20

Setting Basic Scan Conditions ....................................................................................... 22

Scanner Settings........................................................................................................ 23

Scanning Originals and Saving Scanned Images......................................................... 25

Scan Page.................................................................................................................. 25

Scan Batch to File...................................................................................................... 27

Film Address File Name............................................................................................. 31

Saving Scanned Images .................................................................................................. 35

Restrictions in the Number of Characters in File Names ........................................... 35

About Save Formats .................................................................................................. 35

Saving Scanned Images to File (Scan Page) ............................................................ 36

Saving Multiple Page Originals .................................................................................. 37

Opening Saved Files........................................................................................................ 39

Scanning and Printing Documents ................................................................................ 40

Printing Opened Images ............................................................................................ 40

Scan Batch to Printer ................................................................................................. 42

Other Scan Operations .................................................................................................... 45

Verify Scan................................................................................................................. 45

Using Patch Codes/Function Sheets ......................................................................... 47

4Contents

Chapter 3 Setting Detailed Scan Conditions .......................................51

Setting Scan Conditions.................................................................................................. 52

Setting up the Scanner .............................................................................................. 52

Detailed Settings .............................................................................................................. 54

Image Controls........................................................................................................... 55

Option Devices........................................................................................................... 58

Feeder Option ............................................................................................................ 63

Separation.................................................................................................................. 65

Function Key Settings ................................................................................................ 66

Setting the Gamma Curve ......................................................................................... 68

Imprinter/Addon Settings ........................................................................................... 70

Barcode Settings........................................................................................................ 75

Patch Code Settings .................................................................................................. 78

Chapter 4 Troubleshooting....................................................................81

When An Error Message orWarning is Displayed ........................................................ 82

WhenThe Scanned Image is Not Normal....................................................................... 85

Index.................................................................................................................................. 86

Installation and Basic Operation of Scanning Utility 5060

Chapter 1

Installation and Basic Operation

of Scanning Utility 5060

This chapter describes how to install

Scanning Utility 5060, and basic operation of

Scanning Utility 5060.

System Requirements................................. 6

Installing Scanning Utility 5060 .................7

BeforeYou Begin..................................... 7

Installing Scanning Utility 5060 .............7

Uninstalling Scanning Utility 5060 ...... 10

Basic Scanning Utility 5060 Operations.. 11

Starting Up Scanning Utility 5060........11

Explanation of the Scanning Utility

5060 Screen ...........................................12

Exiting Scanning Utility 5060 ...............18

6System Requirements

System Requirements

You must have the following hardware and OS for Scanning Utility 5060 to work.

●An IBM PC/AT or compatible computer with a Pentium 133 MHz CPU or

faster and at least 64 MB of memory

• OS: Microsoft Windows®95/98/Me or Microsoft Windows NT®4.0

Workstation, Microsoft Windows®2000 Professional

• At least 100 MB of hard disk space (at least 5 MB at installation)

●An SVGA compatible display

●A MicrosoftWindows compatible keyboard, mouse and printer, CD-ROM

drive (4×speed or faster recommended)

●A SCSI card whose operation has been confirmed

Operation of the following SCSI cards has been confirmed:

Adaptec AHA-2930 series and AHA-2940 series

●SCSI-2 compatible SCSI cable

MEMO

●Scanning Utility 5060 uses a dedicated scanner driver. Scanner drivers such

as the ISIS driver and TWAIN driver are not required.

●When you install Scanning Utility 5060, another folder “\ceiscan” is created

under the Windows folder in addition to the installation destination folder,

and the file “cei*.dll” is copied to \Windows\system.

Scanning Utility 5060 will not function properly if these files are modified.

●Scanning Utility 5060 uses “wnaspi32.dll” for controlling the scanner. The

scanner will not operate if “wnaspi32.dll” is not correctly installed.

NOTE

When Scanning Utility 5060 is used, set the scanner to the Backup mode or

the Scanner Only mode. If Scanning Utility 5060 is used in the Filmer only

mode, an error message is displayed when scanning is started.

Installation and Basic Operation of Scanning Utility 5060

Installing Scanning Utility 5060

This section describes how to install Scanning Utility 5060 and the installation

procedure.

BeforeYou Begin

Check the following items before you begin to install Scanning Utility 5060.

●Make sure that the OS of the computer on which you are going to install

Scanning Utility 5060 is either Microsoft Windows®95/98/Me or Microsoft

Windows NT®4.0 Workstation, Microsoft Windows®2000 Professional.

●Connection with your computer

For details on how to connect the scanner, refer to the separate DR-5060F

Instructions.

Installing Scanning Utility 5060

The following describes the procedure for installing Scanning Utility 5060 on the

computer.

Turn the scanner ON.

Turn the computer ON, and boot up Windows.

Insert the setup disc into the CD-ROM drive.

8Installing Scanning Utility 5060

Click [Start] and select Run....

At Open, type“D:¨\su5060\setup.exe” and click OK.

In these instructions, the CD-ROM drive is specified as D.

The Choose Setup Language dialog box appears.

Select English (United States) and click OK.

The Welcome dialog box appears.
